DRILLING (SOLID CARBIDE) MICRO-MWS DC Stock Dimensions Type VP15TF Metric Decimal Fraction Wire / Thread L/D Order Number LU LCF LH OAL LF PL DCON (mm) Letter size (inch) mm inch mm inch mm inch mm inch mm inch mm inch mm inch 1 [ MWS00520SB 1.6 .063 6.6 .260 10.1 .398 55.2 2.173 55 2.165 0.2 .008 3.175 .125 1 1.321 .0520 55 12 [ MWS00520XB 16.1 .634 23.3 .917 26.8 1.055 55.3 2.177 55 2.165 0.3 .012 3.175 .125 3 1 [ MWS0135SB 1.7 .067 6.9 .272 10.0 .394 55.3 2.177 55 2.165 0.3 .012 3.0 .118 1 20 [ MWS0135X20DB 27.3 1.075 31.3 1.232 34.3 1.350 68.3 2.689 68 2.677 0.3 .012 3.0 .118 3 1.350 .0531 25 [ MWS0135X25DB 34.1 1.343 38.3 1.508 41.3 1.626 74.3 2.925 74 2.913 0.3 .012 3.0 .118 3 30 [ MWS0135X30DB 40.8 1.606 45.3 1.783 48.3 1.902 82.3 3.240 82 3.228 0.3 .012 3.0 .118 3 1 [ MWS00550SB 1.7 .067 7.3 .287 10.6 .417 55.3 2.177 55 2.165 0.3 .012 3.175 .125 1 1.397 .0550 54 12 [ MWS00550XB 17.1 .673 23.3 .917 26.6 1.047 55.3 2.177 55 2.165 0.3 .012 3.175 .125 3 1 [ MWS0140SB 1.7 .067 7.3 .287 10.3 .406 55.3 2.177 55 2.165 0.3 .012 3.0 .118 1 5 [ MWS0140LB 7.3 .287 17.3 .681 20.3 .799 55.3 2.177 55 2.165 0.3 .012 3.0 .118 3 12 [ MWS0140XB 17.1 .673 23.3 .917 26.3 1.035 55.3 2.177 55 2.165 0.3 .012 3.0 .118 3 1.400 .0551 20 [ MWS0140X20DB 28.3 1.114 32.3 1.272 35.3 1.390 68.3 2.689 68 2.677 0.3 .012 3.0 .118 3 25 [ MWS0140X25DB 35.3 1.390 39.3 1.547 42.3 1.665 74.3 2.925 74 2.913 0.3 .012 3.0 .118 3 30 [ MWS0140X30DB 42.3 1.665 46.3 1.823 49.3 1.941 82.3 3.240 82 3.228 0.3 .012 3.0 .118 3 1 [ MWS0145SB 1.8 .071 7.5 .295 10.4 .409 55.3 2.177 55 2.165 0.3 .012 3.0 .118 1 20 [ MWS0145X20DB 29.3 1.154 33.3 1.311 36.3 1.429 68.3 2.689 68 2.677 0.3 .012 3.0 .118 3 1.450 .0571 25 [ MWS0145X25DB 36.6 1.441 41.3 1.626 43.3 1.705 74.3 2.925 74 2.913 0.3 .012 3.0 .118 3 30 [ MWS0145X30DB 43.8 1.724 48.3 1.902 51.3 2.020 82.3 3.240 82 3.228 0.3 .012 3.0 .118 3 1 [ MWS0150SB 1.8 .071 7.7 .303 10.5 .413 55.3 2.177 55 2.165 0.3 .012 3.0 .118 1 5 [ MWS0150LB 7.8 .307 17.3 .681 20.3 .799 55.3 2.177 55 2.165 0.3 .012 3.0 .118 3 12 [ MWS0150XB 18.3 .720 23.3 .917 26.3 1.035 55.3 2.177 55 2.165 0.3 .012 3.0 .118 3 1.500 .0591 #1-64 20 [ MWS0150X20DB 30.3 1.193 35.3 1.390 37.3 1.469 68.3 2.689 68 2.677 0.3 .012 3.0 .118 3 25 [ MWS0150X25DB 37.8 1.488 42.3 1.665 45.3 1.783 74.3 2.925 74 2.913 0.3 .012 3.0 .118 3 30 [ MWS0150X30DB 45.3 1.783 50.3 1.980 52.3 2.059 82.3 3.240 82 3.228 0.3 .012 3.0 .118 3 1 [ MWS00591SB 1.8 .071 7.7 .303 10.8 .425 55.3 2.177 55 2.165 0.3 .012 3.175 .125 1 1.502 .0591 #1-64 12 [ MWS00591XB 18.3 .720 23.3 .917 26.4 1.039 55.3 2.177 55 2.165 0.3 .012 3.175 .125 3 1 [ MWS0155SB 1.9 .075 7.9 .311 10.6 .417 68.3 2.689 68 2.677 0.3 .012 3.0 .118 1 20 [ MWS0155X20DB 31.3 1.232 36.3 1.429 38.3 1.508 78.3 3.083 78 3.071 0.3 .012 3.0 .118 3 1.550 .0610 25 [ MWS0155X25DB 39.1 1.539 43.3 1.705 46.3 1.823 86.3 3.398 86 3.386 0.3 .012 3.0 .118 3 30 [ MWS0155X30DB 46.8 1.843 51.3 2.020 54.3 2.138 95.3 3.752 95 3.740 0.3 .012 3.0 .118 3 1 [ MWS00625SB 1.9 .075 8.3 .327 11.3 .445 68.3 2.689 68 2.677 0.3 .012 3.175 .125 1 1.588 .0625 1/16 12 [ MWS00625XB 19.4 .764 30.3 1.193 33.3 1.311 68.3 2.689 68 2.677 0.3 .012 3.175 .125 3 1 [ MWS0160SB 1.9 .075 8.3 .327 10.9 .429 68.3 2.689 68 2.677 0.3 .012 3.0 .118 1 5 [ MWS0160LB 8.3 .327 22.3 .878 25.3 .996 68.3 2.689 68 2.677 0.3 .012 3.0 .118 3 12 [ MWS0160XB 19.5 .768 30.3 1.193 33.3 1.311 68.3 2.689 68 2.677 0.3 .012 3.0 .118 3 1.600 .0630 20 [ MWS0160X20DB 32.3 1.272 37.3 1.469 39.3 1.547 78.3 3.083 78 3.071 0.3 .012 3.0 .118 3 M 25 [ MWS0160X25DB 40.3 1.587 45.3 1.783 47.3 1.862 86.3 3.398 86 3.386 0.3 .012 3.0 .118 3 30 [ MWS0160X30DB 48.3 1.902 53.3 2.098 55.3 2.177 95.3 3.752 95 3.740 0.3 .012 3.0 .118 3 1 MWS00635SB 1.9 .075 8.3 .327 11.2 .441 68.3 2.689 68 2.677 0.3 .012 3.175 .125 1 DRILLING [ 1.613 .0635 52 12 [ MWS00635XB 19.7 .776 30.3 1.193 33.2 1.307 68.3 2.689 68 2.677 0.3 .012 3.175 .125 3 1 [ MWS0165SB 2.0 .079 8.5 .335 11.0 .433 68.3 2.689 68 2.677 0.3 .012 3.0 .118 1 20 [ MWS0165X20DB 33.3 1.311 38.3 1.508 40.3 1.587 78.3 3.083 78 3.071 0.3 .012 3.0 .118 3 1.650 .0650 25 [ MWS0165X25DB 41.6 1.638 46.3 1.823 49.3 1.941 86.3 3.398 86 3.386 0.3 .012 3.0 .118 3 30 [ MWS0165X30DB 49.8 1.961 54.3 2.138 57.3 2.256 95.3 3.752 95 3.740 0.3 .012 3.0 .118 3 Note 1) Please contact Mitsubishi Materials for any geometry that is not in the catalog (e.g. different dia. and length). [ : Micro-MWS inch & metric sizes 1.0mm - 2.95mm being phased out through 2022. M088 See new generation Micro-MVS drills for applicable replacement.
