CARBIDE Carbon Steel, Alloy Steel, Cast Iron Tool Steel, Pre-Hardened Steel, Hardened Steel Hardened Steel Hardened Steel Austenitic Titanium Alloy,
| (<30HRC) | ( | ( | 55HRC) | (> | Heat Resistant Alloy | |
| < 45HRC) | < | 55HRC) | Stainless Steel |
e e u u u
APMX LU
DC˂0.4 DC≥ 0.4 Copper Alloy Aluminum Alloy u BHTA2 12° Type 1
LF
DC<0.5 DC 0.5
0 0 - 0.010 - 0.020 4<DCON<6 0
- 0.008 a 2 flute long neck end mill.
APMX LU
LF
Type 2
(mm)
| Order Number | DC | APMX | LU | DN | LF | DCON | No. of Flutes | Stock | Type |
| MS2XLD0020N005 | 0.2 | 0.3 | 0.5 | 0.17 | 45 | 4 | 2 | s | 1 |
| MS2XLD0020N010 | 0.2 | 0.3 | 1 | 0.17 | 45 | 4 | 2 | s | 1 |
| MS2XLD0020N015 | 0.2 | 0.3 | 1.5 | 0.17 | 45 | 4 | 2 | s | 1 |
| MS2XLD0030N010 | 0.3 | 0.4 | 1 | 0.27 | 45 | 4 | 2 | s | 1 |
| MS2XLD0030N020 | 0.3 | 0.4 | 2 | 0.27 | 45 | 4 | 2 | s | 1 |
| MS2XLD0030N030 | 0.3 | 0.4 | 3 | 0.27 | 45 | 4 | 2 | s | 1 |
| MS2XLD0030N060 | 0.3 | 0.4 | 6 | 0.27 | 45 | 4 | 2 | s | 1 |
| MS2XLD0030N090 | 0.3 | 0.4 | 9 | 0.27 | 45 | 4 | 2 | s | 1 |
| MS2XLD0040N020 | 0.4 | 0.6 | 2 | 0.36 | 45 | 4 | 2 | s | 1 |
| MS2XLD0040N030 | 0.4 | 0.6 | 3 | 0.36 | 45 | 4 | 2 | s | 1 |
| MS2XLD0040N040 | 0.4 | 0.6 | 4 | 0.36 | 45 | 4 | 2 | s | 1 |
| MS2XLD0040N080 | 0.4 | 0.6 | 8 | 0.36 | 45 | 4 | 2 | s | 1 |
| MS2XLD0040N120 | 0.4 | 0.6 | 12 | 0.36 | 45 | 4 | 2 | s | 1 |
| MS2XLD0050N020 | 0.5 | 0.7 | 2 | 0.46 | 45 | 4 | 2 | s | 1 |
| MS2XLD0050N040 | 0.5 | 0.7 | 4 | 0.46 | 45 | 4 | 2 | a | 1 |
| MS2XLD0050N060 | 0.5 | 0.7 | 6 | 0.46 | 45 | 4 | 2 | a | 1 |
| MS2XLD0050N080 | 0.5 | 0.7 | 8 | 0.46 | 50 | 4 | 2 | a | 1 |
| MS2XLD0050N100 | 0.5 | 0.7 | 10 | 0.46 | 50 | 4 | 2 | a | 1 |
| MS2XLD0050N150 | 0.5 | 0.7 | 15 | 0.46 | 50 | 4 | 2 | a | 1 |
| MS2XLD0060N020 | 0.6 | 0.9 | 2 | 0.56 | 45 | 4 | 2 | s | 1 |
| MS2XLD0060N040 | 0.6 | 0.9 | 4 | 0.56 | 45 | 4 | 2 | s | 1 |
| MS2XLD0060N060 | 0.6 | 0.9 | 6 | 0.56 | 45 | 4 | 2 | s | 1 |
| MS2XLD0060N080 | 0.6 | 0.9 | 8 | 0.56 | 50 | 4 | 2 | s | 1 |
| MS2XLD0060N100 | 0.6 | 0.9 | 10 | 0.56 | 50 | 4 | 2 | s | 1 |
| MS2XLD0060N120 | 0.6 | 0.9 | 12 | 0.56 | 50 | 4 | 2 | s | 1 |
| MS2XLD0060N180 | 0.6 | 0.9 | 18 | 0.56 | 50 | 4 | 2 | s | 1 |
| MS2XLD0070N020 | 0.7 | 1 | 2 | 0.66 | 45 | 4 | 2 | s | 1 |
| MS2XLD0070N040 | 0.7 | 1 | 4 | 0.66 | 45 | 4 | 2 | s | 1 |
| MS2XLD0070N060 | 0.7 | 1 | 6 | 0.66 | 45 | 4 | 2 | s | 1 |
| MS2XLD0070N080 | 0.7 | 1 | 8 | 0.66 | 50 | 4 | 2 | s | 1 |
| MS2XLD0070N100 | 0.7 | 1 | 10 | 0.66 | 50 | 4 | 2 | s | 1 |
