Coolant (Int./Ext.) HTi10 LU LCF OAL LF PL DCON Coolant (Int./Ext.) HTi10 LU LCF OAL LF PL DCON DRILLING Stock Dimensions (mm) Stock Dimensions (mm) DC(mm)L/D Order Number DC(mm)L/D Order Number 3 Ext. r MAE1070MB 25.1 56.9 102.9 101 1.9 11 3 Ext. r MAE1210MB 62.4 67.2 117.2 115 2.2 13 10.7 3 Int. r MAS1070MB 49.5 56.9 102.9 101 1.9 11 12.1 3 Int. r MAS1210MB 32.1 67.2 117.2 115 2.2 13 6 Int. r MAS1070LB 25.5 90.9 136.9 135 1.9 11 6 Int. r MAS1210LB 63.1 102.2 152.2 150 2.2 13 3 Ext. r MAE1080MB 50.1 57.0 103.0 101 2.0 11 3 Ext. r MAE1220MB 32.5 67.2 117.2 115 2.2 13 10.8 3 Int. r MAS1080MB 25.8 57.0 103.0 101 2.0 11 12.2 3 Int. r MAS1220MB 63.7 67.2 117.2 115 2.2 13 6 Int. r MAS1080LB 50.7 91.0 137.0 135 2.0 11 6 Int. r MAS1220LB 32.8 102.2 152.2 150 2.2 13 3 Ext. r MAE1090MB 26.1 57.0 103.0 101 2.0 11 3 Ext. r MAE1230MB 64.3 67.2 117.2 115 2.2 13 10.9 3 Int. r MAS1090MB 51.3 57.0 103.0 101 2.0 11 12.3 3 Int. r MAS1230MB 33.1 67.2 117.2 115 2.2 13 6 Int. r MAS1090LB 26.4 91.0 137.0 135 2.0 11 6 Int. r MAS1230LB 64.9 102.2 152.2 150 2.2 13 3 Ext. s MAE1100MB 51.9 57.0 103.0 101 2.0 11 3 Ext. r MAE1240MB 33.4 67.3 117.3 115 2.3 13 11.0 3 Int. s MAS1100MB 26.7 57.0 103.0 101 2.0 11 12.4 3 Int. r MAS1240MB 65.5 67.3 117.3 115 2.3 13 6 Int. s MAS1100LB 52.5 91.0 137.0 135 2.0 11 6 Int. r MAS1240LB 33.7 102.3 152.3 150 2.3 13 3 Ext. s *MAE1108MB 27.0 62.0 108.0 106 2.0 12 3 Ext. s MAE1250MB 66.1 67.3 117.3 115 2.3 13 11.08 3 Int. s *MAS1108MB 53.2 62.0 108.0 106 2.0 12 12.5 3 Int. s MAS1250MB 34.0 67.3 117.3 115 2.3 13 6 Int. s *MAS1108LB 27.4 96.0 142.0 140 2.0 12 6 Int. s MAS1250LB 66.8 102.3 152.3 150 2.3 13 3 Ext. r MAE1110MB 53.8 62.0 108.0 106 2.0 12 3 Ext. r MAE1260MB 34.4 67.3 117.3 115 2.3 13 11.1 3 Int. r MAS1110MB 27.7 62.0 108.0 106 2.0 12 12.6 3 Int. r MAS1260MB 67.4 67.3 117.3 115 2.3 13 6 Int. r MAS1110LB 54.4 96.0 142.0 140 2.0 12 6 Int. r MAS1260LB 34.7 102.3 152.3 150 2.3 13 3 Ext. r MAE1120MB 28.0 62.0 108.0 106 2.0 12 3 Ext. r MAE1270MB 68.0 67.3 117.3 115 2.3 13 11.2 3 Int. r MAS1120MB 55.0 62.0 108.0 106 2.0 12 12.7 3 Int. r MAS1270MB 35.0 67.3 117.3 115 2.3 13 6 Int. r MAS1120LB 28.3 96.0 142.0 140 2.0 12 6 Int. r MAS1270LB 68.5 102.3 152.3 150 2.3 13 3 Ext. r MAE1130MB 55.6 62.1 108.1 106 2.1 12 3 Ext. r MAE1280MB 35.2 67.3 117.3 115 2.3 13 11.3 3 Int. r MAS1130MB 28.6 62.1 108.1 106 2.1 12 12.8 3 Int. r MAS1280MB 68.6 67.3 117.3 115 2.3 13 6 Int. r MAS1130LB 56.3 96.1 142.1 140 2.1 12 6 Int. r MAS1280LB 35.3 102.3 152.3 150 2.3 13 3 Ext. r MAE1140MB 29.0 62.1 108.1 106 2.1 12 3 Ext. r MAE1290MB 69.2 67.3 117.3 115 2.3 13 11.4 3 Int. r MAS1140MB 56.9 62.1 108.1 106 2.1 12 12.9 3 Int. r MAS1290MB 35.6 67.3 117.3 115 2.3 13 6 Int. r MAS1140LB 29.3 96.1 142.1 140 2.1 12 6 Int. r MAS1290LB 69.9 102.3 152.3 150 2.3 13 3 Ext. r MAE1150MB 57.0 62.1 108.1 106 2.1 12 3 Ext. s *MAE1296MB 36.0 67.4 117.4 115 2.4 13 11.5 3 Int. r MAS1150MB 29.3 62.1 108.1 106 2.1 12 12.96 3 Int. s *MAS1296MB 70.5 67.4 117.4 115 2.4 13 6 Int. r MAS1150LB 57.5 96.1 142.1 140 2.1 12 6 Int. s *MAS1296LB 36.3 102.4 152.4 150 2.4 13 3 Ext. r MAE1160MB 29.6 62.1 108.1 106 2.1 12 3 Ext. s MAE1300MB 71.1 67.4 117.4 115 2.4 13 11.6 3 Int. r MAS1160MB 58.1 62.1 108.1 106 2.1 12 13.0 3 Int. s MAS1300MB 36.6 67.4 117.4 115 2.4 13 6 Int. r MAS1160LB 29.9 96.1 142.1 140 2.1 12 6 Int. s MAS1300LB 71.7 102.4 152.4 150 2.4 13 3 Ext. r MAE1170MB 58.7 62.1 108.1 106 2.1 12 3 Ext. r MAE1310MB 36.9 72.4 122.4 120 2.4 14 11.7 3 Int. r MAS1170MB 30.2 62.1 108.1 106 2.1 12 13.1 3 Int. r MAS1310MB 72.3 72.4 122.4 120 2.4 14 6 Int. r MAS1170LB 59.3 96.1 142.1 140 2.1 12 6 Int. r MAS1310LB 37.2 112.4 162.4 160 2.4 14 3 Ext. r MAE1180MB 30.5 62.1 108.1 106 2.1 12 3 Ext. r MAE1320MB 72.9 72.4 122.4 120 2.4 14 M 11.8 3 Int. r MAS1180MB 60.0 62.1 108.1 106 2.1 12 13.2 3 Int. r MAS1320MB 37.5 72.4 122.4 120 2.4 14 6 Int. r MAS1180LB 30.9 96.1 142.1 140 2.1 12 6 Int. r MAS1320LB 73.6 112.4 162.4 160 2.4 14 3 Ext. r MAE1190MB 60.6 62.2 108.2 106 2.2 12 3 Ext. r MAE1330MB 37.9 72.4 122.4 120 2.4 14 11.9 3 Int. r MAS1190MB 31.2 62.2 108.2 106 2.2 12 13.3 3 Int. r MAS1330MB 74.2 72.4 122.4 120 2.4 14 6 Int. r MAS1190LB 61.2 96.2 142.2 140 2.2 12 6 Int. r MAS1330LB 38.2 112.4 162.4 160 2.4 14 3 Ext. s MAE1200MB 31.5 62.2 108.2 106 2.2 12 3 Ext. r MAE1340MB 74.8 72.4 122.4 120 2.4 14 12.0 3 Int. s MAS1200MB 61.8 62.2 108.2 106 2.2 12 13.4 3 Int. r MAS1340MB 38.5 72.4 122.4 120 2.4 14 6 Int. s MAS1200LB 31.8 96.2 142.2 140 2.2 12 6 Int. r MAS1340LB 75.4 112.4 162.4 160 2.4 14 CUTTING CONDITIONS M147 TECHNICAL DATA P001 M145
