| P M Steel Stainless Steel | Cutting :Sta | Conditions(Guid ble Cutting :G | e) : eneral Cutting :Unsta | ble Cutting | ||||
| Work | K Cast Iron | |||||||
| Material | N Non-ferrous Metal | |||||||
| S H Heat Resistant Alloy, Titaniu Hardened Steel | m Alloy | Edge Pr E :Rou | eparation : ndF :Sharp Ed | ge | ||||
| Shape | Order Number | Class Edge Preparation | MC5020 MP6120 MP6130 MP7130 MP9120 MP9130 VP15TF VP20RT Coated | TF15 Carbid | L W1 e Dimen | S BS RE sions(inch) | Geometry | |
| General | AOMT123602PEER-M | M E | a a a a a a a | .472 .260 | .142 .071 .008 | |||
| MBreaker | AOMT123604PEER-M | M E | a a a a a a a | .472 .260 | .142 .063 .016 | |||
| AOMT123608PEER-M | M E | a a a a a a a | .472 .260 | .142 .047 .031 | ||||
| AOMT123610PEER-M | M E | a a a a a s s | .472 .260 | .142 .039 .039 | L | |||
| AOMT123612PEER-M | M E | a a a a a a a | .472 .260 | .142 .031 .047 | W1 BS | |||
| AOMT123616PEER-M | M E | a a a a a a a | .472 .260 | .142 .016 .063 | AN 11° | |||
| AOMT123620PEER-M | M E | a a a a a a a | .472 .260 | .142 .016 .079 | .394 RE | S | ||
| AOMT123624PEER-M | M E | a a a a a a a | .472 .260 | .142 .016 .094 | ||||
| AOMT123630PEER-M | M E | a a a a a a a | .472 .260 | .142 .016 .118 | ||||
| AOMT123632PEER-M | M E | a a a a a a a | .472 .260 | .142 .016 .126 | ||||
| Strong Cutting | AOMT123604PEER-H | M E | a a a a a a a a | .472 .260 | .142 .063 .016 | |||
| Edge Type HBreaker | AOMT123608PEER-H | M E | a a a a a a a a | .472 .260 | .142 .047 .031 | L | ||
| AOMT123616PEER-H | M E | a a a a a a a a | .472 .260 | .142 .016 .063 | 1 S | |||
| .394 RE W B | AN 11° S | |||||||
| For Machining of | AOGT123602PEFR-GM | G F | a | .472 .260 | .142 .071 .008 | |||
| Aluminum Alloy GMBreaker | AOGT123604PEFR-GM | G F | a | .472 .260 | .142 .063 .016 | L | ||
| AOGT123608PEFR-GM | G F | a | .472 .260 | .142 .047 .031 | W1 BS | |||
| .394 RE | AN 11° S |
Note 1) For large R inserts APX offers various nose radii for inserts, however one holder can not secure every insert radius. We offer A-Holders that properly secures up to .079" radius. We offer B-Holders that secures .094", .118" and .126" radius, only for popular inch sizes. Customers may modify holders as below, so that larger nose radii can be secured. L
Note on Use of Inserts with Large Corner Radii
When using inserts with corner radius RE>R.094", RE R
please machine the holder with a radius form as shown .094" .118" .106" on the right table. (B-Holder) .126"
R : Holder End Radius RE : Insert Corner Radius R RE Or additional B-Holders are available as non stock, produced to order only. "Order numbers"; Please add "B" to the end of the order number of A-Holders. Ex) APX3000R160M08A30→APX3000R162M08A30B
