DC Stock LU LCF LH OAL LF PL DCON Type DP7020 Metric Decimal Fraction Wire / Thread L/D Order Number (mm) Letter size (inch) mm inch mm inch mm inch mm inch mm inch mm inch mm inch 3 a MMS0794X3D080 25.2 .992 41.4 1.630 41.4 1.630 91.4 3.598 90 3.543 1.4 .055 8 .315 1 7.938 .3125 5/16 3/8-16 5 a MMS0794X5D080 41.1 1.618 57.4 2.260 57.4 2.260 104.4 4.110 103 4.055 1.4 .055 8 .315 1 3 a MMS0800X3DB 25.5 1.004 41.5 1.634 41.5 1.634 91.5 3.602 90 3.543 1.5 .059 8 .315 1 8.000 .3150 5 a MMS0800X5DB 41.5 1.634 57.5 2.264 57.5 2.264 104.5 4.114 103 4.055 1.5 .059 8 .315 1 3 a MMS0810X3DB 25.8 1.016 44.5 1.752 46.5 1.831 97.5 3.839 96 3.780 1.5 .059 10 .394 1 8.100 .3189 5 a MMS0810X5DB 42.0 1.654 61.5 2.421 63.5 2.500 114.5 4.508 113 4.449 1.5 .059 10 .394 1 3 a MMS0820X3DB 26.1 1.028 44.5 1.752 46.5 1.831 97.5 3.839 96 3.780 1.5 .059 10 .394 1 8.200 .3228 P 5 a MMS0820X5DB 42.5 1.673 61.5 2.421 63.5 2.500 114.5 4.508 113 4.449 1.5 .059 10 .394 1 3 a MMS0830X3DB 26.4 1.039 44.5 1.752 46.5 1.831 97.5 3.839 96 3.780 1.5 .059 10 .394 1 8.300 .3268 5 a MMS0830X5DB 43.0 1.693 61.5 2.421 63.5 2.500 114.5 4.508 113 4.449 1.5 .059 10 .394 1 3 a MMS0833X3D100 26.5 1.043 44.5 1.752 46.5 1.831 97.5 3.839 96 3.780 1.5 .059 10 .394 1 8.335 .3282 21/64 5 a MMS0833X5D100 43.2 1.701 61.5 2.421 63.5 2.500 114.5 4.508 113 4.449 1.5 .059 10 .394 1 3 a MMS0840X3DB 26.7 1.051 44.5 1.752 46.5 1.831 97.5 3.839 96 3.780 1.5 .059 10 .394 1 8.400 .3307 5 a MMS0840X5DB 43.5 1.713 61.5 2.421 63.5 2.500 114.5 4.508 113 4.449 1.5 .059 10 .394 1 3 a MMS0843X3D100 26.8 1.055 44.5 1.752 46.5 1.831 97.5 3.839 96 3.780 1.5 .059 10 .394 1 8.433 .3320 Q 3/8-24 5 a MMS0843X5D100 43.7 1.720 61.5 2.421 63.5 2.500 114.5 4.508 113 4.449 1.5 .059 10 .394 1 3 a MMS0850X3DB 27.0 1.063 44.6 1.756 46.6 1.835 97.6 3.843 96 3.780 1.6 .063 10 .394 1 8.500 .3346 M10x1.5 5 a MMS0850X5DB 44.0 1.732 61.6 2.425 63.6 2.504 114.6 4.512 113 4.449 1.6 .063 10 .394 1 3 a MMS0860X3DB 27.4 1.079 46.6 1.835 48.6 1.913 102.6 4.039 101 3.976 1.6 .063 10 .394 1 8.600 .3386 R 5 a MMS0860X5DB 44.6 1.756 64.6 2.543 66.6 2.622 117.6 4.630 116 4.567 1.6 .063 10 .394 1 3 a MMS0870X3DB 27.7 1.091 46.6 1.835 48.6 1.913 102.6 4.039 101 3.976 1.6 .063 10 .394 1 8.700 .3425 M10x1.25 5 a MMS0870X5DB 45.1 1.776 64.6 2.543 66.6 2.622 117.6 4.630 116 4.567 1.6 .063 10 .394 1 3 a MMS0873X3D100 27.8 1.094 46.6 1.835 48.6 1.913 102.6 4.039 101 3.976 1.6 .063 10 .394 1 8.732 .3438 11/32 5 a MMS0873X5D100 45.2 1.780 64.6 2.543 66.6 2.622 117.6 4.630 116 4.567 1.6 .063 10 .394 1 3 a MMS0880X3DB 28.0 1.102 46.6 1.835 48.6 1.913 102.6 4.039 101 3.976 1.6 .063 10 .394 1 8.800 .3465 5 a MMS0880X5DB 45.6 1.795 64.6 2.543 66.6 2.622 117.6 4.630 116 4.567 1.6 .063 10 .394 1 3 a MMS0890X3DB 28.3 1.114 46.6 1.835 48.6 1.913 102.6 4.039 101 3.976 1.6 .063 10 .394 1 8.900 .3504 5 a MMS0890X5DB 46.1 1.815 64.6 2.543 66.6 2.622 117.6 4.630 116 4.567 1.6 .063 10 .394 1 3 a MMS0900X3DB 28.6 1.126 46.6 1.835 48.6 1.913 102.6 4.039 101 3.976 1.6 .063 10 .394 1 9.000 .3543 5 a MMS0900X5DB 46.6 1.835 64.6 2.543 66.6 2.622 117.6 4.630 116 4.567 1.6 .063 10 .394 1 3 a MMS0910X3DB 29.0 1.142 49.7 1.957 51.7 2.035 102.7 4.043 101 3.976 1.7 .067 10 .394 1 9.100 .3583 T 5 a MMS0910X5DB 47.2 1.858 68.7 2.705 71.7 2.823 122.7 4.831 121 4.764 1.7 .067 10 .394 1 3 a MMS0913X3D100 29.0 1.142 49.7 1.957 51.7 2.035 102.7 4.043 101 3.976 1.7 .067 10 .394 1 9.129 .3594 23/64 5 a MMS0913X5D100 47.3 1.862 68.7 2.705 71.7 2.823 122.7 4.831 121 4.764 1.7 .067 10 .394 1 3 a MMS0920X3DB 29.3 1.154 49.7 1.957 51.7 2.035 102.7 4.043 101 3.976 1.7 .067 10 .394 1 9.200 .3622 5 a MMS0920X5DB 47.7 1.878 68.7 2.705 71.7 2.823 122.7 4.831 121 4.764 1.7 .067 10 .394 1 3 a MMS0930X3DB 29.6 1.165 49.7 1.957 51.7 2.035 102.7 4.043 101 3.976 1.7 .067 10 .394 1 M 9.300 .3661 5 a MMS0930X5DB 48.2 1.898 68.7 2.705 71.7 2.823 122.7 4.831 121 4.764 1.7 .067 10 .394 1 3 MMS0935X3D100 29.7 1.169 49.7 1.957 51.7 2.035 102.7 4.043 101 3.976 1.7 .067 10 .394 1 DRILLING a 9.348 .3680 U 7/16-14 5 a MMS0935X5D100 48.4 1.906 68.7 2.705 71.7 2.823 122.7 4.831 121 4.764 1.7 .067 10 .394 1 3 a MMS0940X3DB 29.9 1.177 49.7 1.957 51.7 2.035 102.7 4.043 101 3.976 1.7 .067 10 .394 1 9.400 .3701 5 a MMS0940X5DB 48.7 1.917 68.7 2.705 71.7 2.823 122.7 4.831 121 4.764 1.7 .067 10 .394 1 3 a MMS0950X3DB 30.2 1.189 49.7 1.957 51.7 2.035 102.7 4.043 101 3.976 1.7 .067 10 .394 1 9.500 .3740 5 a MMS0950X5DB 49.2 1.937 68.7 2.705 71.7 2.823 122.7 4.831 121 4.764 1.7 .067 10 .394 1 3 a MMS0953X3D100 30.3 1.193 51.7 2.035 51.7 2.035 102.7 4.043 101 3.976 1.7 .067 10 .394 1 9.525 .3750 3/8 5 a MMS0953X5D100 49.3 1.941 71.7 2.823 71.7 2.823 122.7 4.831 121 4.764 1.7 .067 10 .394 1 3 a MMS0960X3DB 30.5 1.201 51.8 2.039 51.8 2.039 102.8 4.047 101 3.976 1.8 .071 10 .394 1 9.600 .3780 5 a MMS0960X5DB 49.7 1.957 71.8 2.827 71.8 2.827 122.8 4.835 121 4.764 1.8 .071 10 .394 1 CUTTING CONDITIONS M107 OPERATIONAL GUIDANCE M109 TECHNICAL DATA P001 M101
