See pages B99–B105 for inserts.
DWLN 95°
| gage | slotted Torx clamp Torx shim optional | ||
| order number | catalogue number | insert L1 LH B3 F H B shim | pin Plus assembly Plus screw lock pin |
| right hand | |||
| 5696757 | DWLNR2020K06KC04 20 20 25,0 125 31,0 — WN..060408 | IWSN322 KMSP315IP 15 IP CM234R ASSY 15 IP SSP025016M | KLM34L9IP |
| 5696758 | DWLNR2020K08KC04 20 20 25,0 125 33,0 — WN..080408 | IWSN433 KMSP415IP 15 IP CM234R ASSY 15 IP SSP025016M | KLM4615IP |
| 5696759 | DWLNR2525M06KC04 25 25 32,0 150 25,0 — WN..060408 | IWSN322 KMSP315IP 15 IP CM234R ASSY 15 IP SSP025016M | KLM34L9IP |
| 5696760 | DWLNR2525M08KC04 25 25 32,0 150 25,0 4,0 WN..080408 | IWSN433 KMSP415IP 15 IP CM234R ASSY 15 IP SSP025016M | KLM4615IP |
| 5696761 | DWLNR3225P08KC04 32 25 32,0 170 25,0 4,0 WN..080408 | IWSN433 KMSP415IP 15 IP CM234R ASSY 15 IP SSP025016M | KLM4615IP |
| 5696762 | DWLNR3232P08KC04 32 32 40,0 170 25,0 — WN..080408 | IWSN433 KMSP415IP 15 IP CM234R ASSY 15 IP SSP025016M | KLM4615IP |
| left hand | |||
| 5696751 | DWLNL2020K06KC04 20 20 25,0 125 31,0 — WN..060408 | IWSN322 | KMSP39IP 15 IP CM234R ASSY 15 IP SSP025016M KLM34L9IP |
| 5696752 | DWLNL2020K08KC04 20 20 25,0 125 33,0 — WN..080408 | IWSN433 KMSP415IP 15 IP CM234R ASSY 15 IP SSP025016M | KLM4615IP |
| 5696753 | DWLNL2525M06KC04 25 25 32,0 150 25,0 — WN..060408 | IWSN322 KMSP315IP 15 IP CM234R ASSY 15 IP SSP025016M | KLM34L9IP |
| 5696754 | DWLNL2525M08KC04 25 25 32,0 150 25,0 4,0 WN..080408 | IWSN433 KMSP415IP 15 IP CM234R ASSY 15 IP SSP025016M | KLM4615IP |
| 5696755 | DWLNL3225P08KC04 | 32 25 32,0 170 25,0 4,0 WN..080408 IWSN433 KMSP415IP 15 IP CM234R ASSY 15 IP SSP025016M | KLM4615IP |
| 5696756 | DWLNL3232P08KC04 | 32 32 40,0 170 25,0 — WN..080408 IWSN433 KMSP415IP 15 IP CM234R ASSY 15 IP SSP025016M | KLM4615IP |
