VP15TF Type DRILLING DC Stock Dimensions Metric Decimal Fraction Wire / Thread L/D Order Number LU LCF LH OAL LF PL DCON (mm) Letter size (inch) mm inch mm inch mm inch mm inch mm inch mm inch mm inch 1 s MWS0053SB 0.6 .024 2.70 .106 7.30 .287 47.1 1.854 47 1.850 0.10 .004 3.0 .118 1 0.530 .0209 5 s MWS0053LB 2.8 .110 8.11 .319 13.11 .516 47.11 1.855 47 1.850 0.11 .004 3.0 .118 3 12 s MWS0053XB 6.5 .256 16.11 .634 21.11 .831 47.11 1.855 47 1.850 0.11 .004 3.0 .118 3 1 a MWS00210SB 0.6 .024 2.70 .106 7.60 .299 45.1 1.776 45 1.772 0.10 .004 3.175 .125 1 0.534 .0210 75 5 a MWS00210LB 2.8 .110 8.11 .319 13.01 .512 47.11 1.855 47 1.850 0.11 .004 3.175 .125 3 12 a MWS00210XB 6.5 .256 16.11 .634 21.01 .827 47.11 1.855 47 1.850 0.11 .004 3.175 .125 3 1 s MWS0054SB 0.6 .024 2.70 .106 7.30 .287 47.1 1.854 47 1.850 0.10 .004 3.0 .118 1 0.540 .0213 5 s MWS0054LB 2.8 .110 8.11 .319 13.11 .516 47.11 1.855 47 1.850 0.11 .004 3.0 .118 3 12 s MWS0054XB 6.6 .260 16.11 .634 21.11 .831 47.11 1.855 47 1.850 0.11 .004 3.0 .118 3 1 a MWS0055SB 0.7 .028 2.70 .106 7.30 .287 47.10 1.854 47 1.850 0.10 .004 3.0 .118 1 0.550 .0217 5 s MWS0055LB 2.9 .114 8.11 .319 13.11 .516 47.11 1.855 47 1.850 0.11 .004 3.0 .118 3 12 a MWS0055XB 6.7 .264 16.11 .634 21.11 .831 47.11 1.855 47 1.850 0.11 .004 3.0 .118 3 1 a MWS0056SB 0.7 .028 3.00 .118 7.60 .299 47.10 1.854 47 1.850 0.10 .004 3.0 .118 1 0.560 .0220 5 s MWS0056LB 2.9 .114 8.12 .320 13.12 .517 47.12 1.855 47 1.850 0.12 .005 3.0 .118 3 12 a MWS0056XB 6.8 .268 16.12 .635 21.12 .831 47.12 1.855 47 1.850 0.12 .005 3.0 .118 3 1 a MWS0057SB 0.7 .028 3.00 .118 7.50 .295 47.10 1.854 47 1.850 0.10 .004 3.0 .118 1 0.570 .0224 5 s MWS0057LB 3.0 .118 8.12 .320 13.12 .517 47.12 1.855 47 1.850 0.12 .005 3.0 .118 3 12 a MWS0057XB 7.0 .276 16.12 .635 21.12 .831 47.12 1.855 47 1.850 0.12 .005 3.0 .118 3 1 a MWS00225SB 0.7 .028 3.00 .118 7.90 .311 45.10 1.776 45 1.772 0.10 .004 3.175 .125 1 0.572 .0225 74 5 a MWS00225LB 3.0 .118 8.12 .320 13.02 .513 47.12 1.855 47 1.850 0.12 .005 3.175 .125 3 12 a MWS00225XB 7.0 .276 16.12 .635 21.02 .828 47.12 1.855 47 1.850 0.12 .005 3.175 .125 3 1 s MWS0058SB 0.7 .028 3.01 .119 7.51 .296 47.11 1.855 47 1.850 0.11 .004 3.0 .118 1 0.580 .0228 5 s MWS0058LB 3.0 .118 8.12 .320 13.12 .517 47.12 1.855 47 1.850 0.12 .005 3.0 .118 3 12 s MWS0058XB 7.1 .280 16.12 .635 21.12 .831 47.12 1.855 47 1.850 0.12 .005 3.0 .118 3 1 s MWS0059SB 0.7 .028 3.01 .119 7.51 .296 47.11 1.855 47 1.850 0.11 .004 3.0 .118 1 0.590 .0232 5 s MWS0059LB 3.1 .122 8.12 .320 12.12 .477 47.12 1.855 47 1.850 0.12 .005 3.0 .118 3 12 s MWS0059XB 7.2 .283 16.12 .635 20.12 .792 47.12 1.855 47 1.850 0.12 .005 3.0 .118 3 1 a MWS0060SB 0.7 .028 3.01 .119 7.51 .296 47.11 1.855 47 1.850 0.11 .004 3.0 .118 1 0.600 .0236 5 s MWS0060LB 3.1 .122 8.12 .320 12.12 .477 47.12 1.855 47 1.850 0.12 .005 3.0 .118 3 12 a MWS0060XB 7.3 .287 16.12 .635 20.12 .792 47.12 1.855 47 1.850 0.12 .005 3.0 .118 3 1 a MWS00240SB 0.7 .028 3.21 .126 8.01 .315 45.11 1.776 45 1.772 0.11 .004 3.175 .125 1 1 s MWS0061SB 0.7 .028 3.21 .126 7.71 .304 47.11 1.855 47 1.850 0.11 .004 3.0 .118 3 0.610 .0240 73 5 a MWS00240LB 3.2 .126 8.13 .320 12.93 .509 47.13 1.856 47 1.850 0.13 .005 3.175 .125 35sMWS0061LB3.2.1268.13 .320 12.13 .478 47.13 1.856471.850 0.13 .005 3.0.1183 12 a MWS00240XB 7.4 .291 16.13 .635 20.93 .824 47.13 1.856 47 1.850 0.13 .005 3.175 .125 3 12 s MWS0061XB 7.5 .295 16.13 .635 20.13 .793 47.13 1.856 47 1.850 0.13 .005 3.0 .118 3 0.620 .0244 1 s MWS0062SB 0.7 .028 3.21 .126 7.61 .300 47.11 1.855 47 1.850 0.11 .004 3.0 .118 15sMWS0062LB3.2.1268.13 .320 12.13 .478 47.13 1.856471.850 0.13 .005 3.0.1183M 12 s MWS0062XB 7.6 .299 16.13 .635 20.13 .793 47.13 1.856 47 1.850 0.13 .005 3.0 .118 3 1 s MWS0063SB 0.7 .028 3.21 .126 7.61 .300 47.11 1.855 47 1.850 0.11 .004 3.0 .118 1 0.630 .0248 5 s MWS0063LB 3.3 .130 8.13 .320 12.13 .478 47.13 1.856 47 1.850 0.13 .005 3.0 .118 3 12 s MWS0063XB 7.7 .303 16.13 .635 20.13 .793 47.13 1.856 47 1.850 0.13 .005 3.0 .118 3 1 a MWS00250SB 0.8 .031 3.22 .127 7.92 .312 45.12 1.776 45 1.772 0.12 .005 3.175 .125 1 0.635 .0250 72 5 a MWS00250LB 3.3 .130 8.13 .320 12.83 .505 47.13 1.856 47 1.850 0.13 .005 3.175 .125 3 12 a MWS00250XB 7.8 .307 16.13 .635 20.83 .820 47.13 1.856 47 1.850 0.13 .005 3.175 .125 3 1 s MWS0064SB 0.8 .031 3.22 .127 7.62 .300 47.12 1.855 47 1.850 0.12 .005 3.0 .118 1 0.640 .0252 5 s MWS0064LB 3.3 .130 8.13 .320 12.13 .478 47.13 1.856 47 1.850 0.13 .005 3.0 .118 3 12 s MWS0064XB 7.8 .307 16.13 .635 20.13 .793 47.13 1.856 47 1.850 0.13 .005 3.0 .118 3 CUTTING CONDITIONS M093 OPERATIONAL GUIDANCE M096 TECHNICAL DATA P001 M083
