- Double-sided, eight cutting edges.
- Anti-rotation feature for better stability and higher feed rates.
- Pocketing and profiling capabilities.
- Cylindrical End Mills
| order number | catalogue number | D1 max | D1 | D | L | LBX | L2 | Ap1 max | Z | max RPM | coolant supply | kg |
| 5210279 | M200D25Z03A25RN10L150 | 25 | 15 | 25 | 150 | 32 | 32 | 5,0 | 3 | 54700 | Yes | 0,50 |
| 5210300 | M200D25Z03A25RN10L200 | 25 | 15 | 25 | 200 | 32 | 32 | 5,0 | 3 | 54700 | Yes | 0,69 |
| 5210301 | M200D25Z03A32RN10L250 | 25 | 15 | 32 | 250 | 32 | 32 | 5,0 | 3 | 54700 | Yes | 1,41 |
| 5210302 | M200D28Z03A25RN10L200 | 28 | 18 | 25 | 200 | 40 | 40 | 5,0 | 3 | 51600 | Yes | 0,70 |
| 5210303 | M200D32Z04A32RN10L150 | 32 | 22 | 32 | 150 | 40 | 40 | 5,0 | 4 | 48300 | Yes | 0,83 |
| 5210304 | M200D32Z03A32RN10L200 | 32 | 22 | 32 | 200 | 40 | 40 | 5,0 | 3 | 48300 | Yes | 1,14 |
- Spare Parts
insert Torx
| screw | Nm | driver |
| 191.848 | 2,0 | 170.025 |
