first choice alternate choice
- SNGA
P M K N S H
ISO
| catalogue number | D | L10 | S | R¡ | D1 |
| SNGA120408T02020 | 12,70 | 12,70 | 4,76 | 0,8 | 5,16 |
SNGA120412T02020 12,70 12,70 4,76 1,2 5,16
SNGA120416T02020 12,70 12,70 4,76 1,6 5,16
SNGA150612T02020 15,88 15,88 6,35 1,2 6,35
SNGA150616T02020 15,88 15,88 6,35 1,6 6,35
- SNGX
ISO
| catalogue number | D | L10 | S | R¡ | D1 |
| SNGX120708T02020 | 12,70 | 12,70 | 7,94 | 0,8 | — |
SNGX150716T02020 15,88 15,88 7,94 1,6 —
