| �first choice | P M K | � | � | |||||
| N/SNG ISO catalogue number | D | L10 | S | �alternate choice R � | D1 | N S H | � � CW2015 CW3020 | CW5025 |
| SNGN090308T02020 | 9,53 | 9,53 | 3,18 | 0,8 | — | 2952748 | – – | |
| SNGN090412T00515 | 9,53 | 9,53 | 4,76 | 1,2 | — | 2952749 | – – | |
| SNGN120408T00520 | 12,70 | 12,70 | 4,76 | 0,8 | — | 2952750 | – – | |
| SNGN120408T02020 | 12,70 | 12,70 | 4,76 | 0,8 | — | 2952751 | – 2952135 | |
| SNGN120412T01020 | 12,70 | 12,70 | 4,76 | 1,2 | — | – 3869756 | – | |
| SNGN120412T02020 | 12,70 | 12,70 | 4,76 | 1,2 | — | 2952752 | – 2952136 | |
| SNGN120416T01020 | 12,70 | 12,70 | 4,76 | 1,6 | — | – 3869757 | – | |
| SNGN120416T02020 | 12,70 | 12,70 | 4,76 | 1,6 | — | – | – 2952137 | |
| SNGN120704T02020 | 12,70 | 12,70 | 7,94 | 0,4 | — | 2952824 | – – | |
| SNGN120708T02020 | 12,70 | 12,70 | 7,94 | 0,8 | — | 2952825 | – – | |
| SNGN120712T00520 | 12,70 | 12,70 | 7,94 | 1,2 | — | 2953339 | – – | |
| SNGN120712T01020 | 12,70 | 12,70 | 7,94 | 1,2 | — | (contin – 3869758 | ued) – |
