DRILLING VP15TF Type DRILLING (SOLID CARBIDE) MHS Drill Diameter DC Stock Metric Decimal Fraction Wire / Thread L/D LUOrder NumberLCF LH OAL LF PL DCON (mm) Letter size (inch) mm inch mm inch mm inch mm inch mm inch mm inch mm inch 3 s MHS0210L012B 6.7 .264 12.4 .488 14.1 .555 60.4 2.378 60 2.362 0.4 .016 3 .118 1 7 s MHS0210L020B 15.1 .594 20.4 .803 22.1 .870 60.4 2.378 60 2.362 0.4 .016 3 .118 2 2.100 .0827 11 s MHS0210L030B 23.5 .925 30.4 1.197 32.1 1.264 80.4 3.165 80 3.150 0.4 .016 3 .118 2 23 s MHS0210L055B 48.7 1.917 55.4 2.181 57.1 2.248 100.4 3.953 100 3.937 0.4 .016 3 .118 2 30 s MHS0210L075B 63.4 2.496 75.4 2.969 77.1 3.035 120.4 4.740 120 4.724 0.4 .016 3 .118 2 2 s MHS0220L012B 4.8 .189 12.4 .488 13.9 .547 60.4 2.378 60 2.362 0.4 .016 3 .118 1 6 s MHS0220L020B 13.7 .539 20.5 .807 22.0 .866 60.5 2.382 60 2.362 0.5 .020 3 .118 2 2.200 .0866 11 s MHS0220L030B 24.7 .972 30.5 1.201 32.0 1.260 80.5 3.169 80 3.150 0.5 .020 3 .118 2 22 s MHS0220L055B 48.9 1.925 55.5 2.185 57.0 2.244 100.5 3.957 100 3.937 0.5 .020 3 .118 2 30 s MHS0220L075B 66.5 2.618 75.5 2.972 77.0 3.031 120.5 4.744 120 4.724 0.5 .020 3 .118 2 2 s MHS0230L012B 5.0 .197 12.4 .488 13.7 .539 60.4 2.378 60 2.362 0.4 .016 3 .118 1 6 s MHS0230L020B 14.3 .563 20.5 .807 21.8 .858 60.5 2.382 60 2.362 0.5 .020 3 .118 2 2.300 .0906 10 s MHS0230L030B 23.5 .925 30.5 1.201 31.8 1.252 80.5 3.169 80 3.150 0.5 .020 3 .118 2 21 s MHS0230L055B 48.8 1.921 55.5 2.185 56.8 2.236 100.5 3.957 100 3.937 0.5 .020 3 .118 2 30 s MHS0230L075B 69.5 2.736 75.5 2.972 76.8 3.024 120.5 4.744 120 4.724 0.5 .020 3 .118 2 2 s MHS0240L012B 5.2 .205 12.4 .488 13.5 .531 60.4 2.378 60 2.362 0.4 .016 3 .118 1 5 s MHS0240L020B 12.5 .492 20.5 .807 21.6 .850 60.5 2.382 60 2.362 0.5 .020 3 .118 2 2.400 .0945 9 s MHS0240L030B 22.1 .870 30.5 1.201 31.6 1.244 80.5 3.169 80 3.150 0.5 .020 3 .118 2 20 s MHS0240L055B 48.5 1.909 55.5 2.185 56.6 2.228 100.5 3.957 100 3.937 0.5 .020 3 .118 2 28 s MHS0240L075B 67.7 2.665 75.5 2.972 76.6 3.016 120.5 4.744 120 4.724 0.5 .020 3 .118 2 2 s MHS0245L013B 5.3 .209 13.5 .531 14.5 .571 70.5 2.776 70 2.756 0.5 .020 4 .157 1 5 s MHS0245L020B 12.8 .504 20.5 .807 21.5 .846 70.5 2.776 70 2.756 0.5 .020 4 .157 2 2.450 .0965 11 s MHS0245L035B 27.5 1.083 35.5 1.398 36.5 1.437 90.5 3.563 90 3.543 0.5 .020 4 .157 2 24 s MHS0245L065B 59.3 2.335 65.5 2.579 66.5 2.618 110.5 4.350 110 4.331 0.5 .020 4 .157 2 30 s MHS0245L090B 74.0 2.913 90.5 3.563 91.5 3.602 140.5 5.531 140 5.512 0.5 .020 4 .157 2 2 s MHS0250L013B 5.5 .217 13.5 .531 16.3 .642 70.5 2.776 70 2.756 0.5 .020 4 .157 1 5 s MHS0250L020B 13.0 .512 20.5 .807 23.3 .917 70.5 2.776 70 2.756 0.5 .020 4 .157 2 2.500 .0984 11 s MHS0250L035B 28.0 1.102 35.5 1.398 38.3 1.508 90.5 3.563 90 3.543 0.5 .020 4 .157 2 23 s MHS0250L065B 58.0 2.283 65.5 2.579 68.3 2.689 110.5 4.350 110 4.331 0.5 .020 4 .157 2 30 s MHS0250L090B 75.5 2.972 90.5 3.563 93.3 3.673 140.5 5.531 140 5.512 0.5 .020 4 .157 2 2 s MHS0260L013B 5.7 .224 13.5 .531 16.1 .634 70.5 2.776 70 2.756 0.5 .020 4 .157 1 5 s MHS0260L020B 13.5 .531 20.5 .807 23.1 .909 70.5 2.776 70 2.756 0.5 .020 4 .157 2 2.600 .1024 10 s MHS0260L035B 26.5 1.043 35.5 1.398 38.1 1.500 90.5 3.563 90 3.543 0.5 .020 4 .157 2 22 s MHS0260L065B 57.7 2.272 65.5 2.579 68.1 2.681 110.5 4.350 110 4.331 0.5 .020 4 .157 2 30 s MHS0260L090B 78.5 3.091 90.5 3.563 93.1 3.665 140.5 5.531 140 5.512 0.5 .020 4 .157 2 2 s MHS0270L013B 5.9 .232 13.5 .531 15.9 .626 70.5 2.776 70 2.756 0.5 .020 4 .157 1 M 4 s MHS0270L020B 11.4 .449 20.6 .811 23.0 .906 70.6 2.780 70 2.756 0.6 .024 4 .157 2 2.700 .1063 36 #6-32 10 s MHS0270L035B 27.6 1.087 35.6 1.402 38.0 1.496 90.6 3.567 90 3.543 0.6 .024 4 .157 2 21 s MHS0270L065B 57.3 2.256 65.6 2.583 68.0 2.677 110.6 4.354 110 4.331 0.6 .024 4 .157 2 30 s MHS0270L090B 81.6 3.213 90.6 3.567 93.0 3.661 140.6 5.535 140 5.512 0.6 .024 4 .157 2 2 s MHS0280L014B 6.1 .240 14.5 .571 16.7 .657 70.5 2.776 70 2.756 0.5 .020 4 .157 1 4 s MHS0280L020B 11.8 .465 20.6 .811 22.8 .898 70.6 2.780 70 2.756 0.6 .024 4 .157 2 2.800 .1102 35 9 s MHS0280L035B 25.8 1.016 35.6 1.402 37.8 1.488 90.6 3.567 90 3.543 0.6 .024 4 .157 2 20 s MHS0280L065B 56.6 2.228 65.6 2.583 67.8 2.669 110.6 4.354 110 4.331 0.6 .024 4 .157 2 29 s MHS0280L090B 81.8 3.220 90.6 3.567 92.8 3.654 140.6 5.535 140 5.512 0.6 .024 4 .157 2 Note 1) Please contact Mitsubishi Materials for any geometry that is not in the catalog (e.g. different dia. and length). s : Stocked in Japan r : Made to Order M112
