CARBIDE

y Plunging

When machine rigidity, work material rigidity and chip discharge are enough, please select the high efficiency cutting conditions. When either machine rigidity, work material rigidity or chip discharge are not enough, please select the general-purpose cutting conditions.

High efficiency cutting conditions

Work Mtil	Carb Mild	on stee steel	l,	Allo	y stee	l,	Pre-h Carbo Alloy	ardene n stee tool st	d ste l, All eel	el, oy stee	l,	Auste Marte Titani	ni ns um	tic, F itic s allo	er ta y	ritic inle	an ss	d s	teel,	Hard Coba	ened sta ly chro	inless steel, mium alloy		Copp	er,	Co	pper	allo	y
aera	AISI AST	1045, M A36,	AI A	SI 41 ISI 1	40, 010		AISI AISI 4	P21, AI 340, S	SI P KD,	20, SKT		AISI 3	0	4, AI	SI	31	6, T	i-	6Al-4V	AISI 15-5	630, AI PH, 17	SI 631 -4PH
DC	Cutting speed	Revolution	Tab	le feed H	ole Depth	Step	Cutting speed	Revolution T	able fee	d Hole Depth	Step	Cutting speed R	ev	olution T	abl	e feed	Hole	Dep	th Step	Cutting speed	Revolution	Table feed Hole Dept	h Step	Cutting speed	Revol	ution	Table fee	d Hole	Depth	Step
(mm)	(m/min)	(min-1)	(m	m/min)	ap (mm)	(mm)	(m/min)	(min-1) (	mm/min)	ap (mm)	(mm)	(m/min)	(m	in-1) (	mm	/min)	ap (	mm	) (mm)	(m/min)	(min-1)	(mm/min) ap (mm)	(mm)	(m/min)	(min	-1)	(mm/min	) ap	(mm)	(mm)
1	65	20000		160	0.5	0.1	50	16000	100	0.5	0.1	50	16	000		50	0	.5	0.05	30	9500	30 0.5	0.05	75	240	00	190		0.5	0.1
1.5	85	18000		270	0.75	0.3	60	13000	120	0.75	0.3	60	13	000		80	0	.7	5 0.1	35	7400	40 0.75	0.1	100	210	00	320		0.75	0.3
2	100	16000		480	2	0.5	70	11000	200	2	0.4	60	9	500		90	1		0.15	40	6400	60 1	0.1	120	190	00	570		2	0.5
3	100	11000		660	3	1	70	7400	270	3	0.6	60	6	400	1	00	1	.5	0.2	40	4200	60 1.5	0.2	120	130	00	780		3	1.0
4	100	8000		800	4	2	70	5600	340	4	0.8	60	4	800	1	00	2		0.4	40	3200	60 2	0.4	120	95	00	950		4	2
5	100	6400		960	5	2.5	70	4500	410	5	1	60	3	800	1	00	2	.5	0.5	40	2500	60 2.5	0.5	120	76	00	1100		5	2.5
6	100	5300		950	6	3	70	3700	440	6	1.2	60	3	200	1	00	3		0.6	40	2100	60 3	0.6	120	64	00	1200		6	3
8	100	4000		720	8	4	70	2800	340	8	1.6	60	2	400		70	4		0.6	40	1600	50 4	0.6	120	48	00	860		8	4
10	100	3200		580	10	5	70	2200	260	10	2.5	60	1	900		60	5		0.6	40	1300	40 5	0.6	120	38	00	680	1	0	5
12	100	2700		490	12	5	70	1900	230	12	3	60	1	600		50	6		0.6	40	1100	30 6	0.6	120	32	00	580	1	2	5
16	100	2000		360	16	5	70	1400	170	16	4	60	1	200		40	8		0.6	40	800	20 8	0.6	120	24	00	430	1	6	5
20	100	1600		290	20	5	70	1100	130	20	5	60		950		30	10		0.6	40	640	20 10	0.6	120	19	00	340	2	0	5
Depth
Gene of cut	ral p	urpo	s	e c	utti	ng c	ondi	tion	s									a	p
Work	Carb Mild	on stee steel	l,	Allo	y stee	l,	Pre-h Carbo Alloy	ardene n stee tool st	d ste l, All eel	el, oy stee	l,	Auste Marte Titani	ni ns um	tic, F itic s allo	er ta y	ritic inle	an ss	d s	teel,	Hard Coba	ened sta ly chro	inless steel, mium alloy		Copp	er,	Co	pper	allo	y
Mtil
aera	AISI	1045	AI	SI 41	40		AISI	P21 AI	SI P	20		AISI 3	0	4 AI	SI	31	6 T	i-	6Al-4V	AISI	630 AI	SI 631
	AST	, M A36,	A	ISI 1	, 010		AISI 4	, 340, S	KD,	, SKT				,			,			15-5	, PH, 17	-4PH
DC	Cutting speed	Revolution	Tab	le feed H	ole Depth	Step	Cutting speed	Revolution T	able fee	d Hole Depth	Step	Cutting speed R	ev	olution T	abl	e feed	Hole	Dep	th Step	Cutting speed	Revolution	Table feed Hole Dept	h Step	Cutting speed	Revol	ution	Table fee	d Hole	Depth	Step
(mm)	(m/min)	(min-1)	(m	m/min)	ap (mm)	(mm)	(m/min)	(min-1) (	mm/min)	ap (mm)	(mm)	(m/min)	(m	in-1) (	mm	/min)	ap (	mm	) (mm)	(m/min)	(min-1)	(mm/min) ap (mm)	(mm)	(m/min)	(min	-1)	(mm/min	) ap	(mm)	(mm)
1	65	20000		160	0.5	0.05	50	16000	100	0.5	0.05	50	16	000		50	0	.5	0.05	30	9500	30 0.5	0.05	75	240	00	190		0.5	0.05
1.5	85	18000		270	0.75	0.15	60	13000	120	0.75	0.1	60	13	000		80	0	.7	5 0.05	35	7400	40 0.75	0.05	100	210	00	320		0.75	0.15
2	100	16000		480	2	0.25	70	11000	200	2	0.2	60	9	500		90	1		0.05	40	6400	60 1	0.05	120	190	00	570		2	0.25
3	100	11000		660	3	0.3	70	7400	270	3	0.3	60	6	400	1	00	1	.5	0.1	40	4200	60 1.5	0.1	120	130	00	780		3	0.3
4	100	8000		800	4	0.4	70	5600	340	4	0.4	60	4	800	1	00	2		0.2	40	3200	60 2	0.2	120	95	00	950		4	0.4
5	100	6400		960	5	0.5	70	4500	410	5	0.5	60	3	800	1	00	2	.5	0.25	40	2500	60 2.5	0.25	120	76	00	1100		5	0.5
6	100	5300		950	6	0.6	70	3700	440	6	0.6	60	3	200	1	00	3		0.3	40	2100	60 3	0.3	120	64	00	1200		6	0.6
8	100	4000		720	8	0.7	70	2800	340	8	0.7	60	2	400		70	4		0.3	40	1600	50 4	0.3	120	48	00	860		8	0.7
10	100	3200		580	10	0.75	70	2200	260	10	0.75	60	1	900		60	5		0.3	40	1300	40 5	0.3	120	38	00	680	1	0	0.75
12	100	2700		490	12	0.75	70	1900	230	12	0.75	60	1	600		50	6		0.3	40	1100	30 6	0.3	120	32	00	580	1	2	0.75
16	100	2000		360	16	0.75	70	1400	170	16	0.75	60	1	200		40	8		0.3	40	800	20 8	0.3	120	24	00	430	1	6	0.75
20	100	1600		290	20	0.75	70	1100	130	20	0.75	60		950		30	10		0.3	40	640	20 10	0.3	120	19	00	340	2	0	0.75
Depth of cut																		a	p

I

Note 1) SMART MIRACLE coating has reduced electric conductivity; therefore an external contact type (electric transmitted) tool setter may not work.
