  • Basic body shipped without insert holders.
  • Order insert holder, slides, or micro-adjustable cartridges separately.

L1 Assy L1 Assy = L1 body + L1 insert holder

  • TCHS KM™ Shank Series
order numbercatalogue numberBR1 bore rangeL1CSMS system sizekg
3861149KM32TSTCHS02203022,000-30,00052,7KM32TS0,30
3861150KM32TSTCHS03003930,000-39,00067,7KM32TS0,50
3861152KM40TSTCHS03003930,000-39,00087,7KM40TS0,60
3861151KM32TSTCHS03905039,000-50,00063,7KM32TS0,70
3861173KM40TSTCHS03905039,000-50,00083,7KM40TS1,00
3861174KM40TSTCHS05006750,000-67,00078,2KM40TS1,10
3861175KM50TSTCHS05006750,000-67,00088,2KM50TS1,20
3861176KM50TSTCHS06708867,000-88,00095,7KM50TS1,40
3861177KM63TSTCHS06708867,000-88,00095,7KM63TS1,80
3861178KM63TSTCHS08811588,000-115,00093,7KM63TS2,40
  • Spare Parts

fixing disc

catalogue number screw washer

catalogue numberfixing screwdisc washer
KM32TSTCHS0220301214760270012147600100
KM32TSTCHS0300391214760230012147603900
KM32TSTCHS0390501214760240012147600200
KM40TSTCHS0300391214760230012147603900
KM40TSTCHS0390501214760240012147600200
KM40TSTCHS0500671214760250012147604000
KM50TSTCHS0500671214760250012147604000
KM50TSTCHS0670881214760260012147600300
KM63TSTCHS0670881214760260012147600300
KM63TSTCHS0881151214760280012147600400
