Custom Solutions

Custom Solution Worksheet

For more than 50 years, WIDIA-CIRCLE™ has offered the most reliable, highest-quality small hole boring bars available. Flat Location(s) Although our extensive product line covers most machining applications, we understand that a custom solution tool may be required.

Straight Shank-Type Boring Bars

Steel or Carbide

Date

Customer-Specifi ed Dimensions

= O.A.L. (Overall Length) From 3x bar diameter to catalogue length.

= “F” Dimension 0,254mm from basic dimension shown in catalogue triangle insert bars only.

= “A” Dimension +10° to -10° triangle insert bars only.

= Flat Location(s) 1 Flat — no charge (see illustration above).

Special Instructions (please make any necessary notes or sketches in the box at right)

Closest Catalogue Standard

Customer

Distributor

Shipping Requirements

Attention Distributors: Use this worksheet to collect information for your customer.

UGround UNext Day Air U2nd Day Air U3rd Day Air
