Fig.1 Fig.2 (Max. Depth of Cut) (Max. Depth of Cut) DCSFMS DCSFMS DCON DCON L8 KWW KWW L8 CBDP CBDP LF LF 15 KAPR KAPR DAH DAH DCCB DCCB DC Right hand tool holder only. DC Cutter Diameter Set Bolt Geometry DC &80 HSC12035H z x Metric Standard &100 HSC16040H z For Inch Arbors &125 MBA20040H KAPR:90° &160 MBA24045H x y ARBOR TYPE (A Holders) GAMP:+15°─+22° With Coolant Hole GAMF:+21° ─+28° * Number of Teeth Stock Dimensions (mm) [inch] RMPX RE (inch) Order Number WT Fig. R DC LF DCON CBDP DAH DCSFMS KWW L8 DCCB (kg) Insert Screw Wrench Anti-seize Lubricant Insert Type 7 80 50 25.4 [1.0"] 26 13 70 9.5 6 20 1.2 APX4000R08007CA s 2° 1 TPS43 TIP15W MK1KS .016 APX4000R10008DA s 8 100 63 31.75 [1.25"] 32 17 80 12.7 8 26 2.1 1.5° 1 TPS43 TIP15W MK1KS AOMT1848 ─ APX4000R12509EA s 9 125 63 38.1 [1.5"] 40 40 100 15.9 10 56 3.3 1° 2 TPS43 TIP15W MK1KS .079 APX4000R16010FA s 10 160 63 50.8 [2.0"] 40 53 100 19.1 11 72 4.8 1° 2 TPS43 TIP15W MK1KS * Clamp Torque (lbf-in) : TPS43=35.6 Note 1) When using inserts with corner radius RE>.126"(3.2 mm), B-Holders or C-Holders are required as shown on L117. Note 2) Set bolt not included. L INDEXABLE MILLING OPERATION GUIDANCE L123 SPARE PARTS N001 TECHNICAL DATA P001 L113
