(VT-SPO • Form B Plug Chamfer • Machine Screw and Fractional • DIN 371 and 376 — continued)
first choice alternate choice
grade WU41EGWU41EG grade WP49EGWP49EG
TiN Oxide metric dimensions
number dimension class
| order # catalogue # | order # catalogue # | D1 size | L | L3 | L2 | D | of flutes | standard | of fit |
| 5472664 VTSPO6034 | 5387785 VTSPO6034 | 5/8 - 18 | 110 | 24 | 51 | 12,0 | 3 | DIN 376 | 2B |
| 5472665 VTSPO6035 | 5387786 VTSPO6035 | 3/4 - 10 | 140 | 30 | 64 | 16,0 | 3 | DIN 376 | 2B |
| 5472666 VTSPO6036 | 5387787 VTSPO6036 | 3/4 - 16 | 140 | 30 | 64 | 16,0 | 3 | DIN 376 | 2B |
| 5472667 VTSPO6037 | 5387788 VTSPO6037 | 7/8 - 9 | 140 | 34 | 71 | 18,0 | 3 | DIN 376 | 2B |
| 5472668 VTSPO6038 | 5387789 VTSPO6038 | 7/8 - 14 | 140 | 34 | 71 | 18,0 | 3 | DIN 376 | 2B |
| 5472669 VTSPO6039 | 5387790 VTSPO6039 | 1 - 8 | 160 | 38 | 81 | 18,0 | 3 | DIN 376 | 2B |
| 5472670 VTSPO6040 | 5387791 VTSPO6040 | 1 - 12 | 160 | 38 | 81 | 18,0 | 3 | DIN 376 | 2B |
