| Fig.1 | Fig.2 8 DCON DCSFMS | DCON DCSFMS | |||||||
| ø80 | ø100 ø125 KWW DAH DCCB DC DCX L APMX CBDP LF LCCB KAPR | KWW DCCB DC DCX LCCB | L APMX | CBDP LF KAPR | |||||
| Fig.3 | Fig.4 DCSFMS | ||||||||
| ø160 | ø200 DCON ø66.7 | DCSFMS | |||||||
| ø250 KWW L8 P DAH | DCON ø101.6 | DAH | 8 | ||||||
| CBD | KWW | DP L | |||||||
| LCCB LF KAPR | LCCB | LF CB KAPR | |||||||
| DCCB DC DCX APMX | DCCB DC DCX | APMX | |||||||
| Fig.5 | DCSFMS | ||||||||
| ø315 | DCON ø101.6 ø177.8 | ||||||||
| Me | tric Standard | KWW L8 DAH ø22 | |||||||
| Fo | r metric arbors | BDP | |||||||
| C LF B | |||||||||
| KAPR : 50° | LCC KAPR | ||||||||
| GAMP : -6° | DCCB X | iht han | tool holder | hown | |||||
| GAMF : -4° DC=mm siz | e, DCON=mm size | DC DCX APM | g | (m . | |||||
| Teeth | |||||||||
| DC | Order Number | Stock | Coolan Thru | t Number of | Type | LF DCX DCON | Fig. | WT(kg) | APMX |
| AHX640W-080A08R | s | N | 8 | R | 50 92.6 27 | 1 | 1.5 | 6 | |
| 80 | AHX640W-080A08L | s | N | 8 | L | 50 92.6 27 | 1 | 1.5 | 6 |
| AHX640W-080A10R | s | N | 10 | R | 50 92.6 27 | 1 | 1.5 | 6 | |
| AHX640W-080A10L | s | N | 10 | L | 50 92.6 27 | 1 | 1.5 | 6 | |
| AHX640W-100B10R | s | N | 10 | R | 50 112.6 32 | 2 | 2.1 | 6 | |
| 100 | AHX640W-100B10L | s | N | 10 | L | 50 112.6 32 | 2 | 2.1 | 6 |
| AHX640W-100B14R | s | N | 14 | R | 50 112.6 32 | 2 | 2.1 | 6 | |
| AHX640W-100B14L | s | N | 14 | L | 50 112.6 32 | 2 | 2.1 | 6 | |
| AHX640W-125B12R | s | N | 12 | R | 63 137.6 40 | 2 | 3.1 | 6 | |
| 125 | AHX640W-125B12L | s | N | 12 | L | 63 137.6 40 | 2 | 3.1 | 6 |
| AHX640W-125B18R | s | N | 18 | R | 63 137.6 40 | 2 | 3.1 | 6 | |
| AHX640W-125B18L | s | N | 18 | L | 63 137.6 40 | 2 | 3.1 | 6 | |
| AHX640W-160C16R | s | N | 16 | R | 63 172.6 40 | 3 | 5.6 | 6 | |
| 160 | AHX640W-160C16L | s | N | 16 | L | 63 172.6 40 | 3 | 5.6 | 6 |
| AHX640W-160C22R | s | N | 22 | R | 63 172.6 40 | 3 | 5.6 | 6 | |
| AHX640W-160C22L | s | N | 22 | L | 63 172.6 40 | 3 | 5.6 | 6 | |
| AHX640W-200C20R | s | N | 20 | R | 63 212.6 60 | 4 | 8.0 | 6 | |
| AHX640W-200C20L | s | N | 20 | L | 63 212.6 60 | 4 | 8.0 | 6 | |
| 200 | AHX640W-200C28R | s | N | 28 | R | 63 212.6 60 | 4 | 8.0 | 6 |
| AHX640W-200C28L | s | N | 28 | L | 63 212.6 60 | 4 | 8.0 | 6 | |
| AHX640W-250C24R | s | N | 24 | R | 63 262.6 60 | 4 | 12.6 | 6 | |
| AHX640W-250C24L | s | N | 24 | L | 63 262.6 60 | 4 | 12.6 | 6 | |
| 250 | AHX640W-250C36R | s | N | 36 | R | 63 262.6 60 | 4 | 12.6 | 6 |
| AHX640W-250C36L | s | N | 36 | L | 63 262.6 60 | 4 | 12.6 | 6 | |
| AHX640W-315C28R | s | N | 28 | R | 80 327.6 60 | 5 | 31.5 | 6 | |
| 315 | AHX640W-315C28L | s | N | 28 | L | 80 327.6 60 | 5 | 31.5 | 6 |
| AHX640W-315C44R | s | N | 44 | R | 80 3276 60 | 5 | 315 | 6 | |
| AHX640W-315C44L | s | N | 44 | L | . 80 327.6 60 | 5 | . 31.5 | 6 |
