- Premium nickel-coated bodies.
- Designed for maximum performance.
- Ideally suited for die and mould manufacturing.
- Weldon Shanks
max ramp coolant
| order number | catalogue number | D1 max | D1 | D | L | L2 | Ap1 max | Z | angle | max RPM | supply | kg | |||
| 3940703 | M170D020Z02B20RD10 | 20 | 10 | 20 | 110 | 40 | 5,0 | 2 | 20.0° | 15900 | Yes | 0,24 | |||
| 3940708 | M170D025Z03B25RD10 | 25 | 15 | 25 | 110 | 40 | 5,0 | 3 | 9.0° | 12900 | Yes | 0,35 |
- Spare Parts
insert Torx
| D1 max | screw | Nm | driver | |
| 20 | 193.342 | 3,5 | 12148082400 | |
| 25 | 193.342 | 3,5 | 12148082400 |
NOTE: All spare parts except the insert screws must be ordered separately.
