Trapez-Internal
IR/L-TR
first choice alternate choice
P M K N S H
insert thread
| catalogue number | EX | E | size | pitch mm | TPI | TPF | |||
| right hand | |||||||||
| 3IR3TR | 1,3 | 1,5 | 3 | 3,00 | — | — |
4IR4TR 1,7 1,9 4 4,00 — —
4IR5TR 2,1 2,5 4 5,00 — —
5IR6TR 2,3 2,7 5 6,00 — —
