Right Hand Tool

  • Universal Style Toolholder • 76mm Bar Capacity

support blade clamp

order numbercatalogue numberBHH2FL1Lscrewscrew
right hand
353873920641127,0025,0056,3639,78102,96150,85MS1072MS352
361530620644327,0032,0056,3639,78102,96150,85MS1072MS1294

NOTE: Support blade requires two screws. Order blades separately.

  • Components

W L1 FS left hand clamp support blade right hand clamp

WL1FSleft hand clampsupport blade right hand clamp
3.057,051,27435137309111 435136
4.057,051,84435106309105 435103
ll components ship separately.L1 Blade L1 Holder L1 Assy
F Holder
F Assy W FS Blade
L1 Assy = L1 (holder) + L1 (blade) F Assy = F (holder) + FS (blade) + W/2
