Coolant (Int./Ext.) DP1020 Type DRILLING DC Stock Metric Decimal Fraction Wire / Thread L/D Order Number LU LCF LH OAL LF PL DCON (mm) Letter Size (inch) mm inch mm inch mm inch mm inch mm inch mm inch mm inch 2 Ext. s MVE1250X02S130 27.3 1.075 53.3 2.098 56.3 2.217 104.3 4.106 102 4.016 2.3 .091 13 .512 2 2 Ext. a MVE1250X02S140 27.3 1.075 53.3 2.098 56.3 2.217 104.3 4.106 102 4.016 2.3 .091 14 .551 2 2 Int. s MVS1250X02S130PL 27.0 1.063 53.0 2.087 56.0 2.205 104.0 4.094 102 4.016 2.0 .079 13 .512 4 2 Int. a MVS1250X02S140PL 27.0 1.063 53.0 2.087 56.0 2.205 104.0 4.094 102 4.016 2.0 .079 14 .551 4 3 Ext. s MVE1250X03S130 39.8 1.567 78.3 3.083 81.3 3.201 139.3 5.484 137 5.394 2.3 .091 13 .512 2 3 Ext. r MVE1250X03S140 39.8 1.567 78.3 3.083 81.3 3.201 139.3 5.484 137 5.394 2.3 .091 14 .551 2 3 Int. s MVS1250X03S130 39.8 1.567 64.8 2.551 67.3 2.650 130.3 5.130 128 5.039 2.3 .091 13 .512 6 3 Int. a MVS1250X03S140 39.8 1.567 64.8 2.551 67.3 2.650 130.3 5.130 128 5.039 2.3 .091 14 .551 6 12.500 .4921 M14x4.5 5 Int.5Int. sa MVS1250X05S130MVS1250X05S14064.82.551 102.34.028 106.34.185 169.36.665167 6.575 2.3 .091 13 .512 664.82.551 102.34.028 106.34.185 169.36.6651676.5752.3.09114.5516 8 Int. s MVS1250X08S130 102.3 4.028 140.3 5.524 145.3 5.720 208.3 8.201 206 8.110 2.3 .091 13 .512 6 8 Int. a MVS1250X08S140 102.3 4.028 140.3 5.524 145.3 5.720 208.3 8.201 206 8.110 2.3 .091 14 .551 6 10 Int. s MVS1250X10S130 127.3 5.012 165.3 6.508 168.3 6.626 231.3 9.106 229 9.016 2.3 .091 13 .512 8 10 Int. a MVS1250X10S140 127.3 5.012 165.3 6.508 168.3 6.626 231.3 9.106 229 9.016 2.3 .091 14 .551 8 15 Int. s MVS1250X15S130 189.8 7.472 227.3 8.949 230.3 9.067 293.3 11.547 291 11.457 2.3 .091 13 .512 8 15 Int. a MVS1250X15S140 189.8 7.472 227.3 8.949 230.3 9.067 293.3 11.547 291 11.457 2.3 .091 14 .551 8 20 Int. s MVS1250X20S130 252.3 9.933 290.3 11.429 293.3 11.547 356.3 14.028 354 13.937 2.3 .091 13 .512 8 20 Int. a MVS1250X20S140 252.3 9.933 290.3 11.429 293.3 11.547 356.3 14.028 354 13.937 2.3 .091 14 .551 8 2 Ext. s MVE1260X02S130 27.5 1.083 53.3 2.098 53.3 2.098 104.3 4.106 102 4.016 2.3 .091 13 .512 2 2 Ext. a MVE1260X02S140 27.5 1.083 53.3 2.098 53.3 2.098 104.3 4.106 102 4.016 2.3 .091 14 .551 2 2 Int. s MVS1260X02S130PL 27.2 1.071 53.0 2.087 53.0 2.087 104.0 4.094 102 4.016 2.0 .079 13 .512 4 2 Int. a MVS1260X02S140PL 27.2 1.071 53.0 2.087 53.0 2.087 104.0 4.094 102 4.016 2.0 .079 14 .551 4 3 Ext. s MVE1260X03S130 40.1 1.579 80.3 3.161 80.3 3.161 139.3 5.484 137 5.394 2.3 .091 13 .512 2 3 Ext. r MVE1260X03S140 40.1 1.579 80.3 3.161 80.3 3.161 139.3 5.484 137 5.394 2.3 .091 14 .551 2 3 Int. s MVS1260X03S130 40.1 1.579 67.3 2.650 67.3 2.650 130.3 5.130 128 5.039 2.3 .091 13 .512 6 3 Int. a MVS1260X03S140 40.1 1.579 67.3 2.650 67.3 2.650 130.3 5.130 128 5.039 2.3 .091 14 .551 6 12.600 .4961 5 Int. s MVS1260X05S130 65.3 2.571 106.3 4.185 106.3 4.185 169.3 6.665 167 6.575 2.3 .091 13 .512 65Int.aMVS1260X05S14065.32.571 106.34.185 106.34.185 169.36.6651676.5752.3.09114.5516 8 Int. r MVS1260X08S130 103.1 4.059 145.3 5.720 145.3 5.720 208.3 8.201 206 8.110 2.3 .091 13 .512 6 8 Int. a MVS1260X08S140 103.1 4.059 145.3 5.720 145.3 5.720 208.3 8.201 206 8.110 2.3 .091 14 .551 6 10 Int. r MVS1260X10S130 128.3 5.051 171.3 6.744 174.3 6.862 237.3 9.343 235 9.252 2.3 .091 13 .512 8 10 Int. a MVS1260X10S140 128.3 5.051 171.3 6.744 174.3 6.862 237.3 9.343 235 9.252 2.3 .091 14 .551 8 15 Int. r MVS1260X15S130 191.3 7.531 236.3 9.303 239.3 9.421 302.3 11.902 300 11.811 2.3 .091 13 .512 8 15 Int. a MVS1260X15S140 191.3 7.531 236.3 9.303 239.3 9.421 302.3 11.902 300 11.811 2.3 .091 14 .551 8 20 Int. r MVS1260X20S130 254.3 10.012 301.3 11.862 304.3 11.980 367.3 14.461 365 14.370 2.3 .091 13 .512 8 20 Int. a MVS1260X20S140 254.3 10.012 301.3 11.862 304.3 11.980 367.3 14.461 365 14.370 2.3 .091 14 .551 8 M OPERATIONAL GUIDANCE M073 CUTTING CONDITIONS M075 TECHNICAL DATA P001 M059
