CBN TURNING INSERTS [NEGATIVE]

80° CN TYPE INSERTS
WITH HOLE
NP-CNGA 4 3 1 GAWS2
Size Thickness Corner Radius Honing & Wiper
* Please refer to page B002.

Cutting Conditions : Stable Cutting General Cutting Unstable Cutting
H Hardened Materials
Work K Cast Iron
Material S Heat-resistant Alloy, Titanium Alloy
CBN Sintered Alloy
Cutting Coated Solid
CBN CBN CBN


Holder Page
Corner Edge
B


Applicable
Radius Effective
(ISO) Number


MBC020
Shape Order Number


MBS140
RE


MB8120
MB8130
MB8025
MB4120
MB4020
Length


MB8110
BC8105
BC8120
BC8130
BC8110


MB710
MB730
LE
CBN & PCD TURNING INSERTS


(inch) (inch)
NEW PETIT CUT NP-CNGA431-GAWS2 NP-CNGA120404GAWS2 .016 .075 a a a a
* (With Wiper) NP-CNGA432-GAWS2 NP-CNGA120408GAWS2 .031 .083 a a a a
NP-CNGA433-GAWS2 NP-CNGA120412GAWS2 .047 .091 a a a a
C006
NP-CNGA431-GSWS2 NP-CNGA120404GSWS2 .016 .075 a a ─ 009
E021
NP-CNGA432-GSWS2 NP-CNGA120408GSWS2 .031 .083 a a
E024
NP-CNGA433-GSWS2 NP-CNGA120412GSWS2 .047 .091 a a H006
─008
NP-CNGA431-GBWL2 NP-CNGA120404GBWL2 .016 .075 a a a a
NP-CNGA432-GBWL2 NP-CNGA120408GBWL2 .031 .083 a a a a
NEG NP-CNGA433-GBWL2 NP-CNGA120412GBWL2 .047 .091 a a a a

WITH
NEW PETIT CUT BF-CNGM431-TS2 BF-CNGM120404TS2 .016 .075 s
BF-CNGM432-TS2 BF-CNGM120408TS2 .031 .083 C006
HOLE s
─ 009
BF-CNGM433-TS2 BF-CNGM120412TS2 .047 .091 s E021
BF-CNGM431-TA2 BF-CNGM120404TA2 .016 .075 a E024
H006
BF-CNGM432-TA2 BF-CNGM120408TA2 .031 .083 a ─008
(With breaker) BF-CNGM433-TA2 BF-CNGM120412TA2 .047 .091 a
NEW PETIT CUT BM-CNGM431-TA2 BM-CNGM120404TA2 .016 .075 a
C006
BM-CNGM432-TA2 BM-CNGM120408TA2 .031 .083 a ─ 009
E021
BM-CNGM433-TA2 BM-CNGM120412TA2 .047 .091 a
E024
H006
─008
(With breaker)
CNGA432 CNGA120408 .031 .142 a aa
C006
CNGA433 CNGA120412 .047 .142 a aa ─ 009
E021
E024
H006
─008
CNGA432 CNGA120408 .031 .488 a
C006
CNGA433 CNGA120412 .047 .488 a ─ 009
E021
E024
H006
─008
=
* Please refer to page B018 before using the wiper insert.
a


a : USA Stock s : Stocked in Japan
B030 <1 insert in one case>
