How Do Catalogue Numbers Work?
Each character in our catalogue number signifi es a specifi c trait of that
product. Use the following key columns and corresponding images
to easily identify which attributes apply.
MCFNR10CA3
M C F N R
Insert Insert Shape Cartridge Insert Clearance Hand of Tool
Clamping System Style Angle
C Right-hand cartridge
C F K C
R
D L J N
Top clamping by clamping
R Q R P
fi nger for inserts without hole.
M Left-hand cartridge
S S G
L T
W
Top and hole clamping for inserts with hole.
P
Insert clamping by toggle lever for insert hole.
S
Centre clamping by screw for inserts with hole.
