Обозначение материалов в соответствии с выбранными стандартами
| Стандарты | Номер группы материалов 10 | |||||||
|---|---|---|---|---|---|---|---|---|
| NF/AFNOR (ФРАНЦИЯ) | X200Cr12; Z 200 C 12 | 80 DCV 40; 80MoCrV42-16 | Z 120 WDCV 06-05-04-03; HS6-5-3; Z 120 WDCV 06-05-04-04; HS6-5-4 | |||||
| AISI/ASM/ ASTM/SAE/ UNS/AA (США) | D3; T30403 | 501; 502; S50100; S50200; K41545; SA213 T5 | M50; T11350; K91231; AMS 6278 | S7; T41907 | M3 Class 2; T11323 | |||
| BS (ВЕЛИКОБРИТАНИЯ) | BD 3 | |||||||
| DIN (ГЕРМАНИЯ) | X210Cr12; X 210 Cr 12 | X38CrMoV5-3; X 38 CrMoV 5 3 | 27NiCrMoV15-6; 26NiCrMoV14-5; 26 NiCrMoV 14 5 | X12CrMo5; X 11 CrMo 5; X16CrMo5-1; 12CrMo19-5; X16CrMo5-1; 12 CrMo 19 5; 80MoCrV42-16; 80 MoCrV 42 16 | M50NiL | 50CrMoV13-4; 50 CrMoV 13 4; 50CrMoV13-15 | HS6-5-3; HS 6-5-3; S 6-5-3 | |
| Werkstoff (ГЕРМАНИЯ) | 1.2080 | 1.2367 | 1.6957 | 1.7362; 1.7366 | 1.3551 | 1.3590; 1.2355; 1.2357 | 1.3344 | |
| EN (ЕВРОПА) | X210Cr12 | X38CrMoV5-3 | X12CrMo5; X16CrMo5-1 | 80MoCrV42-16; 13MoCrNiV42-16-14 | 50CrMoV13-15; HS6-5-3 | |||
| GOST (РОССИЯ) | Ch12 | |||||||
| JIS (ЯПОНИЯ) | SKD 1 | SCMV 6; SFVA F 5 A; SFVA F 5 B; SFVA F 5 C; SFVA 5 D; SNB 5 Class 1; STBA 29; STFA 25; STPA 25 | SKH 52; SKH 53 | |||||
| SS (ШВЕЦИЯ) | 2725 | |||||||
| UNE (ИСПАНИЯ) | F.521; F.5212; X 210 Cr 12 | F.240.B; TU.J; F.1351 | 80 MoCrV 40-16 | F.5605; 6-5-3 | ||||
| UNI (ИТАЛИЯ) | X 205 Cr 12 KU | |||||||
| IS (ИНДИЯ) | T215Cr12 | |||||||
| KS (РЕСПУБЛИКА КОРЕЯ) | ||||||||
| GB/YB/JB/SY/NB (КНР) | Cr12 | 1Cr5Mo | ||||||
