Simple and secure mounting to the tool by a single cartridge clamping screw. High accuracy on “F” dimension ensures proper application to minimum bore dimensions.

Same clamping systems as standard turning toolholders. Overall sizes to DIN and ISO are ideal for single- and multi-tooth turning, boring, and spotting tools.

Precise axial and radial positioning by adjustment screws.

Clamping System C Clamping System S

• Top clamping system for negative and
• Screw clamping system for positive indexable inserts

positive indexable inserts to DIN 4968. with countersunk hole to DIN 4967.

• This universal clamping system is robust
• Compact design using a minimum of spare parts

and easy to handle. for high reliability and cost effi ciency.

• Some height-adjustable clamps enable
• A carbide shim provides additional tool protection.

the use of additional chipbreakers. Toolholders with cutting edge heights upwards of

• A carbide shim provides additional 16mm (.625") and insert iCs from 9,52mm (.375") tool protection. are secured by means of a threaded bushing.
