НАРЕЗКА РЕЗЬБЫ
Наковальни резьбы ER/IL
Наковальни для внешней правой и внутренней левой резьбы
| Обозначение | IC | a° | S |
|---|---|---|---|
| AE16 -0 | 9.52 | 0 | 3.20 |
| AE16M -0 | 9.52 | 0 | 3.20 |
| AE16 -0.5 | 9.52 | -0.5 | 3.20 |
| AE16M -0.5 | 9.52 | -0.5 | 3.20 |
| AE16 +0.5 | 9.52 | 0.5 | 3.20 |
| AE16M +0.5 | 9.52 | 0.5 | 3.20 |
| AE16 -1.5 | 9.52 | -1.5 | 3.20 |
| AE16M -1.5 | 9.52 | -1.5 | 3.20 |
| AE16 | 9.52 | 1.5 | 3.20 |
| AE16M | 9.52 | 1.5 | 3.20 |
| AE16 +2.5 | 9.52 | 2.5 | 3.20 |
| AE16M +2.5 | 9.52 | 2.5 | 3.20 |
| AE16 +3.5 | 9.52 | 3.5 | 3.20 |
| AE16 +4.5 | 9.52 | 4.5 | 3.20 |
| AE22 -0 | 12.70 | 0 | 4.00 |
| AE22M -0 | 12.70 | 0 | 4.00 |
| AE22U -0 | 12.70 | 0 | 4.00 |
| AE22 -0.5 | 12.70 | -0.5 | 4.00 |
| AE22M -0.5 | 12.70 | -0.5 | 4.00 |
| AE22U -0.5 | 12.70 | -0.5 | 4.00 |
| AE22 +0.5 | 12.70 | 0.5 | 4.00 |
| AE22M +0.5 | 12.70 | 0.5 | 4.00 |
| AE22U +0.5 | 12.70 | 0.5 | 4.00 |
| AE22 -1.5 | 12.70 | -1.5 | 4.00 |
| AE22U -1.5 | 12.70 | -1.5 | 4.00 |
| AE22 | 12.70 | 1.5 | 4.00 |
| AE22M | 12.70 | 1.5 | 4.00 |
| AE22U | 12.70 | 1.5 | 4.00 |
| AE22 +2.5 | 12.70 | 2.5 | 4.00 |
| AE22M +2.5 | 12.70 | 2.5 | 4.00 |
| AE22U +2.5 | 12.70 | 2.5 | 4.00 |
| AE22 +3.5 | 12.70 | 3.5 | 4.00 |
| AE22U +3.5 | 12.70 | 3.5 | 4.00 |
| AE22 +4.5 | 12.70 | 4.5 | 4.00 |
| AE22U +4.5 | 12.70 | 4.5 | 4.00 |
| AE27 -0 | 15.88 | 0 | 5.50 |
| AE27M -0 | 15.88 | 0 | 5.50 |
| AE27U -0 | 15.88 | 0 | 5.50 |
| AE27 -0.5 | 15.88 | -0.5 | 5.50 |
| AE27U -0.5 | 15.88 | -0.5 | 5.50 |
| AE27 +0.5 | 15.88 | 0.5 | 5.50 |
| AE27M +0.5 | 15.88 | 0.5 | 5.50 |
| AE27U +0.5 | 15.88 | 0.5 | 5.50 |
| AE27 -1.5 | 15.88 | -1.5 | 5.50 |
| AE27U -1.5 | 15.88 | -1.5 | 5.50 |
| AE27 | 15.88 | 1.5 | 5.50 |
| AE27M | 15.88 | 1.5 | 5.50 |
| AE27U | 15.88 | 1.5 | 5.50 |
| AE27 +2.5 | 15.88 | 2.5 | 5.50 |
| AE27U +2.5 | 15.88 | 2.5 | 5.50 |
| AE27U +2.5TR | 15.88 | 2.5 | 5.50 |
| AE27 +3.5 | 15.88 | 3.5 | 5.50 |
| AE27U +3.5 | 15.88 | 3.5 | 5.50 |
| AE27U +3.5TR | 15.88 | 3.5 | 5.50 |
| AE27 +4.5 | 15.88 | 4.5 | 5.50 |
| AE27U +4.5 | 15.88 | 4.5 | 5.50 |
| AE27U +4.5TR | 15.88 | 4.5 | 5.50 |
