VP15TF Type DRILLING DC Stock Dimensions Metric Decimal Fraction Wire / Thread L/D Order Number LU LCF LH OAL LF PL DCON (mm) Letter size (inch) mm inch mm inch mm inch mm inch mm inch mm inch mm inch 1 a MWS0078SB 0.9 .035 4.04 .159 8.14 .320 50.14 1.974 50 1.969 0.14 .006 3.0 .118 1 0.780 .0307 5 s MWS0078LB 4.1 .161 10.16 .400 14.16 .557 50.16 1.975 50 1.969 0.16 .006 3.0 .118 3 12 a MWS0078XB 9.5 .374 20.16 .794 24.16 .951 50.16 1.975 50 1.969 0.16 .006 3.0 .118 3 1 a MWS00310SB 0.9 .035 4.04 .159 8.54 .336 50.14 1.974 50 1.969 0.14 .006 3.175 .125 1 0.788 .0310 68 5 a MWS00310LB 4.1 .161 10.16 .400 14.66 .577 50.16 1.975 50 1.969 0.16 .006 3.175 .125 3 12 a MWS00310XB 9.6 .378 20.16 .794 24.66 .971 50.16 1.975 50 1.969 0.16 .006 3.175 .125 3 1 s MWS0079SB 0.9 .035 4.04 .159 8.14 .320 50.14 1.974 50 1.969 0.14 .006 3.0 .118 1 0.790 .0311 5 s MWS0079LB 4.1 .161 10.16 .400 14.16 .557 50.16 1.975 50 1.969 0.16 .006 3.0 .118 3 12 s MWS0079XB 9.6 .378 20.16 .794 24.16 .951 50.16 1.975 50 1.969 0.16 .006 3.0 .118 3 1 a MWS00312SB 0.9 .035 4.04 .159 8.44 .332 50.14 1.974 50 1.969 0.14 .006 3.175 .125 1 0.794 .0313 1/32 5 a MWS00312LB 4.1 .161 10.16 .400 14.56 .573 50.16 1.975 50 1.969 0.16 .006 3.175 .125 3 12 a MWS00312XB 9.7 .382 20.16 .794 24.56 .967 50.16 1.975 50 1.969 0.16 .006 3.175 .125 3 1 a MWS0080SB 1.0 .039 4.05 .159 8.15 .321 50.15 1.974 50 1.969 0.15 .006 3.0 .118 1 0.800 .0315 5 a MWS0080LB 4.2 .165 10.17 .400 14.17 .558 50.17 1.975 50 1.969 0.17 .007 3.0 .118 3 12 a MWS0080XB 9.8 .386 20.17 .794 24.17 .952 50.17 1.975 50 1.969 0.17 .007 3.0 .118 3 1 s MWS0081SB 1.0 .039 4.25 .167 8.35 .329 50.15 1.974 50 1.969 0.15 .006 3.0 .118 1 0.810 .0319 5 s MWS0081LB 4.2 .165 10.17 .400 14.17 .558 50.17 1.975 50 1.969 0.17 .007 3.0 .118 3 12 s MWS0081XB 9.9 .390 20.17 .794 24.17 .952 50.17 1.975 50 1.969 0.17 .007 3.0 .118 3 1 a MWS00320SB 1.0 .039 4.25 .167 8.65 .341 50.15 1.974 50 1.969 0.15 .006 3.175 .125 1 0.813 .0320 67 5 a MWS00320LB 4.2 .165 10.17 .400 14.57 .574 50.17 1.975 50 1.969 0.17 .007 3.175 .125 3 12 a MWS00320XB 9.9 .390 20.17 .794 24.57 .967 50.17 1.975 50 1.969 0.17 .007 3.175 .125 3 1 a MWS0082SB 1.0 .039 4.25 .167 8.35 .329 50.15 1.974 50 1.969 0.15 .006 3.0 .118 1 0.820 .0323 5 a MWS0082LB 4.3 .169 10.17 .400 14.17 .558 50.17 1.975 50 1.969 0.17 .007 3.0. .118 3 12 s MWS0082XB 10.0 .394 20.17 .794 24.17 .952 50.17 1.975 50 1.969 0.17 .007 3.0 .118 3 1 a MWS0083SB 1.0 .039 4.25 .167 8.25 .325 50.15 1.974 50 1.969 0.15 .006 3.0 .118 1 0.830 .0327 5 a MWS0083LB 4.3 .169 10.17 .400 14.17 .558 50.17 1.975 50 1.969 0.17 .007 3.0 .118 3 12 s MWS0083XB 10.1 .398 20.17 .794 24.17 .952 50.17 1.975 50 1.969 0.17 .007 3.0 .118 3 1 a MWS00330SB 1.0 .039 4.25 .167 8.65 .341 50.15 1.974 50 1.969 0.15 .006 3.175 .125 1 0.839 .0330 66 5 a MWS00330LB 4.4 .173 10.17 .400 14.57 .574 50.17 1.975 50 1.969 0.17 .007 3.175 .125 3 12 a MWS00330XB 10.2 .402 20.17 .794 24.57 .967 50.17 1.975 50 1.969 0.17 .007 3.175 .125 3 1 s MWS0084SB 1.0 .039 4.25 .167 8.25 .325 50.15 1.974 50 1.969 0.15 .006 3.0 .118 1 0.840 .0331 5 s MWS0084LB 4.4 .173 10.17 .400 14.17 .558 50.17 1.975 50 1.969 0.17 .007 3.0 .118 3 12 s MWS0084XB 10.3 .406 20.17 .794 24.17 .952 50.17 1.975 50 1.969 0.17 .007 3.0 .118 3 1 a MWS0085SB 1.0 .039 4.25 .167 8.25 .325 50.15 1.974 50 1.969 0.15 .006 3.0 .118 1 0.850 .0335 5 a MWS0085LB 4.4 .173 10.18 .401 14.18 .558 50.18 1.976 50 1.969 0.18 .007 3.0 .118 3 12 s MWS0085XB 10.4 .409 20.18 .794 24.18 .952 50.18 1.976 50 1.969 0.18 .007 3.0 .118 3 1 a MWS0086SB 1.0 .039 4.56 .180 8.56 .337 50.16 1.975 50 1.969 0.16 .006 3.0 .118 1 M 0.860 .0339 5 s MWS0086LB 4.5 .177 10.18 .401 14.18 .558 50.18 1.976 50 1.969 0.18 .007 3.0 .118 3 12 s MWS0086XB 10.5 .413 20.18 .794 24.18 .952 50.18 1.976 50 1.969 0.18 .007 3.0 .118 3 1 s MWS0087SB 1.0 .039 4.56 .180 8.56 .337 50.16 1.975 50 1.969 0.16 .006 3.0 .118 1 0.870 .0343 5 s MWS0087LB 4.5 .177 10.18 .401 14.18 .558 50.18 1.976 50 1.969 0.18 .007 3.0 .118 3 12 s MWS0087XB 10.6 .417 20.18 .794 24.18 .952 50.18 1.976 50 1.969 0.18 .007 3.0 .118 3 1 s MWS0088SB 1.0 .039 4.56 .180 8.56 .337 50.16 1.975 50 1.969 0.16 .006 3.0 .118 1 0.880 .0346 5 s MWS0088LB 4.6 .181 10.18 .401 14.18 .558 50.18 1.976 50 1.969 0.18 .007 3.0 .118 3 12 s MWS0088XB 10.7 .421 20.18 .794 24.18 .952 50.18 1.976 50 1.969 0.18 .007 3.0 .118 3 1 a MWS00350SB 1.1 .043 4.56 .180 8.86 .349 50.16 1.975 50 1.969 0.16 .006 3.175 .125 1 0.889 .0350 65 5 a MWS00350LB 4.6 .181 10.18 .401 14.48 .570 50.18 1.976 50 1.969 0.18 .007 3.175 .125 3 12 a MWS00350XB 10.9 .429 20.18 .794 24.48 .964 50.18 1.976 50 1.969 0.18 .007 3.175 .125 3 CUTTING CONDITIONS M093 OPERATIONAL GUIDANCE M096 TECHNICAL DATA P001 M085
