DP1020 Type DRILLING (inch) DC Stock Metric Decimal Fraction Wire / Thread L/D Order Number LU LCF LH OAL DCON (mm) Letter Size (inch) mm inch mm inch mm inch mm inch mm inch 11.200 .4409 2 a MFE1120X02S120 22.4 .882 46 1.811 49.4 1.945 95 3.740 12 .472 1 11.300 .4449 2 a MFE1130X02S120 22.6 .890 46 1.811 49.4 1.945 95 3.740 12 .472 1 11.400 .4488 2 a MFE1140X02S120 22.8 .898 46 1.811 49.3 1.941 95 3.740 12 .472 1 11.500 .4528 2 a MFE1150X02S120 23.0 .906 46 1.811 49.3 1.941 95 3.740 12 .472 1 11.510 .4532 29/64 1/2-20 2 a MFE1151X02S120 23.0 .906 48 1.890 51.2 2.016 95 3.740 12 .472 1 11.600 .4567 2 a MFE1160X02S120 23.2 .913 48 1.890 51.2 2.016 95 3.740 12 .472 1 11.700 .4606 2 a MFE1170X02S120 23.4 .921 48 1.890 51.2 2.016 95 3.740 12 .472 1 11.800 .4646 2 a MFE1180X02S120 23.6 .929 48 1.890 51.1 2.012 95 3.740 12 .472 1 11.900 .4685 2 a MFE1190X02S120 23.8 .937 48 1.890 51.1 2.012 95 3.740 12 .472 1 12.000 .4724 M14x2.0 2 a MFE1200X02S120 24.0 .945 48 1.890 51.0 2.008 95 3.740 12 .472 1 12.304 .4844 31/64 9/16-12 2 a MFE1230X02S140 24.6 .969 50 1.969 53.0 2.087 102 4.016 14 .551 2 12.500 .4921 M14x1.5 2 a MFE1250X02S140 25.0 .984 50 1.969 53.0 2.087 102 4.016 14 .551 2 12.700 .5000 1/2 2 a MFE1270X02S140 25.4 1.000 52 2.047 55.0 2.165 102 4.016 14 .551 2 13.000 .5118 2 a MFE1300X02S140 26.0 1.024 52 2.047 55.0 2.165 102 4.016 14 .551 2 13.100 .5157 9/16-18 2 a MFE1310X02S140 26.2 1.031 54 2.126 57.0 2.244 102 4.016 14 .551 2 13.500 .5315 5/8-11 2 a MFE1350X02S140 27.0 1.063 54 2.126 57.0 2.244 102 4.016 14 .551 2 13.891 .5469 35/64 2 a MFE1389X02S140 27.8 1.094 56 2.205 59.0 2.323 102 4.016 14 .551 2 14.000 .5512 M16x2.0 2 a MFE1400X02S140 28.0 1.102 56 2.205 59.0 2.323 102 4.016 14 .551 2 14.288 .5625 9/16 2 a MFE1429X02S160 28.6 1.126 58 2.283 61.0 2.402 111 4.370 16 .630 2 14.500 .5709 M16x1.5 2 a MFE1450X02S160 29.0 1.142 58 2.283 61.0 2.402 111 4.370 16 .630 2 14.685 .5782 37/64 5/8-18 2 a MFE1468X02S160 29.4 1.157 60 2.362 63.0 2.480 111 4.370 16 .630 2 15.000 .5906 2 a MFE1500X02S160 30.0 1.181 60 2.362 63.0 2.480 111 4.370 16 .630 2 15.082 .5938 19/32 2 a MFE1508X02S160 30.2 1.189 62 2.441 65.0 2.559 111 4.370 16 .630 2 15.479 .6094 39/64 2 a MFE1548X02S160 31.0 1.220 62 2.441 65.0 2.559 111 4.370 16 .630 2 15.500 .6102 M18x2.5 2 a MFE1550X02S160 31.0 1.220 62 2.441 65.0 2.559 111 4.370 16 .630 2 15.875 .6250 5/8 2 a MFE1588X02S160 31.8 1.252 64 2.520 67.0 2.638 111 4.374 16 .630 2 16.000 .6299 2 a MFE1600X02S160 32.0 1.260 64 2.520 67.0 2.638 111 4.370 16 .630 2 16.272 .6407 41/64 2 a MFE1627X02S180 32.5 1.280 66 2.598 69.0 2.717 119 4.685 18 .709 2 16.500 .6496 M18x1.5 2 a MFE1650X02S180 33.0 1.299 66 2.598 69.0 2.717 119 4.685 18 .709 2 16.669 .6563 21/32 3/4-10 2 a MFE1667X02S180 33.3 1.311 68 2.677 71.0 2.795 119 4.685 18 .709 2 17.000 .6693 Tube Sheet 2 a MFE1700X02S180 34.0 1.339 68 2.677 71.0 2.795 119 4.685 18 .709 2 17.066 .6719 43/64 2 a MFE1707X02S180 34.1 1.343 70 2.756 73.0 2.874 119 4.685 18 .709 2 17.463 .6875 11/16 3/4-16 2 a MFE1746X02S180 34.9 1.374 70 2.756 73.0 2.874 119 4.685 18 .709 2 17.500 .6890 M20x2.5 2 a MFE1750X02S180 35.0 1.378 70 2.756 73.0 2.874 119 4.685 18 .709 2 17.860 .7032 45/64 2 a MFE1786X02S180 35.7 1.406 72 2.835 75.0 2.953 119 4.685 18 .709 2 18.000 .7087 2 a MFE1800X02S180 36.0 1.417 72 2.835 75.0 2.953 119 4.685 18 .709 2 18.257 .7188 23/32 2 a MFE1826X02S200 36.5 1.437 74 2.913 77.0 3.031 127 5.000 20 .787 2 M 18.500 .7283 M20x1.5 2 a MFE1850X02S200 37.0 1.457 74 2.913 77.0 3.031 127 5.000 20 .787 2 18.654 .7344 47/64 2 a MFE1865X02S200 37.3 1.469 76 2.992 79.0 3.110 127 5.000 20 .787 2 19.000 .7480 2 a MFE1900X02S200 38.0 1.496 76 2.992 79.0 3.110 127 5.000 20 .787 2 19.050 .7500 3/4 2 a MFE1905X02S200 38.1 1.500 78 3.071 81.0 3.189 127 5.000 20 .787 2 19.254 .7580 Tube Sheet 2 a MFE1925X02S200 38.5 1.516 78 3.071 81.0 3.189 127 5.000 20 .787 2 CUTTING CONDITIONS M169 OPERATIONAL GUIDANCE M170 TECHNICAL DATA P001 M167
