Coolant (Int./Ext.) DP1020 Type DRILLING DC Stock Metric Decimal Fraction Wire / Thread L/D Order Number LU LCF LH OAL LF PL DCON (mm) Letter Size (inch) mm inch mm inch mm inch mm inch mm inch mm inch mm inch 2 Ext. s MVE1850X02S190 40.4 1.591 67.4 2.654 67.4 2.654 130.4 5.134 127 5.000 3.4 .134 19 .748 2 2 Ext. a MVE1850X02S200 40.4 1.591 67.4 2.654 67.4 2.654 130.4 5.134 127 5.000 3.4 .134 20 .787 2 3 Ext. s MVE1850X03S190 58.9 2.319 117.4 4.622 117.4 4.622 182.4 7.181 179 7.047 3.4 .134 19 .748 2 18.500 .7283 M20x1.5 33 Ext.Int. rs MVE1850X03S200MVS1850X03S19058.92.319117.44.622117.44.622182.47.1811797.0473.4.134 20 .787 258.92.31995.93.77698.43.874163.46.4331606.2993.4.13419.7486 3 Int. a MVS1850X03S200 58.9 2.319 95.9 3.776 98.4 3.874 163.4 6.433 160 6.299 3.4 .134 20 .787 6 5 Int. s MVS1850X05S190 95.9 3.776 151.4 5.961 155.4 6.118 220.4 8.677 217 8.543 3.4 .134 19 .748 6 5 Int. a MVS1850X05S200 95.9 3.776 151.4 5.961 155.4 6.118 220.4 8.677 217 8.543 3.4 .134 20 .787 6 2 Ext. r MVE1860X02S190 40.6 1.598 67.4 2.654 67.4 2.654 130.4 5.134 127 5.000 3.4 .134 19 .748 2 2 Ext. r MVE1860X02S200 40.6 1.598 67.4 2.654 67.4 2.654 130.4 5.134 127 5.000 3.4 .134 20 .787 2 3 Ext. r MVE1860X03S190 59.2 2.331 117.4 4.622 117.4 4.622 182.4 7.181 179 7.047 3.4 .134 19 .748 2 18.600 .7323 3 Ext. r MVE1860X03S200 59.2 2.331 117.4 4.622 117.4 4.622 182.4 7.181 179 7.047 3.4 .134 20 .787 23Int.rMVS1860X03S19059.22.33198.43.87498.43.874163.46.4331606.2993.4.13419.7486 3 Int. r MVS1860X03S200 59.2 2.331 98.4 3.874 98.4 3.874 163.4 6.433 160 6.299 3.4 .134 20 .787 6 5 Int. r MVS1860X05S190 96.4 3.795 155.4 6.118 155.4 6.118 220.4 8.677 217 8.543 3.4 .134 19 .748 6 5 Int. r MVS1860X05S200 96.4 3.795 155.4 6.118 155.4 6.118 220.4 8.677 217 8.543 3.4 .134 20 .787 6 2 Ext. a MVE1865X02S200 40.7 1.602 67.4 2.654 67.4 2.654 130.4 5.134 127 5.000 3.4 .134 20 .787 2 18.654 .7344 47/64 3 Int. a MVS1865X03S200 59.3 2.335 98.4 3.874 98.4 3.874 163.4 6.433 160 6.299 3.4 .134 20 .787 6 5 Int. a MVS1865X05S200 96.6 3.803 155.4 6.118 155.4 6.118 220.4 8.677 217 8.543 3.4 .134 20 .787 6 2 Ext. r MVE1870X02S190 40.8 1.606 67.4 2.654 67.4 2.654 130.4 5.134 127 5.000 3.4 .134 19 .748 2 2 Ext. r MVE1870X02S200 40.8 1.606 67.4 2.654 67.4 2.654 130.4 5.134 127 5.000 3.4 .134 20 .787 2 3 Ext. r MVE1870X03S190 59.5 2.343 117.4 4.622 117.4 4.622 182.4 7.181 179 7.047 3.4 .134 19 .748 2 18.700 .7362 3 Ext. r MVE1870X03S200 59.5 2.343 117.4 4.622 117.4 4.622 182.4 7.181 179 7.047 3.4 .134 20 .787 23Int.rMVS1870X03S19059.52.34398.43.87498.43.874163.46.4331606.2993.4.13419.7486 3 Int. r MVS1870X03S200 59.5 2.343 98.4 3.874 98.4 3.874 163.4 6.433 160 6.299 3.4 .134 20 .787 6 5 Int. r MVS1870X05S190 96.9 3.815 155.4 6.118 155.4 6.118 220.4 8.677 217 8.543 3.4 .134 19 .748 6 5 Int. r MVS1870X05S200 96.9 3.815 155.4 6.118 155.4 6.118 220.4 8.677 217 8.543 3.4 .134 20 .787 6 2 Ext. r MVE1880X02S190 41.0 1.614 67.4 2.654 67.4 2.654 130.4 5.134 127 5.000 3.4 .134 19 .748 2 2 Ext. r MVE1880X02S200 41.0 1.614 67.4 2.654 67.4 2.654 130.4 5.134 127 5.000 3.4 .134 20 .787 2 3 Ext. r MVE1880X03S190 59.8 2.354 117.4 4.622 117.4 4.622 182.4 7.181 179 7.047 3.4 .134 19 .748 2 18.800 .7402 3 Ext. r MVE1880X03S200 59.8 2.354 117.4 4.622 117.4 4.622 182.4 7.181 179 7.047 3.4 .134 20 .787 23Int.rMVS1880X03S19059.82.35498.43.87498.43.874163.46.4331606.2993.4.13419.7486 3 Int. r MVS1880X03S200 59.8 2.354 98.4 3.874 98.4 3.874 163.4 6.433 160 6.299 3.4 .134 20 .787 6 5 Int. r MVS1880X05S190 97.4 3.835 155.4 6.118 155.4 6.118 220.4 8.677 217 8.543 3.4 .134 19 .748 6 5 Int. r MVS1880X05S200 97.4 3.835 155.4 6.118 155.4 6.118 220.4 8.677 217 8.543 3.4 .134 20 .787 6 2 Ext. r MVE1890X02S190 41.2 1.622 67.4 2.654 67.4 2.654 130.4 5.134 127 5.000 3.4 .134 19 .748 2 2 Ext. r MVE1890X02S200 41.2 1.622 67.4 2.654 67.4 2.654 130.4 5.134 127 5.000 3.4 .134 20 .787 2 3 Ext. r MVE1890X03S190 60.1 2.366 117.4 4.622 117.4 4.622 182.4 7.181 179 7.047 3.4 .134 19 .748 2 18.900 .7441 3 Ext. r MVE1890X03S200 60.1 2.366 117.4 4.622 117.4 4.622 182.4 7.181 179 7.047 3.4 .134 20 .787 23Int.rMVS1890X03S19060.12.36698.43.87498.43.874163.46.4331606.2993.4.13419.7486 3 Int. r MVS1890X03S200 60.1 2.366 98.4 3.874 98.4 3.874 163.4 6.433 160 6.299 3.4 .134 20 .787 65Int.rMVS1890X05S19097.93.854155.46.118155.46.118220.48.6772178.5433.4.13419.7486M 5 Int. r MVS1890X05S200 97.9 3.854 155.4 6.118 155.4 6.118 220.4 8.677 217 8.543 3.4 .134 20 .787 6 2 Ext. s MVE1900X02S190 41.5 1.634 67.5 2.657 67.5 2.657 130.5 5.138 127 5.000 3.5 .138 19 .748 2 2 Ext. a MVE1900X02S200 41.5 1.634 67.5 2.657 67.5 2.657 130.5 5.138 127 5.000 3.5 .138 20 .787 2 3 Ext. s MVE1900X03S190 60.5 2.382 117.5 4.626 117.5 4.626 182.5 7.185 179 7.047 3.5 .138 19 .748 2 19.000 .7480 3 Ext. r MVE1900X03S200 60.5 2.382 117.5 4.626 117.5 4.626 182.5 7.185 179 7.047 3.5 .138 20 .787 23Int.sMVS1900X03S19060.52.38298.53.87898.53.878163.56.4371606.2993.5.13819.7486 3 Int. a MVS1900X03S200 60.5 2.382 98.5 3.878 98.5 3.878 163.5 6.437 160 6.299 3.5 .138 20 .787 6 5 Int. s MVS1900X05S190 98.5 3.878 155.5 6.122 155.5 6.122 220.5 8.681 217 8.543 3.5 .138 19 .748 6 5 Int. a MVS1900X05S200 98.5 3.878 155.5 6.122 155.5 6.122 220.5 8.681 217 8.543 3.5 .138 20 .787 6 OPERATIONAL GUIDANCE M073 CUTTING CONDITIONS M075 TECHNICAL DATA P001 M071
