(mm) CARBIDE
| Order Number | RE | DC | APMX | LU | DN | B2 | LF | DCON | No. o | f ock | ype | f fo | Effectiv r inclin | fe length ed angl | f e |
| Flutes | St | T | 0.5° | 1° | 2° | 3° | |||||||||
| VF2XLBR0020N030S06 | 0.2 | 0.4 | 0.32 | 3 | 0.36 | 10° | 50 | 6 | 2 | a | 1 | 3.1 | 3.2 | 3.5 | 3.9 |
| VF2XLBR0020N040S04 | 0.2 | 0.4 | 0.32 | 4 | 0.36 | 8.4° | 50 | 4 | 2 | a | 1 | 4.1 | 4.3 | 4.7 | 5.2 |
| VF2XLBR0020N050S04 | 0.2 | 0.4 | 0.32 | 5 | 0.36 | 7.8° | 50 | 4 | 2 | a | 1 | 5.2 | 5.4 | 5.9 | 6.6 |
| VF2XLBR0025N015S04 | 0.25 | 0.5 | 0.4 | 1.5 | 0.46 | 10.5° | 50 | 4 | 2 | a | 1 | 1.5 | 1.6 | 1.7 | 1.9 |
| VF2XLBR0025N015S06 | 0.25 | 0.5 | 0.4 | 1.5 | 0.46 | 11° | 50 | 6 | 2 | a | 1 | 1.5 | 1.6 | 1.7 | 1.9 |
| VF2XLBR0025N020S04 | 0.25 | 0.5 | 0.4 | 2 | 0.46 | 10° | 50 | 4 | 2 | a | 1 | 2.0 | 2.1 | 2.3 | 2.6 |
| VF2XLBR0025N020S06 | 0.25 | 0.5 | 0.4 | 2 | 0.46 | 10.6° | 50 | 6 | 2 | a | 1 | 2.0 | 2.1 | 2.3 | 2.6 |
| VF2XLBR0025N025S04 | 0.25 | 0.5 | 0.4 | 2.5 | 0.46 | 9.5° | 50 | 4 | 2 | a | 1 | 2.6 | 2.7 | 2.9 | 3.2 |
| VF2XLBR0025N030S04 | 0.25 | 0.5 | 0.4 | 3 | 0.46 | 9.1° | 50 | 4 | 2 | a | 1 | 3.1 | 3.2 | 3.5 | 3.9 |
| VF2XLBR0025N030S06 | 0.25 | 0.5 | 0.4 | 3 | 0.46 | 10° | 50 | 6 | 2 | a | 1 | 3.1 | 3.2 | 3.5 | 3.9 |
| VF2XLBR0025N035S04 | 0.25 | 0.5 | 0.4 | 3.5 | 0.46 | 8.7° | 50 | 4 | 2 | a | 1 | 3.6 | 3.8 | 4.1 | 4.5 |
| VF2XLBR0025N040S04 | 0.25 | 0.5 | 0.4 | 4 | 0.46 | 8.3° | 50 | 4 | 2 | a | 1 | 4.1 | 4.3 | 4.7 | 5.2 |
| VF2XLBR0025N040S06 | 0.25 | 0.5 | 0.4 | 4 | 0.46 | 9.4° | 50 | 6 | 2 | a | 1 | 4.1 | 4.3 | 4.7 | 5.2 |
| VF2XLBR0025N050S04 | 0.25 | 0.5 | 0.4 | 5 | 0.46 | 7.7° | 50 | 4 | 2 | a | 1 | 5.2 | 5.4 | 5.9 | 6.5 |
| VF2XLBR0025N050S06 | 0.25 | 0.5 | 0.4 | 5 | 0.46 | 8.9° | 50 | 6 | 2 | a | 1 | 5.2 | 5.4 | 5.9 | 6.5 |
| VF2XLBR0025N060S04 | 0.25 | 0.5 | 0.4 | 6 | 0.46 | 7.2° | 50 | 4 | 2 | a | 1 | 6.2 | 6.5 | 7.1 | 7.9 |
| VF2XLBR0025N060S06 | 0.25 | 0.5 | 0.4 | 6 | 0.46 | 8.4° | 60 | 6 | 2 | a | 1 | 6.2 | 6.5 | 7.1 | 7.9 |
| VF2XLBR0030N020S04 | 0.3 | 0.6 | 0.48 | 2 | 0.56 | 9.9° | 50 | 4 | 2 | a | 1 | 2.1 | 2.2 | 2.4 | 2.6 |
| VF2XLBR0030N020S06 | 0.3 | 0.6 | 0.48 | 2 | 0.56 | 10.6° | 50 | 6 | 2 | a | 1 | 2.1 | 2.2 | 2.4 | 2.6 |
| VF2XLBR0030N025S04 | 0.3 | 0.6 | 0.48 | 2.5 | 0.56 | 9.4° | 50 | 4 | 2 | a | 1 | 2.6 | 2.7 | 3.0 | 3.3 |
| VF2XLBR0030N030S04 | 0.3 | 0.6 | 0.48 | 3 | 0.56 | 9° | 50 | 4 | 2 | a | 1 | 3.1 | 3.3 | 3.6 | 3.9 |
| VF2XLBR0030N030S06 | 0.3 | 0.6 | 0.48 | 3 | 0.56 | 9.9° | 50 | 6 | 2 | a | 1 | 3.1 | 3.3 | 3.6 | 3.9 |
| VF2XLBR0030N035S04 | 0.3 | 0.6 | 0.48 | 3.5 | 0.56 | 8.6° | 50 | 4 | 2 | a | 1 | 3.6 | 3.8 | 4.2 | 4.6 |
| VF2XLBR0030N040S04 | 0.3 | 0.6 | 0.48 | 4 | 0.56 | 8.3° | 50 | 4 | 2 | a | 1 | 4.2 | 4.4 | 4.8 | 5.2 |
| VF2XLBR0030N040S06 | 0.3 | 0.6 | 0.48 | 4 | 0.56 | 9.3° | 50 | 6 | 2 | a | 1 | 4.2 | 4.4 | 4.8 | 5.2 |
| VF2XLBR0030N050S04 | 0.3 | 0.6 | 0.48 | 5 | 0.56 | 7.6° | 50 | 4 | 2 | a | 1 | 5.2 | 5.4 | 6.0 | 6.6 |
| VF2XLBR0030N050S06 | 0.3 | 0.6 | 0.48 | 5 | 0.56 | 8.8° | 50 | 6 | 2 | a | 1 | 5.2 | 5.4 | 6.0 | 6.6 |
| VF2XLBR0030N060S04 | 0.3 | 0.6 | 0.48 | 6 | 0.56 | 7.1° | 50 | 4 | 2 | a | 1 | 6.3 | 6.5 | 7.1 | 7.9 |
| VF2XLBR0030N060S06 | 0.3 | 0.6 | 0.48 | 6 | 0.56 | 8.4° | 50 | 6 | 2 | a | 1 | 6.3 | 6.5 | 7.1 | 7.9 |
| VF2XLBR0030N070S04 | 0.3 | 0.6 | 0.48 | 7 | 0.56 | 6.6° | 50 | 4 | 2 | a | 1 | 7.3 | 7.6 | 8.3 | 9.2 |
| VF2XLBR0030N080S04 | 0.3 | 0.6 | 0.48 | 8 | 0.56 | 6.2° | 50 | 4 | 2 | a | 1 | 8.3 | 8.7 | 9.5 | 10.6 |
| VF2XLBR0030N080S06 | 0.3 | 0.6 | 0.48 | 8 | 0.56 | 7.6° | 60 | 6 | 2 | a | 1 | 8.3 | 8.7 | 9.5 | 10.6 |
| VF2XLBR0040N020S04 | 0.4 | 0.8 | 0.64 | 2 | 0.76 | 9.9° | 50 | 4 | 2 | a | 1 | 2.1 | 2.2 | 2.3 | 2.6 |
| VF2XLBR0040N020S06 | 0.4 | 0.8 | 0.64 | 2 | 0.76 | 10.6° | 50 | 6 | 2 | a | 1 | 2.1 | 2.2 | 2.3 | 2.6 |
| VF2XLBR0040N030S04 | 0.4 | 0.8 | 0.64 | 3 | 0.76 | 8.9° | 50 | 4 | 2 | a | 1 | 3.1 | 3.3 | 3.5 | 3.9 |
| VF2XLBR0040N030S06 | 0.4 | 0.8 | 0.64 | 3 | 0.76 | 9.9° | 50 | 6 | 2 | a | 1 | 3.1 | 3.3 | 3.5 | 3.9 |
| VF2XLBR0040N040S04 | 0.4 | 0.8 | 0.64 | 4 | 0.76 | 8.2° | 50 | 4 | 2 | a | 1 | 4.2 | 4.3 | 4.7 | 5.2 |
| VF2XLBR0040N040S06 | 0.4 | 0.8 | 0.64 | 4 | 0.76 | 9.3° | 50 | 6 | 2 | a | 1 | 4.2 | 4.3 | 4.7 | 5.2 |
| VF2XLBR0040N050S04 | 0.4 | 0.8 | 0.64 | 5 | 0.76 | 7.5° | 50 | 4 | 2 | a | 1 | 5.2 | 5.4 | 5.9 | 6.5 |
| VF2XLBR0040N060S04 | 0.4 | 0.8 | 0.64 | 6 | 0.76 | 7° | 50 | 4 | 2 | a | 1 | 6.3 | 6.5 | 7.1 | 7.9 |
| VF2XLBR0040N060S06 | 0.4 | 0.8 | 0.64 | 6 | 0.76 | 8.3° | 50 | 6 | 2 | a | 1 | 6.3 | 6.5 | 7.1 | 7.9 |
| VF2XLBR0040N070S04 | 0.4 | 0.8 | 0.64 | 7 | 0.76 | 6.5° | 50 | 4 | 2 | a | 1 | 7.3 | 7.6 | 8.3 | 9.2 |
| VF2XLBR0040N080S04 | 0.4 | 0.8 | 0.64 | 8 | 0.76 | 6.1° | 50 | 4 | 2 | a | 1 | 8.3 | 8.7 | 9.5 | 10.5 |
| VF2XLBR0040N080S06 | 0.4 | 0.8 | 0.64 | 8 | 0.76 | 7.5° | 50 | 6 | 2 | a | 1 | 8.3 | 8.7 | 9.5 | 10.5 |
| VF2XLBR0040N100S04 | 0.4 | 0.8 | 0.64 | 10 | 0.76 | 5.4° | 50 | 4 | 2 | a | 1 | 10.4 | 10.9 | 11.9 | 13.2 |
| VF2XLBR0040N100S06 | 0.4 | 0.8 | 0.64 | 10 | 0.76 | 6.8° | 60 | 6 | 2 | a | 1 | 10.4 | 10.9 | 11.9 | 13.2 |
| VF2XLBR0050N030S04 | 0.5 | 1 | 0.8 | 3 | 0.94 | 8.8° | 50 | 4 | 2 | a | 1 | 3.2 | 3.3 | 3.6 | 4.0 |
| VF2XLBR0050N030S06 | 0.5 | 1 | 0.8 | 3 | 0.94 | 9.8° | 50 | 6 | 2 | a | 1 | 3.2 | 3.3 | 3.6 | 4.0 |
| VF2XLBR0050N040S04 | 0.5 | 1 | 0.8 | 4 | 0.94 | 8° | 50 | 4 | 2 | a | 1 | 4.2 | 4.4 | 4.8 | 5.3 |
| VF2XLBR0050N040S06 | 05 | 1 | 08 | 4 | 094 | 92° | 50 | 6 | 2 | a | 1 | 42 | 44 | 48 | 53 |
| VF2XLBR0050N050S04 | . 0.5 | 1 | . 0.8 | 5 | . 0.94 | . 7.3° | 50 | 4 | 2 | a | 1 | . 5.3 | . 5.5 | . 6.0 | . 6.7 |
