- Double-sided, six cutting edges.
- Highest metal removal rates.
- First choice for roughing applications.
- Screw-On End Mills
max ramp coolant
| order number | catalogue number | D1 max | D1 | D | DPM | G3X | L2 | WF | Ap1 max | Z | angle | max RPM | supply | kg | ||
| 5338912 | M370D42Z03M16WO12 | 42 | 25 | 29 | 17,0 | M16 | 40 | 24 | 2,0 | 3 | 5.1° | 21310 | Yes | 0,22 |
- Spare Parts
insert Torx
| D1 max | screw | Nm | driver | |
| 42 | MS2085 | 4,0 | DT15IP |
