(mm) CARBIDE
| Order Number | RE | DC | BHTA2 | APMX | LB2 | LU | B2 | DN | LF | DCON | No. of Flutes | Stock | Type | 0.5° Ef for | 1 ffec in | ° ftiv clin | 2° fe lengt ed ang | 3° f h le |
| VF3XBR0075T0024L010 | 0.75 | 1.5 | 0.4° | 1.3 | 10 | 2.8 | 8.1° | 1.54 | 60 | 6 | 3 | a | 1 | 10.6 | 1 | 0.9 | 11.4 1 | 2.0 |
| VF3XBR0075T0024L015 | 0.75 | 1.5 | 0.4° | 1.3 | 15 | 2.8 | 6.2° | 1.61 | 60 | 6 | 3 | a | 1 | 15.6 | 1 | 6.0 | 16.9 1 | 7.8 |
| VF3XBR0075T0024L020 | 0.75 | 1.5 | 0.4° | 1.3 | 20 | 2.8 | 5.0° | 1.68 | 70 | 6 | 3 | a | 1 | 20.6 | 2 | 1.2 | 22.3 2 | 3.5 |
| VF3XBR0075T0024L030 | 0.75 | 1.5 | 0.4° | 1.3 | 30 | 2.8 | 3.7° | 1.82 | 80 | 6 | 3 | a | 1 | 30.7 | 3 | 1.5 | 33.1 3 | 5.0 |
| VF3XBR0075T0054L015 | 0.75 | 1.5 | 0.9° | 1.3 | 15 | 2.8 | 6.3° | 1.82 | 60 | 6 | 3 | a | 1 | ─ | 1 | 5.7 | 16.5 1 | 7.4 |
| VF3XBR0075T0054L020 | 0.75 | 1.5 | 0.9° | 1.3 | 20 | 2.8 | 5.1° | 1.98 | 70 | 6 | 3 | a | 1 | ─ | 2 | 0.7 | 21.8 2 | 3.0 |
| VF3XBR0075T0054L030 | 0.75 | 1.5 | 0.9° | 1.3 | 30 | 2.8 | 3.7° | 2.29 | 80 | 6 | 3 | a | 1 | ─ | 3 | 0.8 | 32.4 3 | 4.2 |
| VF3XBR0075T0054L040 | 0.75 | 1.5 | 0.9° | 1.3 | 40 | 2.8 | 3.0° | 2.61 | 80 | 6 | 3 | s | 1 | ─ | 4 | 0.8 | 43.0 4 | 5.3 |
| VF3XBR0075T0130L015 | 0.75 | 1.5 | 1.5° | 1.3 | 15 | 2.8 | 6.4° | 2.08 | 60 | 6 | 3 | s | 1 | ─ | ─ | 16.1 1 | 7.0 | |
| VF3XBR0075T0130L020 | 0.75 | 1.5 | 1.5° | 1.3 | 20 | 2.8 | 5.2° | 2.34 | 70 | 6 | 3 | s | 1 | ─ | ─ | 21.2 2 | 2.4 | |
| VF3XBR0075T0130L030 | 0.75 | 1.5 | 1.5° | 1.3 | 30 | 2.8 | 3.8° | 2.86 | 80 | 6 | 3 | s | 1 | ─ | ─ | 31.5 3 | 3.2 | |
| VF3XBR0100T0024L016 | 1 | 2 | 0.4° | 1.6 | 16 | 3.6 | 5.5° | 2.07 | 70 | 6 | 3 | a | 1 | 16.7 | 1 | 7.1 | 18.0 1 | 9.0 |
| VF3XBR0100T0024L020 | 1 | 2 | 0.4° | 1.6 | 20 | 3.6 | 4.6° | 2.13 | 70 | 6 | 3 | a | 1 | 20.7 | 2 | 1.3 | 22.3 2 | 3.5 |
| VF3XBR0100T0024L025 | 1 | 2 | 0.4° | 1.6 | 25 | 3.6 | 3.9° | 2.20 | 70 | 6 | 3 | a | 1 | 25.8 | 2 | 6.4 | 27.8 2 | 9.3 |
| VF3XBR0100T0024L030 | 1 | 2 | 0.4° | 1.6 | 30 | 3.6 | 3.4° | 2.27 | 80 | 6 | 3 | a | 1 | 30.8 | 3 | 1.6 | 33.2 3 | 5.0 |
| VF3XBR0100T0024L035 | 1 | 2 | 0.4° | 1.6 | 35 | 3.6 | 2.9° | 2.34 | 80 | 6 | 3 | a | 1 | 35.8 | 3 | 6.7 | 38.6 | |
| VF3XBR0100T0024L040 | 1 | 2 | 0.4° | 1.6 | 40 | 3.6 | 2.6° | 2.41 | 80 | 6 | 3 | a | 1 | 40.8 | 4 | 1.9 | 44.0 | |
| VF3XBR0100T0054L020 | 1 | 2 | 0.9° | 1.6 | 20 | 3.6 | 4.7° | 2.42 | 70 | 6 | 3 | a | 1 | ─ | 2 | 0.8 | 21.9 2 | 3.0 |
| VF3XBR0100T0054L025 | 1 | 2 | 0.9° | 1.6 | 25 | 3.6 | 4.0° | 2.57 | 70 | 6 | 3 | a | 1 | ─ | 2 | 5.8 | 27.2 2 | 8.6 |
| VF3XBR0100T0054L030 | 1 | 2 | 0.9° | 1.6 | 30 | 3.6 | 3.4° | 2.73 | 80 | 6 | 3 | a | 1 | ─ | 3 | 0.9 | 32.5 3 | 4.2 |
| VF3XBR0100T0054L035 | 1 | 2 | 0.9° | 1.6 | 35 | 3.6 | 3.0° | 2.89 | 80 | 6 | 3 | a | 1 | ─ | 3 | 5.9 | 37.7 3 | 9.8 |
| VF3XBR0100T0054L040 | 1 | 2 | 0.9° | 1.6 | 40 | 3.6 | 2.7° | 3.04 | 80 | 6 | 3 | a | 1 | ─ | 4 | 0.9 | 43.0 | |
| VF3XBR0100T0054L050 | 1 | 2 | 0.9° | 1.6 | 50 | 3.6 | 2.2° | 3.36 | 110 | 6 | 3 | s | 1 | ─ | 5 | 1.0 | 53.6 | |
| VF3XBR0100T0054L060 | 1 | 2 | 0.9° | 1.6 | 60 | 3.6 | 1.9° | 3.67 | 110 | 6 | 3 | s | 1 | ─ | 6 | 1.0 | ||
| VF3XBR0100T0054L070 | 1 | 2 | 0.9° | 1.6 | 70 | 3.6 | 1.6° | 3.99 | 110 | 6 | 3 | s | 1 | ─ | 7 | 1.1 | ||
| VF3XBR0100T0130L025 | 1 | 2 | 1.5° | 1.6 | 25 | 3.6 | 4.1° | 3.02 | 70 | 6 | 3 | s | 1 | ─ | ─ | 26.4 2 | 7.9 | |
| VF3XBR0100T0130L030 | 1 | 2 | 1.5° | 1.6 | 30 | 3.6 | 3.5° | 3.28 | 80 | 6 | 3 | s | 1 | ─ | ─ | 31.6 3 | 3.3 | |
| VF3XBR0100T0130L035 | 1 | 2 | 1.5° | 1.6 | 35 | 3.6 | 3.1° | 3.54 | 80 | 6 | 3 | s | 1 | ─ | ─ | 36.7 3 | 8.7 | |
| VF3XBR0100T0130L040 | 1 | 2 | 1.5° | 1.6 | 40 | 3.6 | 2.7° | 3.81 | 80 | 6 | 3 | s | 1 | ─ | ─ | 41.8 | ||
| VF3XBR0125T0054L020 | 1.25 | 2.5 | 0.9° | 2 | 20 | 4.5 | 4.3° | 2.89 | 60 | 6 | 3 | s | 1 | ─ | 2 | 0.8 | 21.9 2 | 3.1 |
| VF3XBR0125T0054L030 | 1.25 | 2.5 | 0.9° | 2 | 30 | 4.5 | 3.1° | 3.20 | 80 | 6 | 3 | s | 1 | ─ | 3 | 0.9 | 32.5 3 | 4.2 |
| VF3XBR0125T0054L040 | 1.25 | 2.5 | 0.9° | 2 | 40 | 4.5 | 2.4° | 3.52 | 80 | 6 | 3 | s | 1 | ─ | 4 | 0.9 | 43.1 | |
| VF3XBR0125T0130L020 | 1.25 | 2.5 | 1.5° | 2 | 20 | 4.5 | 4.4° | 3.21 | 60 | 6 | 3 | s | 1 | ─ | ─ | 21.4 2 | 2.5 | |
| VF3XBR0125T0130L030 | 1.25 | 2.5 | 1.5° | 2 | 30 | 4.5 | 3.1° | 3.74 | 80 | 6 | 3 | s | 1 | ─ | ─ | 31.6 3 | 3.3 | |
| VF3XBR0125T0130L040 | 1.25 | 2.5 | 1.5° | 2 | 40 | 4.5 | 2.5° | 4.26 | 80 | 6 | 3 | s | 1 | ─ | ─ | 41.9 | ||
| VF3XBR0150T0024L020 | 1.5 | 3 | 0.4° | 2 | 20 | 5 | 3.8° | 3.11 | 60 | 6 | 3 | a | 1 | 20.7 | 2 | 1.3 | 22.3 2 | 3.5 |
| VF3XBR0150T0024L025 | 1.5 | 3 | 0.4° | 2 | 25 | 5 | 3.1° | 3.18 | 80 | 6 | 3 | a | 1 | 25.8 | 2 | 6.4 | 27.7 2 | 9.2 |
| VF3XBR0150T0024L030 | 1.5 | 3 | 0.4° | 2 | 30 | 5 | 2.7° | 3.25 | 80 | 6 | 3 | a | 1 | 30.8 | 3 | 1.6 | 33.2 | |
| VF3XBR0150T0024L040 | 1.5 | 3 | 0.4° | 2 | 40 | 5 | 2.1° | 3.39 | 80 | 6 | 3 | a | 1 | 40.9 | 4 | 1.9 | 44.0 | |
| VF3XBR0150T0024L050 | 1.5 | 3 | 0.4° | 2 | 50 | 5 | 1.7° | 3.53 | 100 | 6 | 3 | a | 1 | 50.9 | 5 | 2.2 | ||
| VF3XBR0150T0054L020 | 1.5 | 3 | 0.9° | 2 | 20 | 5 | 3.8° | 3.37 | 60 | 6 | 3 | a | 1 | ─ | 2 | 0.9 | 21.9 2 | 3.0 |
| VF3XBR0150T0054L030 | 1.5 | 3 | 0.9° | 2 | 30 | 5 | 2.7° | 3.69 | 80 | 6 | 3 | a | 1 | ─ | 3 | 0.9 | 32.5 | |
| VF3XBR0150T0054L040 | 1.5 | 3 | 0.9° | 2 | 40 | 5 | 2.1° | 4.00 | 80 | 6 | 3 | a | 1 | ─ | 4 | 1.0 | 43.1 | |
| VF3XBR0150T0054L050 | 1.5 | 3 | 0.9° | 2 | 50 | 5 | 1.7° | 4.31 | 100 | 6 | 3 | a | 1 | ─ | 5 | 1.0 | ||
| VF3XBR0150T0054L060 | 1.5 | 3 | 0.9° | 2 | 60 | 5 | 2.3° | 4.63 | 110 | 8 | 3 | a | 1 | ─ | 6 | 1.1 | 64.2 | |
| VF3XBR0150T0054L070 | 1.5 | 3 | 0.9° | 2 | 70 | 5 | 2.0° | 4.94 | 120 | 8 | 3 | a | 1 | ─ | 7 | 1.1 | 74.8 | |
| VF3XBR0150T0130L040 | 1.5 | 3 | 1.5° | 2 | 40 | 5 | 2.2° | 4.73 | 80 | 6 | 3 | s | 1 | ─ | ─ | 41.9 | ||
| VF3XBR0150T0130L050 | 1.5 | 3 | 1.5° | 2 | 50 | 5 | 2.8° | 5.26 | 110 | 8 | 3 | s | 1 | ─ | ─ | 52.2 | ||
| VF3XBR0150T0130L060 | 1.5 | 3 | 1.5° | 2 | 60 | 5 | 2.4° | 5.78 | 110 | 8 | 3 | s | 1 | ─ | ─ | 62.4 | ||
| VF3XBR0150T0130L070 | 15 | 3 | 15° | 2 | 70 | 5 | 21° | 630 | 120 | 8 | 3 | s | 1 | ─ | ─ | 727 | ||
| VF3XBR0200T0054L030 | . 2 | 4 | . 0.9° | 3 | 30 | 6 | . 3.5° | . 4.65 | 90 | 8 | 3 | a | 1 | ─ | 3 | 0.9 | . 32.5 3 | 4.2 |
