DCSFMS DCSFMS
Fig.1 DCON
Fig.2 DCON
KWW KWW


L8


L8
CBDP


CBDP


LF
LF
DAH
DAH DCCB APMX


APMX
DCCB DCX
DCX

Right hand tool holder only.
Metric Standard A1 Cutter Diameter Set Bolt Geometry
DC
For metric arbors &40 HSC08025H z x


APMX
&50, &63 HSC10030H z

AZ
&80 HSC12035H
GAMP :+4°
y ARBOR TYPE GAMF :-6°
&100 MBA16033H x

*1 Max.
Number of Teeth
Coolant Hole


Dimensions (mm) Depth of Cut


RMPX
Stock


WT
Type


RE Order Number (mm) Fig.
(kg)
DCX DCSFMS LF DCON CBDP DAH DCCB KWW L8 APMX A1 AZ
ARP5P-040A05AR s Y 5 40 34 40 16 18 9 14 8.4 5.6 0.15 5.0 2.0 1.30 2.8° 1
Fine Pitch


5 ARP5P-050A06AR s Y 6 50 45 40 22 20 11 17 10.4 6.3 0.27 5.0 2.0 1.85 2.9° 1
ARP5P-063A07AR s Y 7 63 50 40 22 20 11 17 10.4 6.3 0.46 5.0 2.5 2.50 3.0° 1
ARP5P-050A07AR Y 7 50 45 40 22 20 11 17 10.4 6.3 0.27 5.0 2.0 1.85 2.9° 1
Fine Pitch


s
Extra


5
ARP5P-063A08AR s Y 8 63 50 40 22 20 11 17 10.4 6.3 0.46 5.0 2.5 2.50 3.0° 1
ARP6P-040A04AR s Y 4 40 34 40 16 18 9 13.4 8.4 5.6 0.15 6.0 2.0 1.15 2.7° 1
ARP6P-050A05AR s Y 5 50 45 40 22 20 11 17 10.4 6.3 0.26 6.0 2.0 1.70 2.9° 1
Fine Pitch


6 ARP6P-063A06AR s Y 6 63 50 40 22 20 11 17 10.4 6.3 0.44 6.0 2.5 2.50 3.1° 1
ARP6P-080A08AR s Y 8 80 56 50 27 23 13 20 12.4 7 0.88 6.0 2.5 2.50 2.3° 1
ARP6P-100B09AR s Y 9 100 78 50 32 26 45 32 14.4 8 1.47 6.0 2.5 2.50 1.7° 2
ARP6P-050A06AR s Y 6 50 45 40 22 20 11 17 10.4 6.3 0.25 6.0 2.0 1.70 2.9° 1
Extra Fine Pitch


ARP6P-063A07AR s Y 7 63 50 40 22 20 11 17 10.4 6.3 0.44 6.0 2.5 2.50 3.1° 1
6
ARP6P-080A09AR s Y 9 80 56 50 27 23 13 20 12.4 7 0.88 6.0 2.5 2.50 2.3° 1
ARP6P-100B11AR s Y 11 100 78 50 32 26 45 32 14.4 8 1.45 6.0 2.5 2.50 1.7° 2
*1 Y=Yes, N=No
RMPX = Max. Ramping Angle L
Note 1) Set bolt not included.
INDEXABLE MILLING


SPARE PARTS N001
TECHNICAL DATA P001 L239
