| Work Material | S Heat-resistant Alloy, Titanium Alloy | Cuttin :S | g Cond table C | itions( utting | Guide) : :Gen | eral Cutt | ing | :Unstab | le Cutting | (inch) | |
| Shape | Order Number | MP9130 Stock Coated | L | LE | W1 | INSL | S | BS | RE | Geometr | y |
| General | XNMU190912R-MS | a | .752 | .650 | .374 | .500 | .335 | .039 | .047 | L | |
| Purpose | XNMU190916R-MS | a | .752 | .650 | .374 | .500 | .335 | .039 | .063 | W1 S | S |
| XNMU190924R-MS | a | .752 | .654 | .374 | .500 | .335 | .039 | .094 | B RE | ||
| XNMU190932R-MS 1 | a | .795 | .673 | .374 | .500 | .335 | ─ | .126 | LE | ||
| XNMU190940R-MS 1 | a | .858 | .701 | .374 | .500 | .335 | ─ | .157 | SL | ||
| XNMU190950R-MS 1 | a | .858 | .701 | .374 | .500 | .335 | ─ | .197 | IN | ||
| Cutting Edge | XNMU190912R-HS | a | .752 | .650 | .374 | .500 | .335 | .039 | .047 | L | |
| Enhancement Type | LE W1 BS RE INSL | S | |||||||||
| Chip Processing | XNMU190912R-LS | a | .752 | .650 | .374 | .500 | .335 | .039 | .047 | L | |
| Type | LE W1 BS RE INSL | S |
Note 1) Note for insert with a corner radius of .126" and above, as corner radius increases the LF dimension increases. Corner radius .126": LF+.028" Corner radius .157": LF+.059" Corner radius .197": LF+.059"
