Steel shank with through coolant. See pages B30–B46 for inserts.
- A-DCLN 95°
| gage | shim | Torx | Torx slotted clamp | |||||
| order number | catalogue number | DDmin | insert aF° CS L1 F | shim | screw | Plus | Plus pin assembly | |
| right hand | ||||||||
| 5696071 | A25RDCLNR12KC04 25 32,0 17,0 200 1/4-18 NPT -12.0 CN..120408 | — | — | — | CM234RLP ASSY SSP025016M 15 IP | |||
| 5696073 | A32SDCLNR12KC04 32 40,0 22,0 250 1/4-18 NPT -12.0 CN..120408 | ICSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP | ||||
| 5696075 | A40TDCLNR12KC04 40 50,0 27,0 300 1/4-18 NPT -9.0 CN..120408 | ICSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP | ||||
| 5696077 | A40TDCLNR16KC06 32 45,0 27,0 250 1/4-18 NPT -12.0 CN..160612 | ICSN533 KMSP515IP 15 IP | CM209R ASSY | SSP025018M 15 IP | ||||
| left hand | ||||||||
| 5696072 | A25RDCLNL12KC04 | 25 32,0 17,0 200 1/4-18 NPT -12.0 CN..120408 | — | — | — | CM234RLP ASSY SSP025016M 15 IP | ||
| 5696074 | A32SDCLNL12KC04 40 50,0 27,0 300 1/4-18 NPT -9.0 CN..120408 | ICSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP | ||||
| 5696076 | A40TDCLNL12KC04 | 32 45,0 27,0 250 1/4-18 NPT -12.0 DN..150608 | ICSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP | |||
| 5696078 | A40TDCLNL16KC06 | 32 45,0 27,0 250 1/4-18 NPT -12.0 CN..160612 | ICSN533 KMSP515IP 15 IP | CM209R ASSY | SSP025018M 15 IP |
Steel shank with through coolant. See pages B47–B64 for inserts.
- A-DDPN 117,5°
| gage | shim | Torx | clamp | slotted | Torx | |||||||||
| order number catalogue number | DDmin | F | L1 L1A | CS | aF° | insert | shim | screw | Plus | assembly | pin | Plus | ||
| right hand | ||||||||||||||
| 5696079 | A25RDDPNR11KC04 32 45,0 27,0 250 6,5 1/4-18 NPT -12.0 DN..150608 IDSN322 KMSP315IP 15 IP CM234RLP ASSY SSP025016M 15 IP |
| 5696080 | A32SDDPNR15KC06 40 52,0 30,0 300 6,6 1/4-18 NPT -10.0 DN..150608 IDSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP |
| 5696082 | A40TDDPNR15KC06 40 52,0 30,0 300 6,6 1/4-18 NPT -10.0 DN..150608 IDSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP |
| left hand | |||
| 5696081 | A32SDDPNL15KC06 40 52,0 30,0 300 6,6 1/4-18 NPT -10.0 DN..150608 IDSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP |
| 5696083 | A40TDDPNL15KC06 40 52,0 30,0 300 6,6 1/4-18 NPT -10.0 DN..150608 IDSN433 KMSP415IP 15 IP | CM234R ASSY | SSP025016M 15 IP |
