INDEXABLE MILLING A CRKS DCSFMS DCON DC KAPR A APMX .394", 10 mm LF L11 H OAL Section A-A y SCREW-IN TYPE With Coolant Hole Right hand tool holder only. * 1 Number of Teeth Stock Dimensions (inch) DC Order Number WT LF OAL DCON DCSFMS L11 H * CRKS 2 (lbs) Insert Screw Wrench Anti-seize Lubricant Insert Type .625 APX3000UR102AM08A30 a 2 1.181 1.890 .335 .512 .236 .394 M8 .2 TPS25 TIP07F MK1KS AOpT1236 .750 APX3000UR122AM10A30 a 2 1.181 1.929 .413 .709 .236 .551 M10 .2 TPS25 TIP07F MK1KS AOpT1236 .750 APX3000UR123AM10A30 a 3 1.181 1.929 .413 .709 .236 .551 M10 .2 TPS25 TIP07F MK1KS AOpT1236 .875 APX3000UR142AM10A30 a 2 1.181 1.929 .413 .709 .236 .551 M10 .2 TPS25-1 TIP07F MK1KS AOpT1236 .875 APX3000UR143AM10A30 a 3 1.181 1.929 .413 .709 .236 .551 M10 .2 TPS25-1 TIP07F MK1KS AOpT1236 1.000 APX3000UR163AM12A35 a 3 1.378 2.244 .492 .827 .236 .748 M12 .4 TPS25-1 TIP07F MK1KS AOpT1236 1.000 APX3000UR164AM12A35 a 4 1.378 2.244 .492 .827 .236 .748 M12 .4 TPS25-1 TIP07F MK1KS AOpT1236 1.125 APX3000UR184AM12A35 a 4 1.378 2.244 .492 .827 .236 .748 M12 .4 TPS25-1 TIP07F MK1KS AOpT1236 1.250 APX3000UR205AM16A40 a 5 1.575 2.480 .669 1.142 .236 .945 M16 .7 TPS25-1 TIP07F MK1KS AOpT1236 1.375 APX3000UR225AM16A40 a 5 1.575 2.480 .669 1.142 .236 .945 M16 .7 TPS25-1 TIP07F MK1KS AOpT1236 * 1 Clamp Torque (lbf-in) : TPS25=8.9, TPS25 ─ 1=8.9 * 2 Clamp Torque of the Head (lbf-ft) : M8=17.1, M10=33.8, M12=59.2, M16=66.7 Metric Standard y SCREW-IN TYPE With Coolant Hole *1 Number of Teeth Dimensions (mm) Stock DC Order Number WT LF OAL DCON DCSFMS L11 H * kg) CRKS 2 ( Insert Screw Wrench Anti-seize Lubricant Insert Type 16 APX3000R162M08A30 s 2 30 48 8.5 13 6 10 M8 0.1 TPS25 TIP07F MK1KS AOpT1236 18 APX3000R182M08A30 s 2 30 48 8.5 13 6 10 M8 0.1 TPS25 TIP07F MK1KS AOpT1236 20 APX3000R203M10A30 s 3 30 49 10.5 18 6 14 M10 0.1 TPS25 TIP07F MK1KS AOpT1236 L 22 APX3000R223M10A30 s 3 30 49 10.5 18 6 14 M10 0.1 TPS25-1 TIP07F MK1KS AOpT1236 25 APX3000R254M12A35 s 4 35 57 12.5 21 6 19 M12 0.2 TPS25-1 TIP07F MK1KS AOpT1236 28 APX3000R284M12A35 4 35 57 12.5 21 6 19 M12 0.2 TPS25-1 TIP07F MK1KS AOpT1236 INDEXABLE MILLING s 30 APX3000R304M16A40 s 4 40 63 17 29 6 24 M16 0.3 TPS25-1 TIP07F MK1KS AOpT1236 32 APX3000R325M16A40 s 5 40 63 17 29 6 24 M16 0.3 TPS25-1 TIP07F MK1KS AOpT1236 35 APX3000R355M16A40 s 5 40 63 17 29 6 24 M16 0.3 TPS25-1 TIP07F MK1KS AOpT1236 40 APX3000R406M16A40 s 6 40 63 17 29 6 24 M16 0.3 TPS25-1 TIP07F MK1KS AOpT1236 *12 Clamp Torque (lbf-in) : TPS25=8.9, TPS25 ─ 1=8.9 * Clamp Torque of the Head (lbf-ft) : M8=17.1, M10=33.8, M12=59.2, M16=66.7 a : USA Stock s : Stocked in Japan L102 <10 inserts in one case>
