DRILLING VP15TF Type DRILLING (SOLID CARBIDE) MHS Drill Diameter DC Stock Metric Decimal Fraction Wire / Thread L/D LUOrder NumberLCF LH OAL LF PL DCON (mm) Letter size (inch) mm inch mm inch mm inch mm inch mm inch mm inch mm inch 2 r MHS0720L030B 15.6 .614 31.0 1.220 31.5 1.240 81.5 3.209 80 3.150 1.5 .059 8 .315 3 6 r MHS0720L060B 44.5 1.752 60.8 2.394 61.3 2.413 111.3 4.382 110 4.331 1.3 .051 8 .315 4 7.200 .2835 10 r MHS0720L090B 73.3 2.886 90.8 3.575 91.3 3.594 141.3 5.563 140 5.512 1.3 .051 8 .315 414rMHS0720L120B 102.1 4.020 120.8 4.756 121.3 4.776 171.36.744 1706.6931.3.0518.3154 18 r MHS0720L150B 130.9 5.154 150.8 5.937 151.3 5.957 201.3 7.925 200 7.874 1.3 .051 8 .315 4 25 r MHS0720L200B 181.3 7.138 200.8 7.906 201.3 7.925 251.3 9.894 250 9.843 1.3 .051 8 .315 4 2 r MHS0730L030B 15.9 .626 31.0 1.220 31.5 1.240 81.5 3.209 80 3.150 1.5 .059 8 .315 3 6 r MHS0730L060B 45.1 1.776 60.8 2.394 61.3 2.413 111.3 4.382 110 4.331 1.3 .051 8 .315 4 7.300 .2874 10 r MHS0730L090B 74.3 2.925 90.8 3.575 91.3 3.594 141.3 5.563 140 5.512 1.3 .051 8 .315 414rMHS0730L120B 103.5 4.075 120.8 4.756 121.3 4.776 171.36.744 1706.6931.3.0518.3154 18 r MHS0730L150B 132.7 5.224 150.8 5.937 151.3 5.957 201.3 7.925 200 7.874 1.3 .051 8 .315 4 25 r MHS0730L200B 183.8 7.236 200.8 7.906 201.3 7.925 251.3 9.894 250 9.843 1.3 .051 8 .315 4 1 r MHS0740L030B 8.7 .343 31.0 1.220 31.5 1.240 81.5 3.209 80 3.150 1.5 .059 8 .315 3 6 r MHS0740L060B 45.7 1.799 60.9 2.398 61.4 2.417 111.4 4.386 110 4.331 1.4 .055 8 .315 4 7.400 .2913 10 r MHS0740L090B 75.3 2.965 90.9 3.579 91.4 3.598 141.4 5.567 140 5.512 1.4 .055 8 .315 414rMHS0740L120B 104.9 4.130 120.9 4.760 121.4 4.780 171.46.748 1706.6931.4.0558.3154 18 r MHS0740L150B 134.5 5.295 150.9 5.941 151.4 5.961 201.4 7.929 200 7.874 1.4 .055 8 .315 4 24 r MHS0740L200B 178.9 7.043 200.9 7.909 201.4 7.929 251.4 9.898 250 9.843 1.4 .055 8 .315 4 1 s MHS0750L030B 8.8 .346 31.1 1.224 31.6 1.244 81.6 3.213 80 3.150 1.6 .063 8 .315 3 5 s MHS0750L060B 38.9 1.531 60.9 2.398 61.4 2.417 111.4 4.386 110 4.331 1.4 .055 8 .315 4 7.500 .2953 M 9 s MHS0750L090B 68.9 2.713 90.9 3.579 91.4 3.598 141.4 5.567 140 5.512 1.4 .055 8 .315 413sMHS0750L120B98.9 3.894 120.9 4.760 121.4 4.780 171.46.748 1706.6931.4.0558.3154 17 s MHS0750L150B 128.9 5.075 150.9 5.941 151.4 5.961 201.4 7.929 200 7.874 1.4 .055 8 .315 4 24 s MHS0750L200B 181.4 7.142 200.9 7.909 201.4 7.929 251.4 9.898 250 9.843 1.4 .055 8 .315 4 1 r MHS0760L030B 8.9 .350 31.6 1.244 31.6 1.244 81.6 3.213 80 3.150 1.6 .063 8 .315 3 5 r MHS0760L060B 39.4 1.551 61.4 2.417 61.4 2.417 111.4 4.386 110 4.331 1.4 .055 8 .315 4 9 r MHS0760L090B 69.8 2.748 91.4 3.598 91.4 3.598 141.4 5.567 140 5.512 1.4 .055 8 .315 4 7.600 .2992 13 r MHS0760L120B 100.2 3.945 121.4 4.780 121.4 4.780 171.4 6.748 170 6.693 1.4 .055 8 .315 4 17 r MHS0760L150B 130.6 5.142 151.4 5.961 151.4 5.961 201.4 7.929 200 7.874 1.4 .055 8 .315 4 24 r MHS0760L200B 183.8 7.236 201.4 7.929 201.4 7.929 251.4 9.898 250 9.843 1.4 .055 8 .315 4 30 r MHS0760L250B 229.4 9.031 251.4 9.898 251.4 9.898 301.4 11.866 300 11.811 1.4 .055 8 .315 4 1 r MHS0770L030B 9.0 .354 31.6 1.244 31.6 1.244 81.6 3.213 80 3.150 1.6 .063 8 .315 3 5 r MHS0770L060B 39.9 1.571 61.4 2.417 61.4 2.417 111.4 4.386 110 4.331 1.4 .055 8 .315 4 9 r MHS0770L090B 70.7 2.783 91.4 3.598 91.4 3.598 141.4 5.567 140 5.512 1.4 .055 8 .315 4 7.700 .3031 13 r MHS0770L120B 101.5 3.996 121.4 4.780 121.4 4.780 171.4 6.748 170 6.693 1.4 .055 8 .315 4 17 r MHS0770L150B 132.3 5.209 151.4 5.961 151.4 5.961 201.4 7.929 200 7.874 1.4 .055 8 .315 4 M 23 r MHS0770L200B 178.5 7.028 201.4 7.929 201.4 7.929 251.4 9.898 250 9.843 1.4 .055 8 .315 4 30 r MHS0770L250B 232.4 9.150 251.4 9.898 251.4 9.898 301.4 11.866 300 11.811 1.4 .055 8 .315 4 1 s MHS0780L030B 9.1 .358 31.6 1.244 31.6 1.244 81.6 3.213 80 3.150 1.6 .063 8 .315 3 5 s MHS0780L060B 40.4 1.591 61.4 2.417 61.4 2.417 111.4 4.386 110 4.331 1.4 .055 8 .315 4 9 s MHS0780L090B 71.6 2.819 91.4 3.598 91.4 3.598 141.4 5.567 140 5.512 1.4 .055 8 .315 4 7.800 .3071 13 s MHS0780L120B 102.8 4.047 121.4 4.780 121.4 4.780 171.4 6.748 170 6.693 1.4 .055 8 .315 4 17 s MHS0780L150B 134.0 5.276 151.4 5.961 151.4 5.961 201.4 7.929 200 7.874 1.4 .055 8 .315 4 23 s MHS0780L200B 180.8 7.118 201.4 7.929 201.4 7.929 251.4 9.898 250 9.843 1.4 .055 8 .315 4 30 s MHS0780L250B 235.4 9.268 251.4 9.898 251.4 9.898 301.4 11.866 300 11.811 1.4 .055 8 .315 4 Note 1) Please contact Mitsubishi Materials for any geometry that is not in the catalog (e.g. different dia. and length). s : Stocked in Japan r : Made to Order M118
