DCON
DC
KAPR
APMX
LH
LF

Metric Standard
*1 Combination Type
y SHANK TYPE (A Holders)
With Coolant Hole Right hand tool holder only.
* 2
Number of Flutes
Stock
Dimensions (mm) [inch]
Total
Order Number
R DC DCON LF LH APMX Insert Screw Wrench Anti-seize Insert Type
Lubricant
APX4KR4008SA42S056A s 2 8 40 42 160 80 56 TPS43 TIP15W MK1KS
APX4KR4012SA42S056A s 3 12 40 42 160 80 56 TPS43 TIP15W MK1KS
AOMT1848
* 1 APX4KR5012WA508S056A s 3 12 50 50.8 [2.0"]
MK1KS 160 80 56 TPS43 TIP15W
* 1 APX4KR5018WA508M084A s 3 18
TPS43 50 50.8 [2.0"]
TIP15W MK1KS 190 110 84
* 2 Clamp Torque (lbf-in) : TPS43=35.4
Note 1) When using inserts with corner radius RE> .126" on the bottom, B-Holders or C-Holders are required as shown on page L117.
Note 2) Only corner radius RE .016" and .031" can be used for the peripheral cutting edges except the bottom cutting edge (the end cuttting edge).
Note 3) When using the tool at high spindle speeds, ensure that the tool and arbor are correctly balanced.
CBDP
L8
KWW
DCSFMS
DCON
DAH
DC


Right hand tool holder only.
KAPR
APMX
DC Set Bolt Geometry
LF
Metric Standard For Inch Arbors & 50 mm HSC10050
y SHELL TYPE (A Holders)
& 63 mm HSC12070
With Coolant Hole The bore diameter (DCON) is equivalent to a metric size.
*
Number of Flutes
Stock


Dimensions (mm) [inch]
Total


Order Number
R DC LF DCON CBDP DAH DCSFMS KWW L8 APMX Insert Screw Wrench Anti-seize Insert Type
Lubricant
APX4KR06316CA056A s 4 16 63 85 25.4 [1.0"] 26 13 60.7 9.5 6 56 TPS43 TIP15W MK1KS AOMT1848
* Clamp Torque (lbf-in) : TPS43=35.4 L
Metric Standard For Metric Arbors INDEXABLE MILLING
y SHELL TYPE (A Holders)
With Coolant Hole
*
Number of Flutes
Stock


Dimensions (mm)
Total


Order Number
R DC LF DCON CBDP DAH DCSFMS KWW L8 APMX Insert Screw Wrench Anti-seize Insert Type
Lubricant
APX4K-050A09A042RA s 3 9 50 65 22 22 11 48 10.4 6.3 42 TPS43 TIP15W MK1KS
AOMT1848
APX4K-063A16A056RA s 4 16 63 85 27 28 13 60.7 12.4 7 56 TPS43 TIP15W MK1KS
*NoteClamp Torque (lbf-in) : TPS43=35.4
1) When using inserts with corner radius RE> .126" on the bottom, B-Holders or C-Holders are required as shown on page L117.
Note 2) Only corner radius RE .016" and .031" can be used for the peripheral cutting edges except the bottom cutting edge (the end cuttting edge).
Note 3) When using the tool at high spindle speeds, ensure that the tool and arbor are correctly balanced.
Note 4) In case of internal coolant supply, please use a face mill arbor with through coolant channels; Regular center-thru or side-thru arbors can't be used.
Note 5) Set bolt not included.
INSERTS L116 SPARE PARTS N001
OPERATION GUIDANCE L123 TECHNICAL DATA P001 L121
