VP15TF Type DRILLING Drill Diameter DC Stock Metric Decimal Fraction Wire / Thread L/D LUOrder NumberLCF LH OAL LF PL DCON (mm) Letter size (inch) mm inch mm inch mm inch mm inch mm inch mm inch mm inch 2 s MHS0140L007B 3.1 .122 7.3 .287 10.3 .406 60.3 2.374 60 2.362 0.3 .012 3 .118 1 5 s MHS0140L011B 7.3 .287 11.3 .445 14.3 .563 60.3 2.374 60 2.362 0.3 .012 3 .118 2 1.400 .0551 11 s MHS0140L020B 15.7 .618 20.3 .799 23.3 .917 60.3 2.374 60 2.362 0.3 .012 3 .118 2 18 s MHS0140L030B 25.5 1.004 30.3 1.193 33.3 1.311 80.3 3.161 80 3.150 0.3 .012 3 .118 2 29 s MHS0140L045B 40.9 1.610 45.3 1.783 48.3 1.902 80.3 3.161 80 3.150 0.3 .012 3 .118 2 3 s MHS0145L008B 4.7 .185 8.3 .327 11.2 .441 60.3 2.374 60 2.362 0.3 .012 3 .118 1 6 s MHS0145L013B 9.0 .354 13.3 .524 16.2 .638 60.3 2.374 60 2.362 0.3 .012 3 .118 2 1.450 .0571 11 s MHS0145L020B 16.3 .642 20.3 .799 23.2 .913 60.3 2.374 60 2.362 0.3 .012 3 .118 2 21 s MHS0145L035B 30.8 1.213 35.3 1.390 38.2 1.504 80.3 3.161 80 3.150 0.3 .012 3 .118 2 30 s MHS0145L055B 43.8 1.724 55.3 2.177 58.2 2.291 100.3 3.949 100 3.937 0.3 .012 3 .118 2 2 s MHS0150L008B 3.3 .130 8.3 .327 11.1 .437 60.3 2.374 60 2.362 0.3 .012 3 .118 1 6 s MHS0150L013B 9.3 .366 13.3 .524 16.1 .634 60.3 2.374 60 2.362 0.3 .012 3 .118 2 1.500 .0591 #1-64 10 s MHS0150L020B 15.3 .602 20.3 .799 23.1 .909 60.3 2.374 60 2.362 0.3 .012 3 .118 2 20 s MHS0150L035B 30.3 1.193 35.3 1.390 38.1 1.500 80.3 3.161 80 3.150 0.3 .012 3 .118 2 30 s MHS0150L055B 45.3 1.783 55.3 2.177 58.1 2.287 100.3 3.949 100 3.937 0.3 .012 3 .118 2 2 s MHS0160L008B 3.5 .138 8.3 .327 10.9 .429 60.3 2.374 60 2.362 0.3 .012 3 .118 1 5 s MHS0160L013B 8.3 .327 13.3 .524 15.9 .626 60.3 2.374 60 2.362 0.3 .012 3 .118 2 1.600 .0630 10 s MHS0160L020B 16.3 .642 20.3 .799 22.9 .902 60.3 2.374 60 2.362 0.3 .012 3 .118 2 19 s MHS0160L035B 30.7 1.209 35.3 1.390 37.9 1.492 80.3 3.161 80 3.150 0.3 .012 3 .118 2 30 s MHS0160L055B 48.3 1.902 55.3 2.177 57.9 2.280 100.3 3.949 100 3.937 0.3 .012 3 .118 2 2 s MHS0170L008B 3.7 .146 8.3 .327 10.7 .421 60.3 2.374 60 2.362 0.3 .012 3 .118 1 5 s MHS0170L013B 8.9 .350 13.4 .528 15.8 .622 60.4 2.378 60 2.362 0.4 .016 3 .118 2 1.700 .0669 9 s MHS0170L020B 15.7 .618 20.4 .803 22.8 .898 60.4 2.378 60 2.362 0.4 .016 3 .118 2 18 s MHS0170L035B 31.0 1.220 35.4 1.394 37.8 1.488 80.4 3.165 80 3.150 0.4 .016 3 .118 2 29 s MHS0170L055B 49.7 1.957 55.4 2.181 57.8 2.276 100.4 3.953 100 3.937 0.4 .016 3 .118 2 3 s MHS0180L010B 5.7 .224 10.3 .406 12.5 .492 60.3 2.374 60 2.362 0.3 .012 3 .118 1 5 s MHS0180L015B 9.4 .370 15.4 .606 17.6 .693 60.4 2.378 60 2.362 0.4 .016 3 .118 2 1.800 .0709 11 s MHS0180L025B 20.2 .795 25.4 1.000 27.6 1.087 60.4 2.378 60 2.362 0.4 .016 3 .118 2 22 s MHS0180L045B 40.0 1.575 45.4 1.787 47.6 1.874 80.4 3.165 80 3.150 0.4 .016 3 .118 2 30 s MHS0180L065B 54.4 2.142 65.4 2.575 67.6 2.661 100.4 3.953 100 3.937 0.4 .016 3 .118 2 2 s MHS0190L010B 4.1 .161 10.4 .409 12.5 .492 60.4 2.378 60 2.362 0.4 .016 3 .118 1 5 s MHS0190L015B 9.9 .390 15.4 .606 17.5 .689 60.4 2.378 60 2.362 0.4 .016 3 .118 2 1.900 .0748 10 s MHS0190L025B 19.4 .764 25.4 1.000 27.5 1.083 60.4 2.378 60 2.362 0.4 .016 3 .118 2 21 s MHS0190L045B 40.3 1.587 45.4 1.787 47.5 1.870 80.4 3.165 80 3.150 0.4 .016 3 .118 2 30 s MHS0190L065B 57.4 2.260 65.4 2.575 67.5 2.657 100.4 3.953 100 3.937 0.4 .016 3 .118 2 2 s MHS0195L010B 4.3 .169 10.4 .409 12.4 .488 60.4 2.378 60 2.362 0.4 .016 3 .118 1 5 s MHS0195L015B 10.2 .402 15.4 .606 17.4 .685 60.4 2.378 60 2.362 0.4 .016 3 .118 2 M 1.950 .0768 10 s MHS0195L025B 19.9 .783 25.4 1.000 27.4 1.079 60.4 2.378 60 2.362 0.4 .016 3 .118 2 20 s MHS0195L045B 39.4 1.551 45.4 1.787 47.4 1.866 80.4 3.165 80 3.150 0.4 .016 3 .118 2 30 s MHS0195L065B 58.9 2.319 65.4 2.575 67.4 2.654 100.4 3.953 100 3.937 0.4 .016 3 .118 2 2 s MHS0200L010B 4.4 .173 10.4 .409 12.3 .484 60.4 2.378 60 2.362 0.4 .016 3 .118 1 5 s MHS0200L015B 10.4 .409 15.4 .606 17.3 .681 60.4 2.378 60 2.362 0.4 .016 3 .118 2 2.000 .0787 #3-48 9 s MHS0200L025B 18.4 .724 25.4 1.000 27.3 1.075 60.4 2.378 60 2.362 0.4 .016 3 .118 2 20 s MHS0200L045B 40.4 1.591 45.4 1.787 47.3 1.862 80.4 3.165 80 3.150 0.4 .016 3 .118 2 30 s MHS0200L065B 60.4 2.378 65.4 2.575 67.3 2.650 100.4 3.953 100 3.937 0.4 .016 3 .118 2 CUTTING CONDITIONS M126 OPERATIONAL GUIDANCE M127 TECHNICAL DATA P001 M111
