DRILLING VP15TF Type DRILLING (SOLID CARBIDE) MHS Drill Diameter DC Stock Metric Decimal Fraction Wire / Thread L/D LUOrder NumberLCF LH OAL LF PL DCON (mm) Letter size (inch) mm inch mm inch mm inch mm inch mm inch mm inch mm inch 1 r MHS1110L040B 13.0 .512 41.8 1.646 42.3 1.665 102.3 4.028 100 3.937 2.3 .091 12 .472 3 6 r MHS1110L090B 68.6 2.701 91.5 3.602 92.0 3.622 152.0 5.984 150 5.906 2.0 .079 12 .472 4 8 r MHS1110L120B 90.8 3.575 121.5 4.783 122.0 4.803 182.0 7.165 180 7.087 2.0 .079 12 .472 4 11.100 .4370 11 r MHS1110L150B 124.1 4.886 151.5 5.965 152.0 5.984 212.0 8.346 210 8.268 2.0 .079 12 .472 4 15 r MHS1110L200B 168.5 6.634 201.5 7.933 202.0 7.953 262.0 10.315 260 10.236 2.0 .079 12 .472 4 20 r MHS1110L250B 224.0 8.819 251.5 9.902 252.0 9.921 312.0 12.283 310 12.205 2.0 .079 12 .472 4 24 r MHS1110L300B 268.4 10.567 301.5 11.870 302.0 11.890 362.0 14.252 360 14.173 2.0 .079 12 .472 4 1 r MHS1120L040B 13.1 .516 41.8 1.646 42.3 1.665 102.3 4.028 100 3.937 2.3 .091 12 .472 3 5 r MHS1120L090B 58.0 2.283 91.5 3.602 92.0 3.622 152.0 5.984 150 5.906 2.0 .079 12 .472 4 8 r MHS1120L120B 91.6 3.606 121.5 4.783 122.0 4.803 182.0 7.165 180 7.087 2.0 .079 12 .472 4 11.200 .4409 11 r MHS1120L150B 125.2 4.929 151.5 5.965 152.0 5.984 212.0 8.346 210 8.268 2.0 .079 12 .472 4 15 r MHS1120L200B 170.0 6.693 201.5 7.933 202.0 7.953 262.0 10.315 260 10.236 2.0 .079 12 .472 4 20 r MHS1120L250B 226.0 8.898 251.5 9.902 252.0 9.921 312.0 12.283 310 12.205 2.0 .079 12 .472 4 24 r MHS1120L300B 270.8 10.661 301.5 11.870 302.0 11.890 362 14.252 360 14.173 2.0 .079 12 .472 4 1 r MHS1130L040B 13.2 .520 41.8 1.646 42.3 1.665 102.3 4.028 100 3.937 2.3 .091 12 .472 3 5 r MHS1130L090B 58.6 2.307 91.6 3.606 92.1 3.626 152.1 5.988 150 5.906 2.1 .083 12 .472 4 8 r MHS1130L120B 92.5 3.642 121.6 4.787 122.1 4.807 182.1 7.169 180 7.087 2.1 .083 12 .472 4 11.300 .4449 11 r MHS1130L150B 126.4 4.976 151.6 5.969 152.1 5.988 212.1 8.350 210 8.268 2.1 .083 12 .472 4 15 r MHS1130L200B 171.6 6.756 201.6 7.937 202.1 7.957 262.1 10.319 260 10.236 2.1 .083 12 .472 4 20 r MHS1130L250B 228.1 8.980 251.6 9.906 252.1 9.925 312.1 12.287 310 12.205 2.1 .083 12 .472 4 24 r MHS1130L300B 273.3 10.760 301.6 11.874 302.1 11.894 362.1 14.256 360 14.173 2.1 .083 12 .472 4 1 r MHS1140L040B 13.4 .528 41.9 1.650 42.4 1.669 102.4 4.031 100 3.937 2.4 .094 12 .472 3 5 r MHS1140L090B 59.1 2.327 91.6 3.606 92.1 3.626 152.1 5.988 150 5.906 2.1 .083 12 .472 4 8 r MHS1140L120B 93.3 3.673 121.6 4.787 122.1 4.807 182.1 7.169 180 7.087 2.1 .083 12 .472 4 11.400 .4488 11 r MHS1140L150B 127.5 5.020 151.6 5.969 152.1 5.988 212.1 8.350 210 8.268 2.1 .083 12 .472 4 15 r MHS1140L200B 173.1 6.815 201.6 7.937 202.1 7.957 262.1 10.319 260 10.236 2.1 .083 12 .472 4 19 r MHS1140L250B 218.7 8.610 251.6 9.906 252.1 9.925 312.1 12.287 310 12.205 2.1 .083 12 .472 4 24 r MHS1140L300B 275.7 10.854 301.6 11.874 302.1 11.894 362.1 14.256 360 14.173 2.1 .083 12 .472 4 1 s MHS1150L040B 13.5 .531 41.9 1.650 42.4 1.669 102.4 4.031 100 3.937 2.4 .094 12 .472 3 5 s MHS1150L090B 59.6 2.346 91.6 3.606 92.1 3.626 152.1 5.988 150 5.906 2.1 .083 12 .472 4 8 s MHS1150L120B 94.1 3.705 121.6 4.787 122.1 4.807 182.1 7.169 180 7.087 2.1 .083 12 .472 4 11.500 .4528 10 s MHS1150L150B 117.1 4.610 151.6 5.969 152.1 5.988 212.1 8.350 210 8.268 2.1 .083 12 .472 4 15 s MHS1150L200B 174.6 6.874 201.6 7.937 202.1 7.957 262.1 10.319 260 10.236 2.1 .083 12 .472 4 19 s MHS1150L250B 220.6 8.685 251.6 9.906 252.1 9.925 312.1 12.287 310 12.205 2.1 .083 12 .472 4 24 s MHS1150L300B 278.1 10.949 301.6 11.874 302.1 11.894 362.1 14.256 360 14.173 2.1 .083 12 .472 4 1 r MHS1160L040B 13.6 .535 42.4 1.669 42.4 1.669 102.4 4.031 100 3.937 2.4 .094 12 .472 3 M 5 r MHS1160L090B 60.1 2.366 92.1 3.626 92.1 3.626 152.1 5.988 150 5.906 2.1 .083 12 .472 4 8 r MHS1160L120B 94.9 3.736 122.1 4.807 122.1 4.807 182.1 7.169 180 7.087 2.1 .083 12 .472 4 11.600 .4567 10 r MHS1160L150B 118.1 4.650 152.1 5.988 152.1 5.988 212.1 8.350 210 8.268 2.1 .083 12 .472 4 15 r MHS1160L200B 176.1 6.933 202.1 7.957 202.1 7.957 262.1 10.319 260 10.236 2.1 .083 12 .472 4 19 r MHS1160L250B 222.5 8.760 252.1 9.925 252.1 9.925 312.1 12.287 310 12.205 2.1 .083 12 .472 4 23 r MHS1160L300B 268.9 10.587 302.1 11.894 302.1 11.894 362.1 14.256 360 14.173 2.1 .083 12 .472 4 Note 1) Please contact Mitsubishi Materials for any geometry that is not in the catalog (e.g. different dia. and length). s : Stocked in Japan r : Made to Order M124
