VF4MB
CARBIDE Carbon Steel, Alloy Steel, Cast Iron Tool Steel, Pre-Hardened Steel, Hardened Steel Hardened Steel Hardened Steel
| (<30HRC) | ( | 45HRC) | ( | 55HRC) | (>55HRC) | |
| u | e | e |
Austenitic Titanium Alloy, Stainless Steel Heat Resistant Alloy
RE APMX
Copper Alloy Aluminum Alloy
BHTA2 15° Type1 LF
0.5 RE 6 Type2
±0.01 RE APMX
| 1 | DC | 12 | LF |
| 0 | |||
| - 0.020 |
| DCON=6 | 8 | DCON | 10 | DCON=12 |
| 0 | 0 | 0 | ||
| - 0.008 | - 0.009 | - 0.011 |
a 4 flute ball nose end mill for high-speed machining of hardened steel.
(mm)
| Order Number | RE | DC | APMX | LF | DCON | No. of Flutes | Stock | Type |
| VF4MBR0050 | 0.5 | 1 | 2.5 | 50 | 6 | 4 | a | 1 |
| VF4MBR0100 | 1 | 2 | 6 | 60 | 6 | 4 | a | 1 |
| VF4MBR0150 | 1.5 | 3 | 8 | 70 | 6 | 4 | a | 1 |
| VF4MBR0200 | 2 | 4 | 8 | 70 | 6 | 4 | a | 1 |
| VF4MBR0250 | 2.5 | 5 | 12 | 80 | 6 | 4 | a | 1 |
| VF4MBR0300 | 3 | 6 | 12 | 80 | 6 | 4 | a | 2 |
| VF4MBR0400 | 4 | 8 | 14 | 90 | 8 | 4 | a | 2 |
| VF4MBR0500 | 5 | 10 | 18 | 100 | 10 | 4 | a | 2 |
| VF4MBR0600 | 6 | 12 | 22 | 110 | 12 | 4 | a | 2 |
