VF8MHVCH

End mill, Medium cut length, Irregular helix flutes, with multiple thru-coolant 45°

CARBIDE Carbon Steel, Alloy Steel, Cast Iron Tool Steel, Pre-Hardened Steel, Hardened Steel Hardened Steel Hardened Steel Austenitic Titanium Alloy,

(<30HRC) ( 45HRC) ( 55HRC) (>55HRC) Stainless Steel Heat Resistant Alloy Copper Alloy Aluminum Alloy

u u e e

CoolStar Type1 APMX LF

16<DC<20 0 - 0.03

DCON=16 DCON=20

0 0 - 0.011 - 0.013 a Vibration control end mill with multiple internal through coolant holes ensures stable machining on difficult-to-cut materials and applications requiring long overhangs. (mm)

Order NumberDCAPMXLFDCONNo. of FlutesStockType
VF8MHVCHD1600163290168s1
VF8MHVCHD20002038100208s1

RECOMMENDED CUTTING CONDITIONS

yShoulder milling

I

Alloy steel, Tool steel,Austenitic stainless steel,Heat resistant alloy
WorkPre-hardened steelTitanium alloy
Material
AISI H13, AISI W1-10, AISI P21AISI 304, AISI 306, Ti-6Al-4VInconel718
DCRevolutionTable feedRevolutionTable feedRevolutionTable feed
(mm)(min -1)(mm/min)(IPM)(min -1)(mm/min)(IPM)(min-1)(mm/min)(IPM)
164000240094.53000210082.78002409.4
203200190074.82400190074.86402007.9
<0.08DC<0.05DC
Depth of
cut0.5DC─1.5DC0.5DC─1.5DC

yTrochoidal milling DC:Dia. Note 1) If the depth of cut is shallow,

Work MaterialAlloy steel, Tool s AISI H13, AISI Wteel, Pre-hardene 1-10, AISI P21d steelAustenitic stainle Titanium alloy AISI 304, AISI 30ss steel, 6, Ti-6Al-4V
DCRevolutionTablefeedRevolutionTablefeed
(mm)(min-1)(mm/min)(IPM)(min-1)(mm/min)(IPM)
164000190074.83000140055.1
203200150059.02400120047.2
Depth of cut1.5DC0.5DC─1.5DC

mill has a larger effect on

of the machine or the work

and feed rate proportionately, or set a lower depth of cut.

I190 : USA Stock : Stocked in Japan DC:Dia.
