- Insert Selection Guide
| Light | General | Heavy | |
| Machining | Purpose | Machining |
Material
| Group | Geometry | Grade | Geometry | Grade | Geometry | Grade | ||||
| P1–P2 | .S..MM | WU35PM | .S..MM | WP40PM | .S..MM | WP40PM | ||||
| P3–P4 | .S..MM | WP25PM | .S..MM | WP25PM | .S..MH | WP40PM | ||||
| P5–P6 | .S..MM | WP25PM | .S..MM | WP35CM | .S..MH | WP35CM | ||||
| M1–M2 | .S..MM | WS30PM | .S..MM | WU35PM | .S..MM | WP40PM | ||||
| M3 | .S..MM | WP25PM | .S..MM | WP35CM | .S..MM | WP40PM | ||||
| K1–K2 | .S..MH | WK15CM | .S..MH | WK15CM | .S..MH | WP20CM | ||||
| K3 | .S..MH | WK15CM | .S..MH | WK15CM | .S..MH | WP20CM | ||||
| N1–N2 | – | – | – | – | – | – | ||||
| N3 | – | – | – | – | – | – | ||||
| S1–S2 | .S..MM | WS30PM | .S..MM | WU35PM | .S..MM | WP40PM | ||||
| S3 | .S..MM | WS30PM | .S..MM | WU35PM | .S..MM | WP40PM | ||||
| S4 | .S..MM | WS30PM | .S..MM | WU35PM | .S..MM | WP40PM | ||||
| H1 | .S..MH | WP35CM | .S..MR | WP25PM | – | – |
iC12 Inserts WO.J1207…
WOEJ-MM WOEJ-MH
- -MM geometry provides lower cutting forces. First choice for steel, stainless steel, and high-temp alloys.
- -MH geometry is the fi rst choice for high-strength steel and cast iron.
- -MR geometry is designed for heavy-duty steel and cast iron applications.
- WOEJ-MM
fi rst choice alternate choice
P M K N S H
cutting
| catalogue number | edges | D | S | R¡ |
| WOEJ120712SRMM | 6 | 12,00 | 7,30 | 1,27 |
- WOEJ-MH
cutting
| catalogue number | edges | D | S | R¡ |
| WOEJ120712SRMH | 6 | 12,00 | 7,30 | 1,27 |
