CARBIDE (mm)
| Order Number | DC | RE | BHTA2 | APMX | LU | LB2 | DN | B2 | LF | DCON | No. of Flt | tock | Ef for | ffectiv inclin | fe lengt ed ang | f h le |
| ues | S | 0.5° | 1° | 2° | 3° | |||||||||||
| VFHVRBD030R08N020T09 | 3 | 0.8 | 0.9° | 3 | 6 | 20 | 2.9 | 3.6° | 80 | 6 | 4 | a | ─ | 20.9 | 22.4 | 24.1 |
| VFHVRBD030R08N025T09 | 3 | 0.8 | 0.9° | 3 | 6 | 25 | 2.9 | 3° | 80 | 6 | 4 | a | ─ | 25.9 | 27.8 | 30 |
| VFHVRBD030R08N030T09 | 3 | 0.8 | 0.9° | 3 | 6 | 30 | 2.9 | 2.6° | 80 | 6 | 4 | a | ─ | 30.9 | 33.1 | |
| VFHVRBD030R08N040T09 | 3 | 0.8 | 0.9° | 3 | 6 | 40 | 2.9 | 2° | 90 | 6 | 4 | a | ─ | 40.9 | 43.9 | |
| VFHVRBD030R08N050T09 | 3 | 0.8 | 0.9° | 3 | 6 | 50 | 2.9 | 1.7° | 90 | 6 | 4 | a | ─ | 50.9 | ||
| VFHVRBD030R08N060T09 | 3 | 0.8 | 0.9° | 3 | 6 | 60 | 2.9 | 1.4° | 100 | 6 | 4 | a | ─ | 60.9 | ||
| VFHVRBD040R10N025T04 | 4 | 1 | 0.4° | 4 | 7 | 25 | 3.9 | 2.1° | 80 | 6 | 4 | s | 25.7 | 26.6 | 28.5 | |
| VFHVRBD040R10N030T04 | 4 | 1 | 0.4° | 4 | 7 | 30 | 3.9 | 1.8° | 80 | 6 | 4 | s | 30.7 | 31.8 | ||
| VFHVRBD040R10N035T04 | 4 | 1 | 0.4° | 4 | 7 | 35 | 3.9 | 1.6° | 80 | 6 | 4 | s | 35.7 | 36.9 | ||
| VFHVRBD040R10N040T04 | 4 | 1 | 0.4° | 4 | 7 | 40 | 3.9 | 1.4° | 80 | 6 | 4 | s | 40.7 | 42.1 | ||
| VFHVRBD040R10N045T04 | 4 | 1 | 0.4° | 4 | 7 | 45 | 3.9 | 1.3° | 90 | 6 | 4 | s | 45.7 | 47.3 | ||
| VFHVRBD040R10N050T04 | 4 | 1 | 0.4° | 4 | 7 | 50 | 3.9 | 1.2° | 90 | 6 | 4 | s | 50.7 | 52.5 | ||
| VFHVRBD040R10N025T09 | 4 | 1 | 0.9° | 4 | 7 | 25 | 3.9 | 2.2° | 90 | 6 | 4 | a | ─ | 25.9 | 27.8 | |
| VFHVRBD040R10N030T09 | 4 | 1 | 0.9° | 4 | 7 | 30 | 3.9 | 1.9° | 90 | 6 | 4 | a | ─ | 30.9 | ||
| VFHVRBD040R10N040T09 | 4 | 1 | 0.9° | 4 | 7 | 40 | 3.9 | 1.4° | 100 | 6 | 4 | a | ─ | 40.9 | ||
| VFHVRBD040R10N050T09 | 4 | 1 | 0.9° | 4 | 7 | 50 | 3.9 | 1.2° | 100 | 6 | 4 | a | ─ | 50.9 | ||
| VFHVRBD040R10N060T09 | 4 | 1 | 0.9° | 4 | 7 | 60 | 3.9 | 1° | 100 | 6 | 4 | a | ─ | 60.9 | ||
| VFHVRBD060R15N040T09 | 6 | 1.5 | 0.9° | 9 | 12 | 40 | 5.85 | 1.4° | 110 | 8 | 4 | a | ─ | 41.4 | ||
| VFHVRBD060R15N050T09 | 6 | 1.5 | 0.9° | 9 | 12 | 50 | 5.85 | 1.2° | 110 | 8 | 4 | a | ─ | 51.4 | ||
| VFHVRBD060R15N060T09 | 6 | 1.5 | 0.9° | 9 | 12 | 60 | 5.85 | 1° | 110 | 8 | 4 | a | ─ | 61.4 | ||
| VFHVRBD060R15N070T09 | 6 | 1.5 | 0.9° | 9 | 12 | 70 | 5.85 | 0.9° | 110 | 8 | 4 | a | ─ | |||
| VFHVRBD080R20N060T09 | 8 | 2 | 0.9° | 12 | 15 | 60 | 7.85 | 1° | 150 | 10 | 4 | s | ─ | 61.5 | ||
| VFHVRBD080R20N080T09 | 8 | 2 | 0.9° | 12 | 15 | 80 | 7.85 | 0.8° | 150 | 10 | 4 | s | ─ | |||
| VFHVRBD100R20N080T09 | 10 | 2 | 0.9° | 15 | 18 | 80 | 9.7 | 2° | 130 | 16 | 4 | s | ─ | 82 | 88 | |
| VFHVRBD100R20N120T09 | 10 | 2 | 0.9° | 15 | 18 | 120 | 9.7 | 1.4° | 180 | 16 | 4 | s | ─ | 122 | ||
| VFHVRBD120R20N080T09 | 12 | 2 | 0.9° | 18 | 21 | 80 | 11.7 | 1.4° | 130 | 16 | 4 | s | ─ | 82.2 | ||
| VFHVRBD120R20N120T09 | 12 | 2 | 0.9° | 18 | 21 | 120 | 11.7 | 1° | 180 | 16 | 4 | s | ─ | 122.2 |
