Steel shank with through coolant. See pages B47–B64 for inserts.
- A-DDQN 107,5°
| gage | shim | Torx | clamp | slotted | Torx | ||||||||||
| order number catalogue number | DDmin | F | L1 | CS | aF° | aP° | insert | shim | screw | Plus | assembly | pin | Plus | ||
| right hand | |||||||||||||||
| 5696085 | A32SDDQNR15KC06 32 40,0 22,0 250 1/4-18 NPT -12.0 -10.0 DN..150608 IDSN433 KMSP415IP 15 IP CM234RLP ASSY SSP025016M 15 IP |
| 5696087 | A40TDDQNR15KC06 40 50,0 27,0 300 1/4-18 NPT -10.0 -10.0 DN..150608 IDSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP |
| left hand | |||
| 5696086 | A32SDDQNL15KC06 32 40,0 22,0 250 1/4-18 NPT -12.0 -10.0 DN..150608 IDSN433 KMSP415IP 15 IP CM234RLP ASSY SSP025016M 15 IP | ||
| 5696088 | A40TDDQNL15KC06 40 50,0 27,0 300 1/4-18 NPT -10.0 -10.0 DN..150608 IDSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP |
Steel shank with through coolant. See pages B47–B64 for inserts.
- A-DDUN 93°
| gage | shim | Torx | clamp | Torx slotted | ||||
| order number | catalogue number | DDmin | insert aF° CS L1 F | shim | screw | Plus | assembly | Plus pin |
| right hand | ||||||||
| 5696089 | A25RDDUNR11KC04 25 32,0 17,0 200 1/4-18 NPT -12.0 DN..110408 | — | — | — | CM234RLP ASSY SSP025016M 15 IP | |||
| 5696211 | A32SDDUNR11KC04 | 32 40,0 22,0 250 1/4-18 NPT -12.0 DN..110408 | IDSN322 KMSP315IP 15 IP | CM234R ASSY | SSP025016M 15 IP | |||
| 5696213 | A32SDDUNR15KC06 | 32 40,0 22,0 250 1/4-18 NPT -12.0 DN..150608 | IDSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP | |||
| 5696215 | A40TDDUNR15KC06 | 40 50,0 27,0 300 1/4-18 NPT -9.0 DN..150608 | IDSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP | |||
| 5696217 | A50UDDUNR15KC06 50 63,0 35,0 350 1/4-18 NPT -7.0 DN..150608 | IDSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP | ||||
| left hand | ||||||||
| 5696210 | A25RDDUNL11KC04 25 32,0 17,0 200 1/4-18 NPT -12.0 DN..110408 | — | — | — | CM234RLP ASSY SSP025016M 15 IP | |||
| 5696212 | A32SDDUNL11KC04 | 32 40,0 22,0 250 1/4-18 NPT -12.0 DN..110408 | IDSN322 KMSP315IP 15 IP | CM234R ASSY | SSP025016M 15 IP | |||
| 5696214 | A32SDDUNL15KC06 | 32 40,0 22,0 250 1/4-18 NPT -12.0 DN..150608 | IDSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP | |||
| 5696216 | A40TDDUNL15KC06 | 40 50,0 27,0 300 1/4-18 NPT -9.0 DN..150608 | IDSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP | |||
| 5696218 | A50UDDUNL15KC06 | 50 63,0 35,0 350 1/4-18 NPT -7.0 DN..150608 IDSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP |
