Общий каталог Mitsubishi 2020 - 2021 - страница 1243
Навигация
Каталог Mitsubishi Materials запасные части
Каталог Mitsubishi Materials резьбонарезной инструмент
Каталог Mitsubishi Materials СНП с CBN и PCD для токарной обработки
Каталог Mitsubishi Materials сверлильные инструменты
Каталог Mitsubishi Materials расточной инструмент
Каталог Mitsubishi Materials пластины для точения
Fig.1 Fig.2 ø80 ø100 ø125 DCSFMS
DCSFMS ø160 DCON
DCON KWW KWW
KAPR KAPR DAH DCCB DCCB DC DC DCX DCX
| Fig.3 | Fig.4 | Fig.5 | |||
| DCSFMS | DCSFMS | ||||
| ø160 | ø66.7 | ø200 | ø315 | ø177.8 | |
| DCON | ø250 | DCSFMS | ø101.6 | ||
| KWW | DAH | ø101.6 | |||
| DCON | DCON | ||||
| KWW | DAH | DAH ø22 KWW |
KAPR KAPR
| DCCB | DCCB | DCCB |
| DC | DC | DC |
| DCX | DCX | DCX |
Right hand tool holder shown.
CBDP LF KAPR
(mm)
| DCON | DC | Order Number | CBDP | DAH | DCCB | LCCB | DCSFMS | KWW | L8 | Fig. |
| 47.625 | 200 | AHX640WL20020K | 35 | 18 | 140 | 26.8 | 175 | 25.4 | 14.22 | 4 |
| 47.625 | 200 | AHX640WL20028K | 35 | 18 | 140 | 26.8 | 175 | 25.4 | 14.22 | 4 |
| 47.625 | 200 | AHX640WR20020K | 35 | 18 | 140 | 26.8 | 175 | 25.4 | 14.22 | 4 |
| 47.625 | 200 | AHX640WR20028K | 35 | 18 | 140 | 26.8 | 175 | 25.4 | 14.22 | 4 |
| 47.625 | 250 | AHX640WL25024K | 35 | 18 | 180 | 26.8 | 220 | 25.4 | 14.22 | 4 |
| 47.625 | 250 | AHX640WL25036K | 35 | 18 | 180 | 26.8 | 220 | 25.4 | 14.22 | 4 |
| 47.625 | 250 | AHX640WR25024K | 35 | 18 | 180 | 26.8 | 220 | 25.4 | 14.22 | 4 |
| 47.625 | 250 | AHX640WR25036K | 35 | 18 | 180 | 26.8 | 220 | 25.4 | 14.22 | 4 |
| 47.625 | 315 | AHX640WL31528P | 40 | 18 | 225 | 21.8 | 285 | 25.4 | 14.22 | 5 |
| 47.625 | 315 | AHX640WL31544P | 40 | 18 | 225 | 21.8 | 285 | 25.4 | 14.22 | 5 |
| 47.625 | 315 | AHX640WR31528P | 40 | 18 | 225 | 21.8 | 285 | 25.4 | 14.22 | 5 |
| 47.625 | 315 | AHX640WR31544P | 40 | 18 | 225 | 21.8 | 285 | 25.4 | 14.22 | 5 |
| 50.8 | 160 | AHX640WL16016F | 38 | ─ | 72 | 23.8 | 100 | 19.1 | 11 | 2 |
| 50.8 | 160 | AHX640WL16022F | 38 | ─ | 72 | 23.8 | 100 | 19.1 | 11 | 2 |
| 50.8 | 160 | AHX640WR16016F | 38 | ─ | 72 | 23.8 | 100 | 19.1 | 11 | 2 |
| 50.8 | 160 | AHX640WR16022F | 38 | ─ | 72 | 23.8 | 100 | 19.1 | 11 | 2 |
| 60 | 200 | AHX640W-200C20L | 32 | 18 | 135 | 29.8 | 155 | 25.7 | 14 | 4 |
| 60 | 200 | AHX640W-200C20R | 32 | 18 | 135 | 29.8 | 155 | 25.7 | 14 | 4 |
| 60 | 200 | AHX640W-200C28L | 32 | 18 | 135 | 29.8 | 155 | 25.7 | 14 | 4 |
| 60 | 200 | AHX640W-200C28R | 32 | 18 | 135 | 29.8 | 155 | 25.7 | 14 | 4 |
| 60 | 250 | AHX640W-250C24L | 32 | 18 | 180 | 29.8 | 200 | 25.7 | 14 | 4 |
| 60 | 250 | AHX640W-250C24R | 32 | 18 | 180 | 29.8 | 200 | 25.7 | 14 | 4 |
| 60 | 250 | AHX640W-250C36L | 32 | 18 | 180 | 29.8 | 200 | 25.7 | 14 | 4 |
| 60 | 250 | AHX640W-250C36R | 32 | 18 | 180 | 29.8 | 200 | 25.7 | 14 | 4 |
| 60 | 315 | AHX640W-315C28L | 57 | 18 | 225 | 21.8 | 285 | 25.7 | 14 | 5 |
| 60 | 315 | AHX640W-315C28R | 57 | 18 | 225 | 21.8 | 285 | 25.7 | 14 | 5 |
| 60 | 315 | AHX640W-315C44L | 57 | 18 | 225 | 21.8 | 285 | 25.7 | 14 | 5 |
| 60 | 315 | AHX640W-315C44R | 57 | 18 | 225 | 21.8 | 285 | 25.7 | 14 | 5 |
