Shoulder Mills • M690 Series
Inserts

„
Insert Selection Guide
Light General Heavy
Machining Purpose Machining
Material
Group Geometry Grade Geometry Grade Geometry Grade
P1–P2 .E..ML TN6540 .S..MM TN6540 .S..MH TN6540
P3–P4 .E..ML TN7535 .S..MM TN6540 .S..MH TN6540
P5–P6 .E..ML TN7535 .S..MM TN6540 .S..MH TN6540
M1–M2 .E..ML TN6540 .S..MM TN6540 .S..MH TN6540
M3 .E..ML TN7535 .S..MM TN7535 .S..MH TN7535
K1–K2 .E..ML WK15CM .E..ML WK15CM .S..MH WK15CM


Shoulder Mills
K3 .E..ML WK15CM .S..MM TN6525 .S..MH TN6525
N1–N2 .ALP THM-U .E..ML THM-U .S..ML THM-U
N3 .ALP THM-U .E..ML THM-U .S..ML THM-U
S1–S2 .E..ML TN6540 .S..MM TN6540 .S..MM TN6540
S3 .E..ML TN6540 .S..MM WS30PM .S..MM TN6540
S4 .E..ML TN6540 .S..MM WS30PM .S..MM TN6540
H1 .S..MM WS30PM .S..MM WS30PM .S..MM WS30PM

Inserts • SD1204..
P
M
 first choice
K
SDMT-ML SDMX-MM  alternate choice
N
S
SDMT-ML SDMX-MM
H
„
SDMT-ML


WK15CM
WS30PM
TN2510
TN6520
TN6525
TN6540
TN7525
TN7535
cutting
catalogue number edges D L10 S BS R¡ hm
3094667
3020185
2030439
2030437
5427423
SDMT1204PDRML 4 12,70 12,70 4,77 1,10 1,20 0,08
–
–


–
„
SDMX-MM WK15CM
WS30PM
TN2510
TN6520
TN6525
TN6540
TN7525
TN7535


cutting
catalogue number edges D L10 S BS R¡ hm
3950588
3950589
3950590
3950591
5522490


SDMX120408RMM 4 12,70 12,70 4,76 1,93 0,80 0,10
–
–


–
3950596
3950597
3950599
3950600
5519572


SDMX120412RMM 4 12,70 12,70 4,76 1,50 1,20 0,10
–
–


–
4145063
4145064
4145065


SDMX120416RMM 4 12,70 12,70 4,76 1,50 1,60 0,10
–


–
–
–
–
4145072
4145093


SDMX120424RMM 4 12,70 12,70 4,76 0,60 2,40 0,10
–
–
–
–
–
–
4145094
4145095


SDMX120432RMM 4 12,70 12,70 4,76 — 3,20 0,10
–
–
–
–
–
–


widia.com J45
