29°
29°
Stub ACME
first choice alternate choice
P M K N S H
- NAS
insert
| catalogue number | CF | E | size | TPI | |
| right hand | |||||
| NAS3R8 | 1,21 | 3,79 | 3 | 8 |
left hand
NAS3L12 0,83 3,79 3 12
NAS3L8 1,21 3,79 3 8
NAS3L6 1,66 3,79 3 6
45° 7°
American Buttress-Pull
- NTB-B
insert
| catalogue number | RC | E | size | TPI | TPF | ||
| left hand | |||||||
| NTB3LB | 0,17 | 0,31 | 3 | 8-16 | — |
