Coolant (Int./Ext.) DP1020 Type DRILLING DC Stock Metric Decimal Fraction Wire / Thread L/D Order Number LU LCF LH OAL LF PL DCON (mm) Letter Size (inch) mm inch mm inch mm inch mm inch mm inch mm inch mm inch 2 Ext. a MVE1560X02S160 34.0 1.339 60.8 2.394 60.8 2.394 117.8 4.638 115 4.528 2.8 .110 16 .630 2 3 Ext. s MVE1560X03S160 49.6 1.953 98.8 3.890 98.8 3.890 162.8 6.409 160 6.299 2.8 .110 16 .630 2 15.600 .6142 3 Int. a MVS1560X03S160 49.6 1.953 82.8 3.260 82.8 3.260 147.8 5.819 145 5.709 2.8 .110 16 .630 6 5 Int. a MVS1560X05S160 80.8 3.181 130.8 5.150 130.8 5.150 195.8 7.709 193 7.598 2.8 .110 16 .630 6 8 Int. a MVS1560X08S160 127.6 5.024 178.8 7.039 183.8 7.236 243.8 9.598 241 9.488 2.8 .110 16 .630 6 2 Ext. a MVE1570X02S160 34.3 1.350 60.9 2.398 60.9 2.398 117.9 4.642 115 4.528 2.9 .114 16 .630 2 3 Ext. s MVE1570X03S160 50.0 1.969 98.9 3.894 98.9 3.894 162.9 6.413 160 6.299 2.9 .114 16 .630 2 15.700 .6181 3 Int. a MVS1570X03S160 50.0 1.969 82.9 3.264 82.9 3.264 147.9 5.823 145 5.709 2.9 .114 16 .630 6 5 Int. a MVS1570X05S160 81.4 3.205 130.9 5.154 130.9 5.154 195.9 7.713 193 7.598 2.9 .114 16 .630 6 8 Int. a MVS1570X08S160 128.5 5.059 178.9 7.043 183.9 7.240 243.9 9.602 241 9.488 2.9 .114 16 .630 6 2 Ext. a MVE1580X02S160 34.5 1.358 60.9 2.398 60.9 2.398 117.9 4.642 115 4.528 2.9 .114 16 .630 2 3 Ext. s MVE1580X03S160 50.3 1.980 98.9 3.894 98.9 3.894 162.9 6.413 160 6.299 2.9 .114 16 .630 2 15.800 .6220 3 Int. a MVS1580X03S160 50.3 1.980 82.9 3.264 82.9 3.264 147.9 5.823 145 5.709 2.9 .114 16 .630 6 5 Int. a MVS1580X05S160 81.9 3.224 130.9 5.154 130.9 5.154 195.9 7.713 193 7.598 2.9 .114 16 .630 6 8 Int. a MVS1580X08S160 129.3 5.091 178.9 7.043 183.9 7.240 243.9 9.602 241 9.488 2.9 .114 16 .630 6 2 Ext. a MVE1588X02S160 34.6 1.362 60.9 2.398 60.9 2.398 117.9 4.642 115 4.528 2.9 .114 16 .630 2 15.875 .6250 5/8 3 Int. a MVS1588X03S160 50.5 1.988 82.9 3.264 82.9 3.264 147.9 5.823 145 5.709 2.9 .114 16 .630 65Int.aMVS1588X05S16082.23.236130.95.154130.95.154195.97.7131937.5982.9.11416.6306 8 Int. a MVS1588X08S160 129.9 5.114 178.9 7.043 183.9 7.240 243.9 9.602 241 9.488 2.9 .114 16 .630 6 2 Ext. a MVE1590X02S160 34.7 1.366 60.9 2.398 60.9 2.398 117.9 4.642 115 4.528 2.9 .114 16 .630 2 3 Ext. s MVE1590X03S160 50.6 1.992 98.9 3.894 98.9 3.894 162.9 6.413 160 6.299 2.9 .114 16 .630 2 15.900 .6260 3 Int. a MVS1590X03S160 50.6 1.992 82.9 3.264 82.9 3.264 147.9 5.823 145 5.709 2.9 .114 16 .630 6 5 Int. a MVS1590X05S160 82.4 3.244 130.9 5.154 130.9 5.154 195.9 7.713 193 7.598 2.9 .114 16 .630 6 8 Int. a MVS1590X08S160 130.1 5.122 178.9 7.043 183.9 7.240 243.9 9.602 241 9.488 2.9 .114 16 .630 6 2 Ext. a MVE1600X02S160 34.9 1.374 60.9 2.398 60.9 2.398 117.9 4.642 115 4.528 2.9 .114 16 .630 2 3 Ext. s MVE1600X03S160 50.9 2.004 98.9 3.894 98.9 3.894 162.9 6.413 160 6.299 2.9 .114 16 .630 2 16.000 .6299 3 Int. a MVS1600X03S160 50.9 2.004 82.9 3.264 82.9 3.264 147.9 5.823 145 5.709 2.9 .114 16 .630 6 5 Int. a MVS1600X05S160 82.9 3.264 130.9 5.154 130.9 5.154 195.9 7.713 193 7.598 2.9 .114 16 .630 6 8 Int. a MVS1600X08S160 130.9 5.154 178.9 7.043 183.9 7.240 243.9 9.602 241 9.488 2.9 .114 16 .630 6 2 Ext. r MVE1610X02S170 35.1 1.382 62.9 2.476 62.9 2.476 121.9 4.799 119 4.685 2.9 .114 17 .669 2 2 Ext. r MVE1610X02S180 35.1 1.382 62.9 2.476 62.9 2.476 121.9 4.799 119 4.685 2.9 .114 18 .709 2 3 Ext. r MVE1610X03S170 51.2 2.016 104.9 4.130 104.9 4.130 169.9 6.689 167 6.575 2.9 .114 17 .669 2 16.100 .6339 3 Ext. r MVE1610X03S180 51.2 2.016 104.9 4.130 104.9 4.130 169.9 6.689 167 6.575 2.9 .114 18 .709 23Int.rMVS1610X03S17051.22.01685.43.36287.93.461152.96.0201505.9062.9.11417.6696 3 Int. r MVS1610X03S180 51.2 2.016 85.4 3.362 87.9 3.461 152.9 6.020 150 5.906 2.9 .114 18 .709 6 5 Int. r MVS1610X05S170 83.4 3.283 134.9 5.311 138.9 5.469 203.9 8.028 201 7.913 2.9 .114 17 .669 6 5 Int. r MVS1610X05S180 83.4 3.283 134.9 5.311 138.9 5.469 203.9 8.028 201 7.913 2.9 .114 18 .709 6 2 Ext. s MVE1620X02S170 35.3 1.390 62.9 2.476 62.9 2.476 121.9 4.799 119 4.685 2.9 .114 17 .669 2 2 Ext. r MVE1620X02S180 35.3 1.390 62.9 2.476 62.9 2.476 121.9 4.799 119 4.685 2.9 .114 18 .709 2 3 Ext. r MVE1620X03S170 51.5 2.028 104.9 4.130 104.9 4.130 169.9 6.689 167 6.575 2.9 .114 17 .669 2 16.200 .6378 3 Ext. r MVE1620X03S180 51.5 2.028 104.9 4.130 104.9 4.130 169.9 6.689 167 6.575 2.9 .114 18 .709 23Int.rMVS1620X03S17051.52.02885.43.36287.93.461152.96.0201505.9062.9.11417.6696M 3 Int. r MVS1620X03S180 51.5 2.028 85.4 3.362 87.9 3.461 152.9 6.020 150 5.906 2.9 .114 18 .709 6 5 Int. r MVS1620X05S170 83.9 3.303 134.9 5.311 138.9 5.469 203.9 8.028 201 7.913 2.9 .114 17 .669 6 5 Int. r MVS1620X05S180 83.9 3.303 134.9 5.311 138.9 5.469 203.9 8.028 201 7.913 2.9 .114 18 .709 6 2 Ext. a MVE1627X02S180 35.5 1.398 63.0 2.480 63.0 2.480 122.0 4.803 119 4.685 3.0 .118 18 .709 2 16.272 .6407 41/64 3 Int. a MVS1627X03S180 51.7 2.035 85.5 3.366 88.0 3.465 153.0 6.024 150 5.906 3.0 .118 18 .709 6 5 Int. a MVS1627X05S180 84.3 3.319 135.0 5.315 139.0 5.472 204.0 8.031 201 7.913 3.0 .118 18 .709 6 OPERATIONAL GUIDANCE M073 CUTTING CONDITIONS M075 TECHNICAL DATA P001 M067
