- Double-sided, six cutting edges.
- Highest metal removal rates.
- First choice for roughing applications.
- Shell Mills
coolant
| order number | catalogue number | D1 max | D1 | D | D6 | L | Ap1 max | Z | max RPM | supply | kg |
| 5338913 | M370D50Z04WO12 | 50,0 | 33 | 22 | 42 | 50 | 2,0 | 4 | 19530 | Yes | 0,38 |
| 5338914 | M370D52Z04WO12 | 52,0 | 35 | 22 | 49 | 50 | 2,0 | 4 | 19160 | Yes | 0,47 |
| 5338915 | M370D63Z04WO12 | 63,0 | 46 | 22 | 49 | 50 | 2,0 | 4 | 17400 | Yes | 0,57 |
| 5338916 | M370D63Z05WO12 | 63,0 | 46 | 22 | 49 | 50 | 2,0 | 5 | 17400 | Yes | 0,57 |
| 5338917 | M370D66Z05WO12 | 66,0 | 49 | 27 | 60 | 50 | 2,0 | 5 | 17000 | Yes | 0,79 |
| 5338918 | M370D80Z05WO12 | 80,0 | 63 | 27 | 60 | 50 | 2,0 | 5 | 15440 | Yes | 0,94 |
| 5338919 | M370D80Z06WO12 | 80,0 | 63 | 27 | 60 | 50 | 2,0 | 6 | 15440 | Yes | 0,94 |
| 5338920 | M370D100Z06WO12 | 100,0 | 83 | 32 | 78 | 50 | 2,0 | 6 | 13810 | Yes | 1,56 |
| 5338921 | M370D100Z07WO12 | 100,0 | 83 | 32 | 78 | 50 | 2,0 | 7 | 13810 | Yes | 1,57 |
| 5338922 | M370D125Z07WO12 | 125,0 | 108 | 40 | 90 | 63 | 2,0 | 7 | 12350 | Yes | 2,92 |
| 5338923 | M370D125Z09WO12 | 125,0 | 108 | 40 | 90 | 63 | 2,0 | 9 | 12350 | Yes | 2,94 |
- Spare Parts
| insert | Torx Plus | socket-head | socket-head cap screw | coolant | coolant lock | |||||||
| D1 max | screw | Nm | driver | cap screw | with coolant groove | lock screw | screw assembly | |||||
| 50 | MS2085 | 4,0 | DT15IP | 12146120500 | MS1234CG | — | — | |||||
| 52 | MS2085 | 4,0 | DT15IP | 12146120500 | MS1234CG | — | — | |||||
| 63 | MS2085 | 4,0 | DT15IP | 125.025 | MS1234CG | — | — | |||||
| 66 | MS2085 | 4,0 | DT15IP | 125.230 | MS2038CG | — | — | |||||
| 80 | MS2085 | 4,0 | DT15IP | 125.230 | MS2038CG | — | — | |||||
| 100 | MS2085 | 4,0 | DT15IP | — | — | KLS32M | MS2195C | |||||
| 125 | MS2085 | 4,0 | DT15IP | — | — | KLS40M | MS2187C |
NOTE: Socket-head cap screw with coolant groove and coolant lock screw assembly must be ordered separately.
